Brinly SAT-40 BH Owner's Manual

40” lawn aerator
Hide thumbs Also See for SAT-40 BH:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
O W N E R ' S M A N U A L
4 0 " L A W N A E R A T O R
MO DE L :
S AT- 4 0 B H
Assembly
Installation
Operation

Repair Parts

For the latest product updates and setup tips:
Important: This manual contains information for the safety of
persons and property. Read it carefully before assembly and
operation of the equipment!
Visit us on the web!
www.brinly.com
L-1643-01-BH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAT-40 BH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brinly SAT-40 BH

Summary of Contents for Brinly SAT-40 BH

  • Page 1: Repair Parts

    O W N E R ' S M A N U A L 4 0 ” L A W N A E R A T O R MO DE L : S AT- 4 0 B H Assembly Installation Operation Repair Parts For the latest product updates and setup tips: Important: This manual contains information for the safety of...

  • Page 2: Customer Responsibilities

    CONGRATULATIONS on your new Brinly-Hardy Lawn Aerator! Your aerator has been designed, engineered and Keep the vehicle and attachment in good operating manufactured to give you the best possible dependablility and condition and keep safety devices in place.
  • Page 3 Tools Required for Assembly: * 1- Pair of work gloves * 1- Pair of Pliers * 1- Screwdriver (flat blade) * 2- 7/16” Wrenches * 1- 1/2” Wrech * 2- Adjustable Wrenches L-1643-01-BH...

  • Page 4: Parts Reference

    Parts Reference L-1643-01-BH...
  • Page 5 Parts List QTY. REF. NO. PART NO. DESCRIPTION R-821-10 Drawbar Clevis B-5925 Logo Decal B-5453-10 Tray B-3593-10 Drawbar B-4892-10 End Panel B-5832-10 Axel Assembly B-5423-10 Tine B-4888-10 Handle Assembly R-891 Wheel B-4867 Handle Grip R-1946 Caution Decal D-146P Hairpin Cotter 20M1012P Round Head Screw, 5/16”x3/4”...
  • Page 6 Figure 1. 5/16" Flat Washer 5/16" Lock Washer Qty. 6 Qty. 6 5/16" Hex Nut Round Head Screw Qty. 6 Qty. 6 Figure 2. 5/16" x 1" Round Head Screw Qty. 2 Roun Qty. 2 41” 5/16" Lock Washer Qty. 5 5/16"...
  • Page 7 Figure 3. 5/8” Washer (thick) 5/8” Washer (thin) Qty. 4 Qty. 2 WARNING! Tines have extremely sharp points. Wear gloves and handle with care Note: Round projections on Spacer/Bearing flanges must fit into small holes in Aerator tines and into holes of opposite Spacer/ Bearing flange.
  • Page 8 Figure 5. 1/4" Hex Lock Nut Qty. 1 1/4" Hex Bolt Qty. 1 Figure 6. 1/2" Hex Nut Qty. 4 1/2" Flat Washer Qty. 4 1/2” Lock Washer Qty. 2 1/2"x3” Hex Bolt Qty. 2 L-1643-01-BH...

  • Page 9: Operation

    Figure 7. MOUNTING AND TRANSPORTING Attatch Aerator to your rider using Pin (18) and Hairpin Cotter (12) supplied. To place in Transport Position: Pull FORWARD on Handle Assembly (8), pull out slightly and position over Transport Lock Pin (24). Aerator rests on wheels.
  • Page 10 Notes: L-1643-01-BH...
  • Page 11 Caring for the quality of your lawn w i t h th e pr o d u cts f rom Bri nly - Har dy Company N o mor e r ust or dents w i th thes e poly law n r oll er s.
