OWNER'S MANUAL
4 0 " L A W N A E R A T O R
MODEL:
S A - 4 0 0 B H
• Assembly
• Installation
• Operation
• Repair Parts
For the latest product updates & setup tips:
Visit us on the web!
www.brinly.com
Important: This manual contains information for the safety
of persons and property. Read it carefully before
assembly and operation of the equipment!
Original Instructions
1008590BH-C
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Brinly S A - 4 0 0 B H
Summary of Contents for Brinly S A - 4 0 0 B H
- Page 1 OWNER'S MANUAL 4 0 " L A W N A E R A T O R MODEL: S A - 4 0 0 B H • Assembly • Installation • Operation • Repair Parts Original Instructions For the latest product updates & setup tips:...
-
Page 2: Table Of Contents
INTRODUCTION AND SAFETY ================================================================================================ CONGRATULATIONS on the purchase of your new Brinly-Hardy Aerator! Your tow at speeds higher than the maximum recommended towing speed. Aerator has been designed, engineered and manufactured to give you the best • Towing speed should always be slow enough to maintain control. Travel slowly possible dependability and performance. -
Page 3: Component View And Reference List
PARTS REFERENCE ================================================================================================ INSTALLATION Tools Required: QUESTIONS? MISSING PARTS? (1) Flat Head Screwdriver REPLACEMENT PARTS? (1) 1/2” Wrench STOP DON’T GO BACK (1) Set of Pliers or Hammer TO THE STORE! (1) Pair of Gloves. Please call our Customer Service Department Toll-Free at 877.728.8224 www.customerservice... -
Page 4: Assembly
ASSEMBLY ================================================================================================ Figure 1 Install Drawbar (3) to the Tray (5) using two 5/16" X 1" Round Head Screws (11), two 5/16" Lock Washers (13), and two 5/16" Hex Nuts (12) as shown in Figure Assemble the Clevis Drawbar (20) to the Drawbar (3) using two 5/16"... - Page 5 ASSEMBLY ================================================================================================ CAUTION: Gloves are required when handling aerator tines. Tines have extremely sharp points. Figure 4 Use caution when handling. 15 17 Position the 10 Tines (8) and 20 Bearings (9) onto the Tine Shaft as follows: * Bearing (9), small end fi rst * Tine (8) * Bearing (9), large end fi...
-
Page 6: Operation
OPERATION ================================================================================================ Figure 6 DEPTH / PENETRATION OF TINES CAUTION: Avoid injury! Openings in Tray allow access to Tines for cleaning and service. Excercise caution when working around Tray openings and avoid placing body parts into the openings. Bagged weight material can fall through Tray Openings and be torn open or damaged by the Tines. -
Page 7: Maintenance-Storage
MAINTENANCE-STORAGE ================================================================================================ MAINTENANCE The key to years of trouble-free service is to keep your Aerator clean and dry. After the fi rst 30 minutes of use, check all fasteners for tightness. Thereafter, periodically check all fasteners for tightness. Tines are manufactured with galvanized steel to resist wear of abrasive soil. Striking objects can cause Tines to curl or break. -
Page 8: Warranty Information
MANUFACTURER’S LIMITED WARRANTY Pull Behind Accessories The limited warranty set forth below is given by Brinly-Hardy respect to any product, shall bind Brinly-Hardy Co. During Company with respect to new merchandise purchased and used the period of the warranty, the exclusive remedy is repair or in the United States, its possessions and territories.
