O W N E R ' S M A N U A L
4 0 " L A W N A E R A T O R
MODEL:
S A T - 4 0 B H
•
Assembly
•
Installation
•
Operation
•
Repair Parts
For the latest product updates & setup tips:
Visit us on the web!
www.brinly.com
Important: This manual contains information for the safety of
persons and property. Read it carefully before assembly and
operation of the equipment!
L-1643BH-D

Advertisement

loading
Need help?

Need help?

Do you have a question about the SAT-40 BH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brinly SAT-40 BH

Summary of Contents for Brinly SAT-40 BH

  • Page 1 • Repair Parts For the latest product updates & setup tips: Visit us on the web! Important: This manual contains information for the safety of www.brinly.com persons and property. Read it carefully before assembly and operation of the equipment! L-1643BH-D...

  • Page 2: Table Of Contents

    INTRODUCTION CONGRATULATIONS on the purchase of your new Brinly-Hardy Lawn Aerator! Your lawn aerator is designed, engineered and manufactured to give you the best possible dependability and performance. CUSTOMER RESPONSIBILITIES Please read and retain this manual. The instructions enables you to assemble and maintain your lawn aerator properly. And please, always observe the “Safety”...

  • Page 3: Safety

    SAFETY TO HELP PREVENT BODILY INJURY DUE TO LOSS OF TOWING SAFELY STABILITY OR CONTROL: • Stopping distance increases with speed and weight of towed load. Travel slowly and allow extra time and distance • Do not exceed maximum towing capacity of towing vehicle to stop.

  • Page 4: Parts Reference

    PARTS REFERENCE TOOLS REQUIRED FOR ASSEMBLY: • 1 - Pair of work gloves • 1 - Pair of pliers EXPLODED VIEW • 1 - Screwdriver (flat blade) • 2 - 7/16” Wrenches • 1 - 1/2” Wrench • 2 - 3/4” wrenches PARTS LIST PART NO.

  • Page 5: Assembly

    ASSEMBLY Step 1. ATTACH END PANELS TO TRAY 1a) Attach the two End Panels (5) to the Tray (3) using six 5/16” x3/4” Rd Hd. Screws (13), 5/16” Flat Washers (29), 5/16” Lock Washers (16) and 5/16” Hex Nuts (15), as shown.
  • Page 6 ASSEMBLY Step 3. ASSEMBLE TINES TO AXLE 3a) Place a 5/8” Flat Washer, Thick (17) onto the Axle Assembly (6), then slide it through the hole in End Panel (5 right Side) and add another Flat Washer Thick (17) if needed. 3b) Position the eleven Tines (7) and twenty-two Spacer/Bearing Tubes (27) onto the Axle Assembly (6) as...
  • Page 7 ASSEMBLY ATTACH HANDLE ASSEMBLY Step 4. 4a) Attach the Handle Assembly (8) to end the of the Axle Assembly (6) by inserting one 1/4” x 1-1/4” Hex Bolt (25) though the hole in the end of the Axle Assembly) and secure with 1/4”...
  • Page 8 ASSEMBLY Step 5. INSTALL WHEELS 4a) Attach one Wheel (9) to the Handle Assembly (8) and the other wheel to the wheel bar mount on the Axle (6). Secure to each side using hardware in the following order: Flat Washer, 1/2” Hex Nut, 1/2”...
  • Page 9 ASSEMBLY Step 6. MOUNTING & TRANSPORTING 6a) Attach Aerator to your towing vehicle using Drawbar Pin (18) and Hairpin Cotter (12) supplied. 6b) To place in Transport Position: • Pull FORWARD on Handle Assembly (8). • Pull out slightly and position over Transport Lock Pin (24).

  • Page 10: Operation

    OPERATION INSTALLING YOUR AERATOR OPERATING CAUTION: Avoid injury! Make sure feet and CAUTION: Avoid injury! Avoid damage to tines. hands are clear of Tine Tips. Engage the transport wheels when crossing concrete or asphalt driveways and walkways. Avoid injury! Do not operate lift handle unless attachment is installed to towing vehicle Excessive towed load can cause loss of control on slopes.

  • Page 11: Maintenance

    SERVICE MAINTENANCE After the first 30 minutes of use check all fasteners for tightness. Tines are manufactured with galvanized steel to resist wear of abrasive soil. Striking objects can cause tines to curl or break. Contact our Customer Service Department to purchase replace- ment Tines (Part # B-5423).
  • Page 12 MANUFACTURER’S LIMITED WARRANTY Pull Behind Accessories The limited warranty set forth below is given by Brinly-Hardy The provisions as set forth in this warranty provide the sole Company with respect to new merchandise purchased and and exclusive remedy arising from the sale. Brinly-Hardy Co.
