Grizzly G5783 Instruction Sheet

EYE/EAR INJURY HAZARD!
Wear safety glasses and
hearing protection during
use of this tool!
Always disconnect tool from
air to prevent unexpected
operation during service!
DO NOT EXCEED 120 PSI!
Personal
occur.

Introduction

Drill in tight places with this
drill. Producing up to 1300 RPM, this angle drill
includes a ⁄ " Jacobs
3
8
large paddle switch also makes this drill easy to
use in any position. Requires 90 PSI of air pres-
sure with 7 CFM of compressor capacity.

Inventory

A. Angle Air Drill ............................................. 1
B. Chuck Key .................................................. 1
C. Hex Wrench 3mm ...................................... 1

Operation

Insert your drill bit up to
tighten with the chuck key. Change the drill direc-
tion by pushing the reverse valve into the body
then rotate to lock into position. Connect the drill
to your regulated air source. The hex wrench is
included for removing the screw (Ref #55) that
holds the chuck to the spindle.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
INJURY HAZARD!
injury could
⁄ " reversible angle
3
8
chuck and chuck key. The
®
⁄ " into the chuck and
3
8
COPYRIGHT © JUNE, 2006 BY GRIZZLY INDUSTRIAL, INC.
#PC8322 PRINTED IN TAIWAN
MODEL G5783
⁄ " REVERSIBLE
3
8
ANGLE AIR DRILL
INSTRUCTION SHEET
Figure 1. Model G5783.
Air drill MUST have 3-4 drops of air tool oil directly
dropped into the air fitting before each use as
shown in Figure 2. Keep the head gear lubricated
by pumping a small amount light grease into the
ball cap on the head.
Figure 2. Lubricating directly into air fitting.
If you need help with your new pneumatic tool,
call our Tech Support at: (570) 546-9663.
