Kramer VP-400 Specifications

VP-400
1:4 VGA Distribution Amplifier
The Kramer
VP-400
provides correct buffering and isolation, and then distributes the signal to four identical outputs on high-density
15 pin D connectors. Unused outputs do not require special termination. Video bandwidth exceeding 345MHz
ensures that the
1
presentation systems requiring a local monitor and up to three projectors. A 12V power supply is included. The
is part of the Kramer TOOLS family of compact, high quality, and cost effective solutions for a variety
VP-400
of applications.

TECHNICAL SPECIFICATIONS

INPUT:
OUTPUTS:
VIDEO BANDWIDTH:
DIFF. GAIN:
DIFF. PHASE:
COUPLING:
K-FACTOR:
S/N RATIO:
POWER SOURCE:
DIMENSIONS:
WEIGHT:
ACCESSORIES:
OPTIONS:

TYPICAL APPLICATIONS

Any professional presentation system requiring multiple outputs from a single VGA source.
Can be used as a multi-channel video or component DA with BNC breakout cables.
Schools, churches, corporate applications.
Rental and staging.
1.70
PRODUCTS CATALOG 2004
is a high performance 1:4 distribution amplifier for VGA signals. It accepts one input,
remains transparent even for high-resolution VGA modes like XGA. It is ideal for
VP-400
Analog red, green, blue signals - 0.7 Vpp/75
4 analog red, green, blue signals - 0.7 Vpp/75
345MHz. -3dB.
0.06%.
0.13 Deg.
AC.
< 0.05%.
74dB.
12 VDC, 90 mA.
12cm x 7.5cm x 2.5cm (4.7" x 2.95" x 0.98", W, D, H.).
0.3 kg. (0.67 lbs.) approx.
Power supply, mounting bracket.
VA-50P power supply with six 12VDC outlets.RK-T1, RK-T3 rack adapters.
KRAMER: SIMPLE CREATIVE TECHNOLOGY
, H & V sync, TTL level, on an HD15F connector.
Ω
, H & V sync, TTL level, on HD15F connectors.
Ω
W W W . K R A M E R E L E C T R O N I C S . C O M
