Abit IT5A User Manual page 18

2-6
PN1 - Hardware Reset connectors
There is no specific orientation.
to the PN1 connector pins on the mainboard.
Pin number
1
2
PN1 - Sleep LED connector
This connector has a specific orientation.
connector cable attached to the case to the Sleep LED connector on the
mainboard.
Pin number
9
10
FAN1 - CPU Fan power connector
This has a specific orientation. Connect the three-threads CPU fan cable to the
FAN1 connector.
Pin number
1
2
3
Name or significance of signal
Hardware reset signal
Ground
Name or significance of signal
LED's Cathode
LED's Anode
Name of the signal or signification
Control on / off
+12V
Sensor
Connect the two-thread hardware reset cable
Connect the two-thread Sleep LED
Chapter 2
