Cloning the Programmed Data

You can transfer the programmed data to and from another PSR-300 (or PSR-
400) scanner using an optional connecting cable with 1/8-inch (3.5 mm) stereo
phone plugs on both ends (not supplied).
Note: CLONE MODE Incorrect Model appears if the scanner receives data
from another scanner other than a PSR-300 (or PSR-400).
Follow these steps to clone the data.
1. Turn on both scanners.
2. Connect the connecting cable to each scanner's PC/IF jack. ** CLONE
MODE ** Press UP to send Remove cable to exit. appears.
3. Press . Confirm to send data? 1 -> YES Press other key for NO. ap-
pears.
4. Press 1 to send the data to the other unit or press any other key to cancel
the operation.
The scanner sends the data. To exit the clone mode, remove the cable.
46
