Summary of Contents for Kramer TP-102HD
-
Page 1: User Manual
Kramer Electronics, Ltd. Preliminary USER MANUAL Model: TP-102HD XGA/HD Line Transmitter/DA... -
Page 2: Table Of Contents
Figure 3: Configuring a 1:2 XGA/HD to Twisted Pair Transmitter/Receiver/DA Figure 4: CAT 5 PINOUT Tables Table 1: TP-102HD XGA/HD Line Transmitter/DA Features Table 2: TP-102HD (Underside Panel) Features Table 3: CAT 5 PINOUT ... -
Page 3: Introduction
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products 2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com 3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com... -
Page 4: Quick Start
Step 2: Connect the power Step 3: Change the polarity - see section 4 You can change the polarity You can change the polarity of H and V Sync for video: of H and V Sync for video: KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 5: Overview
1 The terminology XGA is used throughout this manual, where this implies any RGBHV signal on an 15-pin HD connector having a resolution from VGA up to UXGA 2 The TP-102HD accepts high definition resolutions: 480p, 576p, 720p, 1080i, and 1080p 3 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com... -
Page 6: Shielded Twisted Pair (Stp)/Unshielded Twisted Pair (Utp)
We recommend that you use Shielded Twisted Pair (STP) cable. There are different levels of STP cable available, and we advise you to use the best quality STP cable that you can afford. Our non-skew-free cable, Kramer BC-STP is intended for analog signals where skewing is not an issue. For cases where there is skewing, our UTP skew-free cable, Kramer BC-XTP, may be used. -
Page 7: Figure 1: Tp-102Hd Xga/Hd Line Transmitter/Da
Your TP-102HD XGA/HD Line Transmitter/DA Figure 1: TP-102HD XGA/HD Line Transmitter/DA Table 1: TP-102HD XGA/HD Line Transmitter/DA Features Feature Function 12V DC +12V DC connector for powering the unit LINE OUT 2 RJ-45 Connector Connects to the LINE IN RJ-45 connector on the (second) -
Page 8: Figure 2: Tp-102Hd (Underside Panel)
Your TP-102HD XGA/HD Line Transmitter/DA Figure 2 Table 2 define the TP-102HD underside panel: Figure 2: TP-102HD (Underside Panel) Table 2: TP-102HD (Underside Panel) Features Feature Function VS Switch Slide the switch to the left (to NORMAL) to retain the polarity; slide the switch... -
Page 9: Configuring A 1:2 Xga/Hd-To-Twisted Pair Da System
XGA OUT 15-pin HD (F) connector of the second TP-120 unit to the XGA/HD acceptor (for example, display 2) 3. On each of the three Kramer TOOLS, connect the 12V DC power adapter to the power socket and connect the adapter to the mains electricity. -
Page 10: Figure 3: Configuring A 1:2 Xga/Hd To Twisted Pair Transmitter/Receiver/Da
Configuring a 1:2 XGA/HD-to-Twisted Pair DA System Figure 3: Configuring a 1:2 XGA/HD to Twisted Pair Transmitter/Receiver/DA KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 11: Wiring The Cat 5 Line In / Line Out Rj-45 Connectors
12cm x 7.15cm x 2.76cm (4.7" x 2.8" x 1.08"), W, D, H WEIGHT: 0.3kg (0.67lbs) approx. ACCESSORIES: RK-3T 19" rack adapter, power supply 1 For the TP-102HD Transmitter/TP-120 Receiver setup with 100m CAT 5 cable 2 Sufficient for feeding two receivers via CAT 5... - Page 12 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: 1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
- Page 13 For the latest information on our products and a list of Kramer distributors, visit our Web site: www.kramerelectronics.com, where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
