CyberGuard SG300 User Manual page 286

Note
If you are using an older LITE(2)/LITE(2)+, you may have to attach the unit's WAN port
directly to your PC using a crossover cable for the first stage of the recovery procedure.
The Netflash program prompts you to switch the cable to the LAN port/switch using a
straight through for the second stage of the recovery procedure.
Log in to your PC with administrator privileges (2000/XP/NT4 only).
Ensure there are no DHCP server programs or services (Start -> Run -> Open:
services.msc) running on your PC.
Disable the inbuilt Windows firewall (Control Panel -> Windows Firewall), and any third
party firewall or antivirus software.
Hold in the Reset/Erase button while applying power, keep it held in for 3 seconds.
Double click on Netflash to launch it.
Click Recover and select Network Recovery.
Click Recover Device.
Enter an address in the same network range as your PC and click OK
Note
If the recovery procedure fails at or after Assigning IP address.., but the Heart Beat/H/B
light is flashing, the unit may have become uncontactable due to bad configuration. If this
is the case, hit the Reset/Erase button twice within 2 seconds to restore factory default
configuration, power off the unit and restart the recovery procedure from the beginning.
If prompted, select your CyberGuard SG unit from the list displayed.
Enter your CyberGuard SG unit's password and click OK.
If prompted, enter your CyberGuard SG unit's web administration port.
282
Appendix D – Recovering From a Failed Upgrade
