HEAVY-DUTY PLANER
MODEL H3141
INSTRUCTION MANUAL
COPYRIGHT © DECEMBER 2002 BY GRIZZLY INDUSTRIAL, INC.
1821 VALENCIA ST., BELLINGHAM, WA 98227
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
PRINTED IN CHINA
ONLINE MANUAL DISCLAIMER
THE INFORMATION IN THIS MANUAL REPRESENTS THE CONFIGURATION OF THE MACHINE
AS IT IS CURRENTLY BEING SHIPPED. THE MACHINE CONFIGURATION CAN CHANGE AS
PRODUCT IMPROVEMENTS ARE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF
THE MACHINE, THIS MANUAL MAY NOT EXACTLY DEPICT YOUR MACHINE . CONTACT CUS-
TOMER SERVICE IF YOU HAVE ANY QUESTIONS ABOUT DIFFERENCES. PREVIOUS VER-
SIONS ARE NOT AVAILABLE ONLINE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H3141 and is the answer not in the manual?

Questions and answers

Related Manuals for Grizzly H3141

Summary of Contents for Grizzly H3141

  • Page 1 COPYRIGHT © DECEMBER 2002 BY GRIZZLY INDUSTRIAL, INC. 1821 VALENCIA ST., BELLINGHAM, WA 98227 WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. PRINTED IN CHINA ONLINE MANUAL DISCLAIMER THE INFORMATION IN THIS MANUAL REPRESENTS THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED.
  • Page 2 Some dust created by power sanding, sawing, grind- ing, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints. •...

  • Page 3: Safety Instructions

    ENCE OF DRUGS OR ALCOHOL. NEVER ALLOW UNTRAINED USERS TO RUN THIS TOOL WHILE UNSUPERVISED. H3141 Heavy-Duty Planer WEAR PROPER APPAREL. Do not wear loose clothing, gloves, neckties, rings, bracelets, or other jewelry which may get caught in moving parts. Non-slip footwear is recommended.

  • Page 4: Safety Instructions For Power Tools

    No list of safety guidelines can be complete. Operating this tool may require additional safety precau- tions specific to your working environment. Failure to use rea- sonable caution while operating this tool could result in serious personal injury. H3141 Heavy-Duty Planer...
  • Page 5 We are pleased to provide this manual with the Model H3141. It was written to encourage safety considerations and guide you through general operating pro- cedures and maintenance. This manual represents our effort to produce the best documentation possible.
  • Page 6 Power Switch Power Switch Belt Cover Fence Figure 1. Left Side Brush/Motor Cover Cutterhead Assembly Infeed Sole Retractable Side Blade Guard Figure 3. Bottom Lock-On Depth Control Knob Depth Stop Dust Bag Figure 2. Right Side Outfeed Sole H3141 Heavy-Duty Planer...

  • Page 7: Electrical & Adjustments

    110 volts and capa- ble of handling a 6 amp current. The plug on the Model H3141 is a 2 prong double insulated style and should only be plugged into a grounded power outlet. If you are unsure about your electrical system, con- tact a qualified electrician.

  • Page 8: Operation

    Review the Electrical sec- tion. If the fence will be used, attach the fence to the planer and adjust it to the desired width of cut. Make sure all knobs are secure. The planer is ready to be operated!

  • Page 9: Maintenance

    8. Re-insert the blade into the blade hold- er so the new edge will be revealed. New blades can be purchased in the current Grizzly Catalog as Part #H4999. 9. Re-install the blade holder into the cut- terhead.
  • Page 10 To replace the motor brushes, loosen the phillips screws on the vented motor cover and set the motor cover aside. Remove the brush holders and brushes, and replace with new ones as shown in Figure 13. Figure 13. Changing motor brushes. H3141 Heavy-Duty Planer...
  • Page 12 PH3141067 LOCK KNOB PH3141068 SPECIAL BOLT M6-1.0 X 24 PH3141069 BUSHING PH3141070 DEPTH GAUGE PH3141071 FIXATION FRAME PH3141072 BUSHING PH3141073 KNOB BOLT M6-1.0 X 10 PCB5M CARRIAGE BOLT M6-1.0 X 12 PH3141075 BAFFLE PWN01M WING NUT M6-1.0 H3141 Heavy-Duty Planer...
  • Page 13 NOTES H3141 Heavy-Duty Planer...
  • Page 14 NOTES H3141 Heavy-Duty Planer...
  • Page 15 NOTES H3141 Heavy-Duty Planer...

  • Page 16: Warranty And Returns

    WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of main- tenance.
