Signal processing
Type
32-bit floating-point digital signal
processor(s)
Clock speed
200MHz
Maximum 1600 MIPS/1200MFLOPS
calculation
(6400MIPS/4800MFLOPS with DSP
option card)
Delay memory 16MByte/72s(Maximum)
(64MByte/288s(Maximum)
with DSP option card)
Audio latency 610us (analog in to analog out)
(860us with DSP option card)
Sampling rate
48kHz

Communication ports

LAN
10Base-T (RJ-45)
RS-232C
D-Sub 9 pin, male; DTE
RS-485
Phoenix/Euroblock 2-piece, 3-pin
Indicators
Status Power/Status/Ethernet/Serial
(RS232C + RS485)
Audio Signal (Present/Normal/Clip)
for each audio input and output

Expansion slots

Audio I/O 8 Slots (4 in ESP-88)
Control I/O
2 Slots (1 in ESP-88)
Max 16 inputs/16 outputs
DSP 1 Slot

Technical Specifications

Audio channels
Analog
Digital (AES3)
Mechanical
Dimensions
Weight
Electrical
Mains voltage
Power
consumption
Maximum power
consumption
Environmental
Operating
temperature
Humidity
9
32 max (all slots full)
64 (all slots full)
18.9" W x 3.5" H x 12.6" D
(482 mm x 88 mm x 320 mm)
11.5 lb
(5.3kg)
85-264VAC 50/60Hz with PFC
< 35VA
<70VA (at <35˚C ambient)
<50˚C at less than 35VA / <40˚C at
less than 70VA
80% relative humidity
(without condensation)
