Brinly SAT2-40BH-S Owner's Manual

40" lawn aerator
Hide thumbs

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
4 0 " L A W N A E R A T O R
MODEL:
S AT 2 - 4 0 B H - S
• Assembly
• Installation
• Operation
• Repair Parts
Visit us on the web!
www.brinly.com
English Manual
Call Customer Service, Toll-Free: 877-728-8224
Important: This manual contains information for the safety
of persons and property. Read it carefully before
assembly and operation of the equipment!
1
1019099-F

Advertisement

loading
Need help?

Need help?

Do you have a question about the SAT2-40BH-S and is the answer not in the manual?

Questions and answers

Related Manuals for Brinly SAT2-40BH-S

Summary of Contents for Brinly SAT2-40BH-S

  • Page 1 • Operation • Repair Parts Call Customer Service, Toll-Free: 877-728-8224 Important: This manual contains information for the safety Visit us on the web! of persons and property. Read it carefully before www.brinly.com assembly and operation of the equipment! 1019099-F English Manual...

  • Page 2: Table Of Contents

    INTRODUCTION AND SAFETY ================================================================================================ CONGRATULATIONS on your new Brinly-Hardy Aerator! This accessory has been designed, engineered and manufactured to give you the best possible dependability and performance. Should you experience any problem you cannot easily remedy, please do not hesitate to contact our knowledgeable customer service department toll-free at 1-877-728-8224.

  • Page 3: Safety

    SAFETY ================================================================================================ GENERAL NOTES (OPERATION) Caution should be taken when towing and/or using any attachment. This attachment combined with the weight distribution, turning radius, and speed of towing vehicle can result in severe injury or death to operator, damage to towing vehicle, and/or attachment if not used properly. Follow all towing safety precautions noted in the towing vehicle owner’s manual, including the following precautions: - Ensure the combined weight of the towing vehicle (tow vehicle weight + operator weight) is greater...
  • Page 4 Please call our Customer Service attachment may impair its function, safety and void the Department, Toll Free: 877-728-8224 warranty. or customerservice@brinly.com TOWING VEHICLE AND TOWING SAFELY - Know your towing vehicle controls and how to stop safely. READ YOUR TOWING VEHICLE OWNER’S MANUAL before operating.

  • Page 5: Component View And Reference List

    PARTS REFERENCE ================================================================================================ Ref # Part # Description Ref # Part # Description 1019260-06 Drawbar Clevis 1019390 Washer; Flat, 5/8” (thick) 1019412 Tray B-3861 Drawbar Pin 1019415 Drawbar 1M1648P Bolt; Hex, 1/2” x 3” 1019244-06 End Panel 30M1600P Nut; Hex, 1/2” 1019283-06 Axle Assembly 1019753...
  • Page 6 HARDWARE IDENTIFIER ================================================================================================ DO NOT RETURN PRODUCT IF YOU ARE MISSING PARTS. Illustrations on this page Please Call: 1 (877) 728-8224 are to scale for faster identification of hardware during assembly. Nut: Hex Lock, 5/16” (x10) ..B-4786 Washer: Thick 5/8”...

  • Page 7: Assembly

    For faster identification of the hardware during assembly, simply lay the hardware on top of these illustrations. Additional info and videos are available on our website: brinly.com This QR code links directly to the Spike Aerator product page. Step 1...
  • Page 8 ASSEMBLY ================================================================================================ Step 2 Install Drawbar Attach drawbar (4) to the tray (3) using the following as illustrated: x2 - 5/16” x 3/4” Hex Head Bolts (13) x2 - 5/16" Hex Lock Nuts (15) Attach Clevis (1) to the Drawbar (4) using the following as illustrated: x2 - 5/16”...
  • Page 9 ASSEMBLY ================================================================================================ Step 3-A Place a 5/8” Thick, Flat Washer (16) on the Axle Assembly (6). Slide the Axle (6) through the hole in the End Panel (5, right side) and add another Flat Washer Thick (16) if needed. Step 3-B CAUTION: GLOVES ARE REqUIRED WHEN HANDLING AER ATOR TINES.
  • Page 10 ASSEMBLY ================================================================================================ Step 3-C Position as many extra washers (16 or 26) as needed to eliminate any side-to-side movement and push Axle Assembly (6) through hole in the left End Panel (5) as far as possible. See layout below. NOTE: Tines must not move from side to side inside opening of end panels. If lOOseNess exIsTs, use additional 5/8"...
  • Page 11 ASSEMBLY ================================================================================================ Step 4-B Slide the Handle Assembly (8) on the end of the Axle Assembly (6). Insert one 1/4” x 1-1/4” Hex Bolt (23) though the hole in the end of the Handle Assembly (8). Secure with 1/4-20” Nylon Lock Nut (24), as shown.
  • Page 12 ASSEMBLY ================================================================================================ Step 5-A While wearing gloves, carefully and gently flip the Spike Aerator over. Step 5-B IMPORTANT: Attaching the wheel without all of the proper hardware will cause the wheel to INSTALL FIRST WHEEL wobble. Insure all hardware is used, see Attach a wheel (9) to the wheel bar inset below.
  • Page 13 ASSEMBLY ================================================================================================ Step 5-C Attach the second wheel (9) to the Handle Assembly (6) using hardware in this order: • 1/2” x 3” Hex Bolt (19) • 1/2” Flat Washer (21) • Wheel (9) • 1/2” Flat Washer (21) • 1/2” Hex Nut (20) ( Handle Assembly ) •...

  • Page 14: Operation

    OPERATION ================================================================================================ CAUTION: Avoid damage to tines. Engage the transport wheels when crossing concrete or asphalt driveways and walkways. TRANSIT POSITION OPERATING POSITION - Pull FORWARD - Pull OUT on the on Handle Assembly (8). Handle Assembly (releasing from Transport - Pull out slightly and Position) and push position over Transport...
  • Page 15 Weight should be secured by rope, straps, or other suitable means to contain the weight in the tray. MODEL WEIGHT CAPACITY SAT2-40BH-S 42 lbs. (Empty) - Weight tray maximum capacity = 150 pounds. 150 lbs. (Max Load) - Moderate soil moisture is 192 lbs.

  • Page 16: Maintenance

    Maximum Towed Weight ... . 192 lbs. cotter pin for an extra-strong, convenient upgrade. - Diameter: 1/2” - Pin Length: 3” NOTE: Additional accesories are also available in our Parts Store online: shop.brinly.com 1019099-F English Manual...
  • Page 17 Please find your product serial number and model number, then contact our Customer Service department: In North America and Canada call Toll-Free: 877-728-8224 Chat online: www.brinly.com Email: customerservice@brinly.com NOTES 1019099-F English Manual...

  • Page 18: Warranty

    MANUFACTURER’S LIMITED WARRANTY AERATORS The limited warranty set forth below is given by Brinly-Hardy Company with respect to new merchandise purchased and used in the United States (its possessions and territories) and Canada. Brinly-Hardy Company warrants the products listed below against to use this product.
