Knoll HDP2300 User Manual

High definition projector
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PROJECTOR
User' s Manual
HDP2300 High Definition Projector

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDP2300 and is the answer not in the manual?

Questions and answers

Related Manuals for Knoll HDP2300

Summary of Contents for Knoll HDP2300

  • Page 1 PROJECTOR User’ s Manual HDP2300 High Definition Projector...
  • Page 2 Copyright This publication, including all photographs, illustrations and software, is protected under international copy- right laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. © Copyright 2010 Disclaimer The information in this document is subject to change without notice.

  • Page 3: Important Safety Information

    HDP2300 Users Manual Important Safety Information Important: It is strongly recommended that you read this section carefully before using the projector. These safety and usage instructions will ensure that you enjoy many years of safe use of the projector. Keep this manual for future reference.

  • Page 4: Projector Installation Notice

    Preface Projector Installation Notice Place the projector in a horizontal position The tilt angle of the projector should not exceed 15 degrees, nor should the projector be installed in any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically. Allow at least 50 cm clearance around the exhaust vent.
  • Page 5 HDP2300 Users Manual Replacing the Lamp Replacing the lamp can be hazardous if done incorrectly. See Replacing the Projection Lamp on page 35 for clear and safe instructions for this procedure. Before replacing the lamp: Unplug the power cord. Allow the lamp to cool for about one hour.

  • Page 6: Table Of Contents

    GETTING STARTED ................................1 ................................1 ACKING HECKLIST ............................... 2 IEWS OF ROJECTOR ARTS HDP2300 Series Front-right View..........................2 Top view—On-screen Display (OSD) buttons and LEDs ....................4 Rear view ..................................5 Bottom view..................................7 ..............................8 EMOTE ONTROL ARTS ..........................
  • Page 7 ERVICED HDMI Q & A………………………………………………………………………………………………………………43 SPECIFICATIONS................................44 ................................. 44 PECIFICATIONS ........................45 ROJECTION ISTANCE VS ROJECTION HDP2300 Series Projection Distance and Size Table ....................45 HDP2300 S ..........................46 ERIES IMING ABLE ..............................49 ROJECTOR IMENSIONS REGULATORY COMPLIANCE ............................. 50 FCC W ..................................

  • Page 8: Getting Started

    HDP2300 Users Manual ETTING TARTED Packing Checklist Carefully unpack the projector and check that the following items are included: HDP2300 SERIES P ROJECTOR WITH LENS CAP EMOTE CONTROL VGA CABLE OMPONENT CABLE OWER CORD (WITH TWO AA BATTERIES) HDMI CD-ROM...

  • Page 9: Views Of Projector Parts

    HDP2300 Users Manual Views of Projector Parts HDP2300 Series Front-right View ABEL ESCRIPTION EE PAGE IR receiver Receives IR signal from remote control Lens Projection Lens Focus ring Focuses the projected image Zoom ring Enlarges the projected image Height adjuster Adjusts level of projector See Top view—On-screen Display (OSD) buttons...
  • Page 10 HDP2300 Users Manual ABEL ESCRIPTION EE PAGE Horizontal lens shift Adjusts the image position horizontally Lens release button Press the release button before removing the lens Important: Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp cool.

  • Page 11: Top View-On-Screen Display (Osd) Buttons And Leds

    HDP2300 Users Manual Top view—On-screen Display (OSD) buttons and LEDs ABEL ESCRIPTION PAGE MENU Opens and exits OSD menus ▲ (Up cursor) / Navigates and changes settings in the OSD Keystone+ Quick Menu – For Keystone ENTER Enter or confirm highlighted OSD menu item...

  • Page 12: Rear View

    HDP2300 Users Manual Rear view ABEL ESCRIPTION EE PAGE VIDEO Connect the composite cable from a video device YPbPr Connect a component video enabled device HDMI 1/ 2/ 3 Connect the HDMI CABLE from a HDMI device Connect the USB cable from a computer...
  • Page 13 Connects the S-Video cable from a video device AC IN Connects the power cable Power switch Turns on/off the projector Security chain lock Helps protect the HDP2300 from unauthorized use Secures to permanent object with a Kensington® Lock Kensington Lock system – 6 –...

  • Page 14: Bottom View

    HDP2300 Users Manual Bottom view ABEL ESCRIPTION EE PAGE Tilt adjustor Rotate adjuster lever to adjust angle position. Ceiling support holes Contact your dealer for information on mounting the projector on a ceiling Note: When installing, ensure that you use only UL Listed ceiling mounts.

  • Page 15: Remote Control Parts

    HDP2300 Users Manual Remote Control Functions Important: 1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluo- rescent lights can disrupt remote control operation. 2. Be sure nothing obstructs the path between the remote control and the projector. If the path be- tween the remote control and the projector is obstructed, you can bounce the signal off certain reflective surfaces such as projector screens.
  • Page 16 Turns on or off the remote control backlight for about 10 seconds. Pressing any LIGHT other key while the backlight is on keeps the backlight on for a further 10 sec- onds. VOL - Adjusts volume ( HDP2300 without Audio Function) VOL + MUTE Mutes the built-in speaker CONTRAST...

  • Page 17: Remote Control Operating Range

    HDP2300 Users Manual Remote Control Operating Range The remote control uses infrared transmission to control the projector. It is not necessary to point the remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or the rear of the projector, the remote will function well within a radius of about 7 meters (23 feet) and 15 degrees above or below the projector level.

  • Page 18: Setup And Operation

    ETUP AND PERATION Inserting the Remote Control Batteries Remove the battery compartment cover by sliding the cover in the direction of the arrow. Insert the battery with the positive side facing up. Replace the cover. Caution: 1. Only use AA batteries (Alkaline batteries are recommended). 2.

  • Page 19: Connecting Input Devices

    HDP2300 Users Manual Connecting Input Devices A PC or notebook computer and video devices can be connected to the projector at the same time. Video devices include DVD, VCD, and VHS players, as well as movie camcorders and digital still cameras.

  • Page 20: Installing Or Removing The Optional Lens

    HDP2300 Users Manual Installing or Removing the Optional Lens Caution: Do not shake or place excessive pressure on the projector or the lens components as the projec- tor and lens components contain precision parts. Before removing or installing the lens, be sure to turn off the projector, wait until the cooling fans stop, and turn off the main power switch.

  • Page 21: Installing The New Lens

    HDP2300 Users Manual Installing the New Lens Align the notches and correctly position the electrical contact pad as shown in the picture. Note: Pin of IRIS should be in the direction as shown in the picture. Rotate the lens clockwise until you feel it click into place.

  • Page 22: Starting And Shutting Down The Projector

    HDP2300 Users Manual Starting and Shutting down the Projector Starting the projector Remove the lens cap. Securely connect the power cord and signal cable. When connected, the power led will turn red. Turn on the lamp by pressing “ ”...

  • Page 23: Shutting Down The Projector

    HDP2300 Users Manual Turn on your source that you want to display on the screen (computer, note- book, video player, etc). The projector will detect the source automatically and will display on the screen. If not, push menu button and go to “SYSTEM SETUP: Basic”.

  • Page 24: Adjusting The Projector Level

    HDP2300 Users Manual Adjusting the Projector Level Take note of the following when setting up the projector: • The projector table or stand should be level and sturdy. • Position the projector so that it is perpendicular to the screen.

  • Page 25: Adjusting Projected Image Position Using Shift

    HDP2300 Users Manual Adjusting Projected Image Position Using Shift The Shift feature provides a lens shift function that can be used to adjust the position of the projected image either horizontally or vertically within the range detailed below. Shift is a unique system that provides lens shift while maintaining a much higher ANSI contrast ratio than traditional lens shift systems.

  • Page 26: Adjusting The Horizontal Image Position

    HDP2300 Users Manual Adjusting the horizontal image position With the lens in the center position the horizontal image position can be adjusted to the left or right by up to a maximum of 10% of the half image width. Note that the maximum horizontal image height ad- justment can be limited by the vertical image position.

  • Page 27: Adjusting The Zoom Ring, Focus And Keystone

    HDP2300 Users Manual Adjusting the Zoom ring, Focus and Keystone Use the Image-zoom control (on the projector only) to resize the pro- jected image and screen size. Use the Image-focus control (on the projector only) to sharpen the pro- jected image.

  • Page 28: On-Screen Display (Osd) Menu Settings

    (OSD) M CREEN ISPLAY ETTINGS OSD Menu Controls The projector has an OSD that lets you make image adjustments and change various settings. Navigating the OSD You can use the remote control cursor buttons or the buttons on the top of the projector to navigate and make changes to the OSD.

  • Page 29: Setting The Osd Language

    HDP2300 Users Manual Setting the OSD Language Set the OSD language to your preference before continuing. 1. Press the MENU button. Press the cursor ◄► button to navigate to SYSTEM SETUP: Basic. 2. Press the cursor ▲▼ button until Language is highlighted.

  • Page 30: Osd Menu Overview

    HDP2300 Users Manual OSD Menu Overview Use the following illustration to quickly find a setting or determine the range for a setting. – 23 –...

  • Page 31: Picture: Basic Menu

    HDP2300 Users Manual PICTURE: Basic Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the PICTURE: Basic menu. Press the cursor ▲▼ button to move up and down in the PICTURE: Basic menu.

  • Page 32: Picture: Advanced Menu

    HDP2300 Users Manual PICTURE: Advanced Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the PICTURE: Advanced menu. Press the cursor ▲▼ button to move up and down in the PICTURE: Advanced menu. Press ◄► to change values for settings.

  • Page 33: Hsg Adjustment

    HDP2300 Users Manual HSG Adjustment Press the ENTER button to enter the HSG Adjustment sub menu. ESCRIPTION Press the ◄► buttons to set the Primary Color. Primary Color Notes: There are six sets (R/ G/ B/ C/ M/ Y) of colors to be customized.

  • Page 34: Display Menu

    HDP2300 Users Manual DISPLAY Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the DISPLAY menu. Press the cursor ▲▼ button to move up and down in the DISPLAY menu. Press ◄► to change values for settings.

  • Page 35: Pc Detail Adjustment

    HDP2300 Users Manual PC Detail Adjustment Press the ENTER button to enter the PC Detail Adjustment sub menu. Note: Customizing the settings in PC Detail Adjustment menu is only available when PC input source (analog RGB) is selected. ESCRIPTION Press the ENTER/AUTO button on the control panel or the ENTER/AUTO button on the Auto remote control to automatically adjust frequency, phase, and position.

  • Page 36: System Setup: Basic Menu

    HDP2300 Users Manual SYSTEM SETUP: Basic Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the SYSTEM SETUP: Basic menu. Press the cursor ▲▼ button to move up and down in the SYSTEM SETUP: Basic menu.

  • Page 37: Menu Settings

    HDP2300 Users Manual Menu Settings Press the ENTER button to enter the Menu Settings sub menu. ESCRIPTION Press the ◄► buttons to select from five OSD locations: Menu Position Top-Left/ Top-Right/ Center/ Bottom-Left/ Bottom-Right. Press the ◄► buttons to set the Menu Display timer before the OSD times out.

  • Page 38: System Setup: Advanced Menu

    HDP2300 Users Manual SYSTEM SETUP: Advanced Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the SYSTEM SETUP: Advanced menu. Press the cursor ▲▼ button to move up and down in the SYSTEM SETUP: Advanced menu.

  • Page 39: Lamp

    HDP2300 Users Manual Lamp Press the ENTER button to enter the Lamp sub menu. ESCRIPTION Lamp Mode Press the ◄► buttons to adjust lamp brightness. Reset Lamp Timer Press the ENTER button to reset the Lamp Hour after the lamp is replaced.

  • Page 40: Closed Caption

    HDP2300 Users Manual Closed Caption Press the ENTER button to enter the Closed Caption sub menu. ESCRIPTION Closed Caption Enable Press the ◄► buttons to turn on or off Closed Caption. Caption Version Press the ◄► buttons to select the Caption Version.

  • Page 41: Information Menu

    HDP2300 Users Manual INFORMATION Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the INFORMATION Menu. ESCRIPTION Source Displays the activated input source. Resolution Displays the native resolution of input source.

  • Page 42: Maintenance And Security

    AINTENANCE AND ECURITY Replacing the Projection Lamp The projection lamp should be replaced when it burns out. It should only be replaced with a certified replacement part, which you can order from your local dealer. Important: a. The projection lamp used in this product contains a small amount of mercury. b.
  • Page 43 HDP2300 Users Manual Use a screwdriver to remove the screws from the lamp module. Pull out the lamp module. Reverse steps 1 to 7 to install the new lamp module. While installing, align the lamp module with the connector and ensure it is level to avoid damage.

  • Page 44: Cleaning The Projector

    HDP2300 Users Manual Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: 1. Be sure to turn off and unplug the projector at least 30 minutes before cleaning. Failure to do so could result in a severe burn.

  • Page 45: Using The Physical Lock

    Kensington, 2853 Campus Drive, San Mateo, CA 94403, U.S.A. Tel: 800-535-4242, http://www.Kensington.com. Using the Security Chain Lock In addition to the password protection function and the Kensington lock, the Security Chain Opening helps protect the HDP2300 from unauthorized use. See the following picture. – 38 –...

  • Page 46: Troubleshooting

    ROUBLE SHOOTING Common problems and solutions These guidelines provide tips to deal with problems you may encounter while using the projector. If the problem remains unsolved, contact your dealer for assistance. Often after time spent troubleshooting, the problem is traced to something as simple as a loose con- nection.

  • Page 47: Led Error Messages

    HDP2300 Users Manual LED Error Messages OWER EADY RROR ESSAGES LINK LINK LINK Lamp Ready Start Cooling FLASHING Over temperature Thermal Break Sensor error Lamp End of lamp life detected Burner Fan error Lamp Fan error Power Fan error DMD Fan error...

  • Page 48: Image Problems

    HDP2300 Users Manual Image Problems Problem: No image appears on the screen 1. Verify the settings on your notebook or desktop PC. 2. Turn off all equipment and power up again in the correct order. Problem: The image is blurred 1.

  • Page 49: Remote Control Problems

    HDP2300 Users Manual Remote Control Problems Problem: The projector does not respond to the remote control 1. Direct the remote control towards remote sensor on the projector. 2. Ensure the path between remote and sensor is not obstructed. 3. Turn off any fluorescent lights in the room.

  • Page 50: Hdmi Q & A

    HDP2300 Users Manual HDMI Q & A Q. What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI cable? Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or High- Speed cables. ․Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal.

  • Page 51: Specifications

    PECIFICATIO NS Specifi cations Model HDP2300 Series Display type TI DLP DMD 0.65” 1920 x 1080 Native Resolution 8.8 kg (19 lbs) Weight Lens type Standard Long Short Projection distance 1.5 meters ~ 7 meters 2.meters ~ 20 meters 0.5 meters ~ 3 meters 31.2"...

  • Page 52: Projection Distance Vs. Projection Size

    HDP2300 Users Manual Projection Distance vs. Projection Size HDP2300 Series Projection Distance and Size Table Standard projection lens: TR: 1.54 ~ 1.93 Distance (m) 1.28 3.42 4.27 8.55 1.36 2.73 3.41 10.23 Diagonal (“) Keystone Correction 9.93 9.93 9.93 9.93 12.39...

  • Page 53: Hdp2300 Series Timing Mode Table

    HDP2300 Users Manual HDP2300 Series Timing Mode Table The projector can display several resolutions. The following table outlines the resolutions that can be displayed by the projector. HDMI OMPOSITE IGNAL ESOLUTION OMPONENT / S-V IDEO ANALOG DIGITAL 640 x 350 31.5...
  • Page 54 HDP2300 Users Manual HDMI OMPOSITE IGNAL ESOLUTION OMPONENT / S-V IDEO ANALOG DIGITAL 640 x 480 37.9 72.8 — — 800 x 600 35.2 56.3 — — 800 x 600 37.9 60.3 — — VESA 800 x 600 46.9 75.0 —...
  • Page 55 — — O: Frequency supported —: Frequency not supported The native resolution of the panel for the HDP2300 series is 1920 x 1080. Resolution other than native resolution may display with uneven size of text or lines. – 48 –...

  • Page 56: Projector Dimensions

    HDP2300 Users Manual Projector Dimensions – 49 –...

  • Page 57: Regulatory Compliance

    EGULATORY OMPLIANCE FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device pur- suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communica- tions.
