  • Page 1 HDO1850 Installation and user manual v1.0...
  • Page 2 Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. © Copyright 2014 Disclaimer The information in this document is subject to change without notice.
  • Page 3 Important Safety Information Important: It is strongly recommended that you read this section carefully before using the projector. These safety and usage instructions will ensure that you enjoy many years of safe use of the projector. Keep this manual for future reference. Symbols Used Warning symbols are used on the unit and in this manual to alert you of hazardous situations.
  • Page 4 Projector Installation Notice  Place the projector in a horizontal position The tilt angle of the projector should not exceed 15 degrees, nor should the projector be installed in any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically, and may lead to other unpredictable damages.
  • Page 5 Verify Installation Location  To supply power, the 3-blade (with earthing lead) socket should be used to ensure proper grounding and equalized ground potential for all of the equipment in the Projector System.  The power code provided with the Projector should be used. In case of any missing item, other qualified 3-blade (with earthing lead) power cord can be used as substitution;...
  • Page 6 Power Safety  Only use the supplied power cord.  Do not place anything on the power cord. Place the power cord where it will not be in the way of foot traffic.  Remove the batteries from the remote control when storing or not in use for a prolonged period. Replacing the Lamp Replacing the lamp can be hazardous if done incorrectly.
  • Page 7 Main Features  Lightweight unit, easy to pack away and transport.  Compatible with all major video standards including NTSC, PAL, and SECAM.  A high brightness rating allows for presentations in daylight or in lit rooms.  Supports resolutions up to UXGA at 16.7 million colors to deliver crisp, clear images. ...

  • Page 8: Table Of Contents

    Table of Contents GETTING STARTED ................................1 ................................1 ACKING HECKLIST ............................... 2 IEWS OF ROJECTOR ARTS Front-right View ................................2 Top view—On-screen Display (OSD) buttons and LEDs ..................3 Rear view ..................................4 Bottom view ................................... 6 ..............................7 EMOTE ONTROL ARTS...
  • Page 9 SPECIFICATIONS ................................57 ................................. 57 PECIFICATIONS (DH912)..................... 58 ROJECTION ISTANCE VS ROJECTION Projection Distance and Size Table ......................... 58 (DH913)..................... 59 ROJECTION ISTANCE VS ROJECTION Projection Distance and Size Table ......................... 59 ................................ 60 IMING ABLE ..............................62 ROJECTOR IMENSIONS REGULATORY COMPLIANCE ............................

  • Page 10: Getting Started

    ETTING TARTED Packing Checklist Carefully unpack the projector and check that the following items are included: DLP P ROJECTOR WITH EMOTE CONTROL CABLE OWER CORD AAA B WITH ATTERIES CD-ROM ARRYING CASE UICK TART UIDE ARRANTY ’ S MANUAL Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work. It is recommend that you keep the original packing material should you ever need to return the equipment for warranty service.

  • Page 11: Views Of Projector Parts

    Views of Projector Parts Front-right View ABEL ESCRIPTION EE PAGE IR receiver Receive IR signal from remote control Lens Projection Lens Focus ring Focuses the projected image Zoom ring Enlarges the projected image See Top view—On-screen Display (OSD) buttons Function keys and LEDs.

  • Page 12: Top View-On-Screen Display (Osd) Buttons And Leds

    Top view—On-screen Display (OSD) buttons and LEDs ABEL ESCRIPTION EE PAGE MENU Opens and exits OSD menus Navigates in the OSD Quick Menu – For Keystone SOURCE Enter the Source menu Navigates and changes settings in the OSD Enter or confirm highlighted OSD menu item AUTO Optimizes image size, position, and resolution Navigates and changes settings in the OSD...

  • Page 13: Rear View

    Rear view 3 4 5 6 7 8 ABEL ESCRIPTION EE PAGE AC IN Connect the POWER cable VGA IN 2 Connect the RGB cable from a computer VGA IN 1 Connect the RGB cable from a computer Connect the USB cable from a computer (USB) VGA OUT Connect the RGB cable to a display...
  • Page 14 Note:  To use this feature, you must plug in the connector before turn on/off the projector.  Screen controllers are supplied and supported by screen manufacturers.  Do not use this jack for anything other than intended use. Note: If your video equipment has both S-VIDEO and RCA jacks (composite video) connect to the S-VIDEO connector.

  • Page 15: Bottom View

    Bottom view ABEL ESCRIPTION EE PAGE Contact your dealer for information on mounting the projector on a Ceiling support holes ceiling Tilt adjustor Rotate adjuster lever to adjust angle position. Note: When installing, ensure that you use only UL Listed ceiling mounts. For ceiling installations, use approved mounting hardware and M4 screws with a maximum screw depth of 12 mm (0.47 inch).

  • Page 16: Remote Control Parts

    Remote Control Parts Important: 1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluorescent lights can disrupt remote control operation. 2. Be sure nothing obstructs the path between the remote control and the projector. If the path between the remote control and the projector is obstructed, you can bounce the signal off certain reflective surfaces such as projector screens.
  • Page 17 ABEL ESCRIPTION EE PAGE Turns the projector off Toggles the input sources for display between PC sources Video/S-Video Toggles the input sources for display between Video and S-Video Navigates and changes settings in the OSD or MHL mode Keystone correction. Goes back to previous OSD menu, exits and saves menu settings EXIT Goes back to previous page or exit programs in MHL mode...

  • Page 18: Remote Control Operating Range

    ABEL ESCRIPTION EE PAGE HDMI Toggles the input sources for display between HDMI sources Turns the projector on Caution: Use of controls, adjustments or performance of procedures other than those specified herein may result in hazardous laser light exposure. Note: Controlling your smart device with the remote control When the projector projects the contents from your MHL compatible smart device, you can use the remote control to control your smart device.

  • Page 19: Inserting The Remote Control Batteries

    Inserting the Remote Control Batteries Remove the battery compartment cover by sliding the cover in the direction of the arrow. Insert the battery with the positive side facing up. Replace the cover. Caution: 1. Only use AAA batteries (Alkaline batteries are recommended). 2.

  • Page 20: Setup And Operation

    ETUP AND PERATION Starting and Shutting down the Projector Connect the power cord to the projector. Connect the other end to a wall outlet. POWER LED on the projector light. Turn on the connected devices. Ensure the POWER LED not a flashing.
  • Page 21 When the “Power Off? /Press Power again” message appears, press the POWER button. The projector turns off. Caution: 1. Be sure to remove the lens cap before starting projector. 2. Do not unplug the power cord until the POWER LED stops flashing–indicating the projector has cooled down.

  • Page 22: Setting An Access Password (Security Lock)

    Setting an Access Password (Security Lock) You can use the four (arrow) buttons to set a password and prevent unauthorized use of the projector. When enabled, the password must be entered after you power on the projector. (See Navigating the on page Setting the OSD Language on page...
  • Page 23 You can use the cursor buttons ▲▼◄► either on keypad or IR remote control for password entry. You can use any combination including the same arrow five times, but not less than five. Press the cursor buttons in any order to set the password.

  • Page 24: Adjusting The Projector Level

    Adjusting the Projector Level Take note of the following when setting up the projector:  The projector table or stand should be level and sturdy.  Position the projector so that it is perpendicular to the screen.  Ensure the cables are in a safe location. You could trip over them. To adjust the angle of the picture, turn the tilt-adjuster right or left until the desired angle has been achieved.

  • Page 25: Adjusting The Zoom, Focus And Keystone

    Adjusting the Zoom, Focus and Keystone Use the Image-zoom control (on the projector only) to resize the projected image and screen size Use the Image-focus control (on the projector only) to sharpen the projected image Use the KEYSTONE buttons (on the projector or the remote control) to correct image-trapezoid (wider...

  • Page 26: On-Screen Display (Osd) Menu Settings

    (OSD) M CREEN ISPLAY ETTINGS OSD Menu Controls The projector has an OSD that lets you make image adjustments and change various settings. Navigating the OSD You can use the remote control cursor buttons to navigate and make changes to the OSD. 1.

  • Page 27: Setting The Osd Language

    Setting the OSD Language Set the OSD language to your preference before continuing. 1. Press the MENU button. Press the cursor ◄► button to navigate to Settings 1. Press the cursor ▲▼ button to move to the Advanced 1 menu. (Enter) / ►...

  • Page 28: Osd Menu Overview

    OSD Menu Overview Use the following illustration to quickly find a setting or determine the range for a setting. Main Menu Sub Menu Settings Image Display Mode Presentation, Bright, Game, Movie, TV, sRGB, Blackboard, User Brightness 0~100 Contrast 0~100 Computer Horizontal Position -5~5 (depend on Autolock) Vertical Position...
  • Page 29 Main Menu Sub Menu Settings Settings 1 Source Source reference Input Source Select (IR/Keypad) Projection Normal, Real, Ceiling, Real+Ceiling Aspect Ratio Fill, 4:3, 16:9, Letter Box, Native, 2.35:1 Keystone -40~40 Digital Zoom -10~10 Audio Volume 0~10 Mute Off, On Advanced 1 Language English, Français, Deutsch, Español, Português, 簡体中文, 繁體中文, Italiano,...
  • Page 30 Main Menu Sub Menu Settings Settings 2 Auto Source Off, On No Signal 0~180 Power Off Auto Power Off, On Lamp Mode ECO , Normal, Dynamic ECO Reset All Status Active Source Video Information Lamp Hours(ECO, Normal, Dynamic ECO) Serial Number Software Version Advanced 1 Menu Position...

  • Page 31: Image Menu

    Image Menu Attention ! All of display mode parameters when changed will be saved to user mode. Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Image Menu. Press the cursor ▲▼ button to move up and down in the Image menu. Press ◄► to enter and change values for settings.

  • Page 32: Computer Menu

    Computer Menu Press the MENU button to open the OSD menu. Press ◄► to move to the Image menu. Press ▲▼ to move to the Computer menu and then press Enter or ►. Press ▲▼ to move up and down in the Computer menu.

  • Page 33: Advanced Feature

    Advanced Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the Advanced menu and then press Enter or ►. Press ▼▲ to move up and down in the Advanced menu.

  • Page 34: Color Manager

    Color Manager Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the Color Manager menu and then press Enter or ►. Press ▼▲ to move up and down in the Color Manager menu.

  • Page 35: Settings 1 Menu

    Settings 1 Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Settings 1 menu. Press the cursor ▲▼ button to move up and down in the Settings 1 menu. Press ◄►...

  • Page 36: Audio

    Audio Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▼▲ to move to the Audio menu and then press Enter or ►. Press ▼▲ to move up and down in the Audio menu.

  • Page 37: Advanced 1 Feature

    Advanced 1 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▲▼ to move to the Advanced 1 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 1 menu.
  • Page 38 3D Setting ESCRIPTION Press the cursor ◄► button to enter and select different 3D mode. Press the cursor ◄► button to enter and enable or disable 3D Sync Invert. 3D Sync Invert Press the cursor ◄► button to enter and enable or disable different 3D Format. 3D Format Note: 1.

  • Page 39: Advanced 2 Feature

    Advanced 2 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▲▼ to move to the Advanced 2 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 2 menu.

  • Page 40: Settings 2 Menu

    Settings 2 Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Settings 2 menu. Press the cursor ▲▼ button to move up and down in the Settings 2 menu. ESCRIPTION Press the cursor ◄►...

  • Page 41: Status

    Status Press the cursor ▲▼ button to move up and down in the Settings 2 menu. Select the Status menu and press Enter or ► to enter. ESCRIPTION Active Source Display the activated source. Displays resolution/video information for RGB source and color standard for Video Video Information source.

  • Page 42: Advanced 1 Feature

    Advanced 1 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 2 menu. Press ▲▼ to move to the Advanced 1 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 1 menu.
  • Page 43 Lamp Hour Reset Please refer to Resetting the Lamp on page to reset the lamp hour counter. Network ESCRIPTION Network State Displays the network connection status. Press ◄► to turn DHCP On or Off. DHCP Note: If you select DHCP Off, complete the IP Address, Subnet Mask, Gateway, and DNS fields.
  • Page 44 LAN_RJ45 Wired LAN Terminal functionalites Remote control and monitoring of a projector from a PC (or Laptop) via wired LAN is also possible. Compatibility with Crestron / AMX (Device Discovery) / Extron control boxes enables not only collective projector management on a network but also management from a control panel on a PC (or Laptop) browser screen.
  • Page 45 LAN_RJ45 1. Connect an RJ45 cable to RJ45 ports on the projector and the PC (Laptop). 2. On the PC (Laptop), select Start Control Panel Network and Internet. — 36 —...
  • Page 46 3. Right-click on Local Area Connection, and select Properties. 4. In the Properties window, select the Networking tab, and select Internet Protocol (TCP/IP). 5. Click Properties. 6. Click Use the following IP address and fill in the IP address and Subnet mask, then click OK. –...
  • Page 47 7. Press the Menu button on the projector. 8. Select Settings2 Advanced1 Network 9. After getting into Network, input the following: DHCP: Off IP Address: 10.10.10.10 Subnet Mask: 255.255.255.0 Gateway: 0.0.0.0 DNS Server: 0.0.0.0 10. Press to confirm settings. (Enter) / Open a web browser (for example, Microsoft Internet Explorer with Adobe Flash Player 9.0 or higher).
  • Page 48 ATEGORY NPUT ENGTH IP Address Crestron Control IP ID Port Projector Name Projector Location Assigned To DHCP (Enabled) (N/A) IP Address Network Configuration Subnet Mask Default Gateway DNS Server Enabled (N/A) User Password New Password Confirm Enabled (N/A) Admin Password New Password Confirm For more information, please visit http://www.crestron.com.
  • Page 49 Preparing Email Alerts 1. Make sure that user can access the homepage of LAN RJ45 function by web browser (for ex- ample, Microsoft Internet Explorer v6.01/v8.0). 2. From the Homepage of LAN/RJ45, click Alert Settings. 3. By default, these input boxes in Alert Settings are blank. —...
  • Page 50 4. For Sending alert mail, input the following: SMTP field is the mail server for sending out email (SMTP protocol). This is a required field. To eld is the recipient’s email address (for example, the projector administrator). This is a required field.
  • Page 51 RS232 by Telnet Function Besides projector connected to RS232 interface with “Hyper-Terminal” communication by dedicated RS232 command control, there is alternative RS232 command control way, so called “RS232 by TELNET” for LAN/RJ45 interface. Quick Start-Guide for “RS232 by TELNET” Check and get the IP-Address on OSD of the projector. Make sure that laptop/PC can access the web-page of the projector.
  • Page 52 Input the command format like the below: telnet ttt.xxx.yyy.zzz 23 (“Enter” key pressed) (ttt.xxx.yyy.zzz: IP-Address of the projector) If Telnet-Connection ready, and user can have RS232 command input, then “Enter” key pressed, the RS232 command will be workable. How to have TELNET enabled in Windows VISTA / 7 By default installation for Windows VISTA, “TELNET”...
  • Page 53 Select “Turn Windows features on or off” to open Have “Telnet Client” option checked, then press “OK” button. Specsheet for “RS232 by TELNET” : 1. Telnet: TCP 2. Telnet port: 23 (for more detail, kindly please get contact with the service agent or team) 3.

  • Page 54: Advanced 2 Feature

    Advanced 2 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 2 menu. Press ▲▼ to move to the Advanced 2 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 2 menu.
  • Page 55 Source Filter Press the ENTER button to enter the Source Filter sub menu. ESCRIPTION Press the cursor ◄► button to enter and enable or disable the HDMI1/ HDMI1/MHL MHL-compatible source. Press the cursor ◄► button to enter and enable or disable the HDMI2 source. HDMI2 Press the cursor ◄►...

  • Page 56: Maintenance And Security

    AINTENANCE AND ECURITY Replacing the Projection Lamp The projection lamp should be replaced when it burns out. It should only be replaced with a certified replacement part, which you can order from your local dealer. Important: a. The projection lamp used in this product contains a small amount of mercury. b.
  • Page 57 Remove the lamp compartment cover. Remove the three screws from the lamp module. Lift the module handle up. Pull firmly on the module handle to remove the lamp module. Reverse steps 1 to 5 to install the new lamp module. While installing, align the lamp module with the connector and ensure it is...

  • Page 58: Resetting The Lamp

    Resetting the Lamp After replacing the lamp, you should reset the lamp hour counter to zero. Refer to the following: Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Settings 2 menu. Press the cursor button to move down to Advanced 1 and press enter.

  • Page 59: Cleaning The Projector

    Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: 1. Be sure to turn off and unplug the projector about one hour before cleaning. Failure to do so could result in a severe burn. 2.

  • Page 60: Using The Kensington Lock & Using The Security Bar

    ® Using the Kensington Lock & Using the Security Bar ® Using the Kensington Lock If you are concerned about security, attach the projector to a permanent object with the Kensington slot and a security cable. Note: Contact your vendor for details on purchasing a suitable Kensington security cable. The security lock corresponds to Kensington’s MicroSaver Security System.

  • Page 61: Troubleshooting

    ROUBLESHOOTING Common problems and solutions These guidelines provide tips to deal with problems you may encounter while using the projector. If the problem remains unsolved, contact your dealer for assistance. Often after time spent troubleshooting, the problem is traced to something as simple as a loose connection.

  • Page 62: Led Error Messages

    LED Error Messages OWER RROR ESSAGES REEN Lamp Ready Start Flashing Cooling Flashing Over Temperature T1 error 3 blinks 1 blinks Thermal Break Sensor error 4 blinks G794 error 4 blinks 4 blinks Lamp fail 5 blinks Ballast temp over 5 blinks 1 blinks Ballast circuit short...

  • Page 63: Lamp Problems

    Problem: The image is blurred 1. Adjust the Focus on the projector. 2. Press the Auto button on the remote control. 3. Ensure the projector-to-screen distance is within the specified range. 4. Check that the projector lens is clean. Problem: The image is wider at the top or bottom (trapezoid effect) 1.

  • Page 64: Audio Problems

    Audio Problems Problem: There is no sound 1. Adjust the volume on the remote control. 2. Adjust the volume of the audio source. 3. Check the audio cable connection. 4. Test the source audio output with other speakers. 5. Have the projector serviced. Problem: The sound is distorted 1.

  • Page 65: Hdmi Q & A

    HDMI Q & A Q. What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI cable? Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or High- Speed cables. ˙Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal.

  • Page 66: Specifications

    PECIFICATIONS Specifications HDO1850 Model DH912 DH913 Display type TI DMD 0.65" 1080p Resolution 1080p 1920x1080 Projection distance 1m~ 10m (3.29ft ~ 32.8ft) 1.2m~10m (3.94ft~32.8ft) Projection screen size 23.5" ~ 300" 25.9”~324.97” Projection lens Manual Focus/Manual Zoom Zoom ratio 1.2x 1.5x...

  • Page 67: Projection Distance Vs. Projection Size (Dh912)

    Projection Distance vs. Projection Size (DH912) Projection Distance and Size Table Page intentionally left blank DH912 ROJECTION ROJECTION MAGE MAGE IDTH MAGE HEIGHT ISTANCE ISTANCE FFSET IAGONAL INCH INCH INCH INCH INCH 132.8 52.3 29.4 74.7 82.6 209.9 100.4 112.1 154.9 34.3 87.1...

  • Page 68: Projection Distance Vs. Projection Size (Dh913)

    Projection Distance vs. Projection Size (DH913) Projection Distance and Size Table DH913 HDO1850 ROJECTION ROJECTION MAGE MAGE IDTH MAGE EIGHT ISTANCE ISTANCE FFSET IAGONAL INCH INCH INCH INCH INCH 52.3 132.8 29.4 74.7 72.7 184.6 109.3 277.6 112.1 61.0 155.0 34.3...

  • Page 69: Timing Mode Table

    Timing Mode Table DP/HDMI OMPOSITE IGNAL ESOLUTION OMPONENT ( KH IDEO NALOG IGITAL ○ － － － － NTSC 15.734 ○ － － － － PAL/SECAM 15.625 ○ ○ － － 720 x 400 31.5 70.1 ○ ○ － － 720 x 400 37.9 85.04...
  • Page 70 DP/HDMI OMPOSITE IGNAL ESOLUTION OMPONENT ( KH IDEO NALOG IGITAL ○ ○ － － 1440 x 900 70.6 ○ ○ － － 1600 x1200 ○ ○ － － 1680 x 1050 64.7 59.9 ○ ○ － － 1680 x 1050 65.3 ○...

  • Page 71: Projector Dimensions

    Projector Dimensions — 62 —...

  • Page 72: Regulatory Compliance

    EGULATORY OMPLIANCE FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

  • Page 73: Rs-232C Protocol

    PPENDIX RS-232C Protocol RS232 Setting Baud rate: 9600 Parity None check: Data bit: Stop bit: Flow None Control Minimum delay for next command: 1ms Control Command Structure Header code Command code Data code End code Command Data ‘V’ ASCII Command Data Operation Command Note:...
  • Page 74 Command Group 01 Return ASCII Function Description Value VXXG0101 56h Xh Xh 47h 30h 31h 30h 31h 0Dh Get Brightness n=0~100 Pn/F VXXS0101n 56h Xh Xh 53h 30h 31h 30h 31h nh 0Dh Set Brightness n=0~100 VXXG0102 56h Xh Xh 47h 30h 31h 30h 32h 0Dh Get Contrast n=0~100 Pn/F...
  • Page 75 Command Group 02 Return ASCII Function Description Value VXXS0201 56h Xh Xh 53h 30h 32h 30h 31h 0Dh Select RGB VXXS0202 56h Xh Xh 53h 30h 32h 30h 32h 0Dh Select RGB2 VXXS0203 56h Xh Xh 53h 30h 32h 30h 33h 0Dh Select DVI VXXS0204 56h Xh Xh 53h 30h 32h 30h 34h 0Dh Select Video...
  • Page 76 Command Group 03 Return ASCII Function Description Value VXXS0305n 56h Xh Xh 53h 30h 33h 30h 35h nh 0Dh Volume n=0~10 VXXG0306 56h Xh Xh 47h 30h 33h 30h 36h 0Dh Treble n=0~16 Pn/F VXXS0306n 56h Xh Xh 53h 30h 33h 30h 36h nh 0Dh Treble n=0~16 VXXG0307 56h Xh Xh 47h 30h 33h 30h 37h 0Dh Bass...
  • Page 77 VXXS0358n 56h xh xh 53h 30h 33h 35h 38h nh 0Dh Control 2:Back IR turn on 3:Both IR turn off Knoll Systems 145 Tyee Drive. Point Roberts, WA 98281, USA 14-7163 Vantage Way, Delta BC, V4G1N1, Canada — 68 —...
