Grizzly H0625 Machine Data Sheet

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL H0625 OSCILLATING DRILL PRESS

Product Dimensions:

Weight................................................................................................................................................................ 49 lbs.
Length/Width/Height............................................................................................................................... 17 x 9 x 23 in.
Foot Print (Length/Width)................................................................................................................... 12-1/4 x 7-3/4 in.

Shipping Dimensions:

Type............................................................................................................................................................. Cardboard
Content............................................................................................................................................................ Machine
Weight................................................................................................................................................................ 54 lbs.
Length/Width/Height............................................................................................................................. 14 x 18 x 10 in.

Electrical:

Switch............................................................................................................. Paddle On/Off with Safety Lockout Key
Switch Voltage...................................................................................................................................................... 110V
Cord Length.......................................................................................................................................................... 10 ft.
Cord Gauge....................................................................................................................................................18 gauge
Minimum Circuit Size........................................................................................................................................ 10 amp
Plug Included.......................................................................................................................................................... Yes

Motors:

Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower..............................................................................................................................................1/2 HP
Voltage........................................................................................................................................................110V
Prewired......................................................................................................................................................110V
Phase........................................................................................................................................................ Single
Amps...............................................................................................................................................................5A
Speed.................................................................................................................................................1725 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ............................................................................................................................... V-Belt Drive
Bearings........................................................................................................ Shielded, Permanently Lubricated

Main Specifications:

Construction
Table Construction...................................................................................................Precision Ground Cast Iron
Spindle Housing Construction.............................................................................................................. Cast Iron
Column Construction............................................................................................................... Ground Cast Iron
Head Construction................................................................................................................................Cast Iron
Base Construction................................................................................................................................ Cast Iron
Paint.......................................................................................................................................................... Epoxy

Head Information

Head Swivel.......................................................................................................................................... 360 deg.
The information contained herein is deemed accurate as of 10/6/2008 and represents our most recent product specifications.
Model H0625
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
MACHINE DATA
SHEET
PAGE 1 OF 2
