Expansion cards

Three types of optional cards are available: DSP
expansion; GPIO; and Audio.
DSP expansion card
Daughter card for main DSP card. Increases per-
formance by 300%. One card can be added to an
ESP.
GPIO card
Fits in the available GPIO slot. Eight control inputs
and eight control outputs. One GPIO card can be
added to an ESP.
Audio Cards:
4x4 mic/line card
Occupies two audio slots. Four microphone or line
level inputs (software selectable), and four line level
outputs.
EDR line level output card
Occupies one audio slot. Four highest-quality, line
level outputs.
EDR line level input card
Occupies one audio slot. Four highest-quality, line
level inputs.
AES3 output card
Occupies one audio slot. Eight AES3 outputs (two
per output connector).
AES3 input card
Occupies one audio slot. Eight AES3 inputs (two
per input connector).
Four-channel mic/line input card PC041917
Occupies one audio slot and four microphone or
line-level inputs (software-selectable).
Four-channel SDR output card
Occupies one audio slot. Four line-level outputs.
Surround Sound Decoder
input card
Occupies one audio slot. One optical audio input
and one coaxial audio input
Modularity and Expansion
PC041769
PC041768
PC041915
PC041763
PC041764
PC041766
PC041765
PC041916
PC302210
6
Maximum expansion card configuration
The ESP-00 has eight available audio expansion slots
and two available GPIO slots.
4 ch input/output 4x28 8x24 12x20 16x16 20x12 24x8 28x4
4 ch input/4x4 I/O 20x12 24x12 20x8 24x8 24x4 28x8 32x4
EDR in/EDR out 4x28 8x24 12x20 16x16 20x12 24x8 28x4
AES-3 in/AES-3 out 8x56 16x48 24x40 36x36 40x24 48x16 56x8
AES-3 in/EDR out 8x28 16x24 24x20 36x16 40x12 48x8 56x4
EDR in/AES-3-out 4x56 8x48 12x40 16x32 20x24 24x16 28x8
Other configurations can be created by mixing SDR
and EDR cards which are not shown here.
