PPendIx

Technical Specifications

Integrated DSP
Signal Processor
Maximum Calculation
Delay
Audio Latency
A/D and D/A Converters
Sample Rate
Audio Performance Specifications
Frequency Response
THD+N
Channel Separation (Crosstalk)
Dynamic Range
Control Inputs
Inputs (Control)
Analog Input Voltage Range
Digital Input Voltage Range
Control Outputs
Outputs (Control)
Output Voltage
Indicators and Controls
LED Status Indicators
Audio Signal Indication
Electrical Specifications
Mains Voltage
AC Power Consumption
Mains Connector
Power Dissipation
Physical
Dimensions
Net Weight
Operating Temperature
Cooling System
General
PC Configuration Software
Network Control
Communication Ports
Expansion Slots
Audio Channel Capacity
English
ESP-880, ESP-1240, ESP-4120
32-bit fixed/floating-point DSP + ARM, 456 MHz
3.6 GIPS / 2.7 GFLOPS
860 μs (analog in to analog out)
20 Hz - 20 kHz (+0.3 dB/-0.1 dB)
0.002 % at +4 dBu (A-weighted/20 Hz – 20 kHz)
< -105 dB at +4 dBu input and output level, 1 kHz
> 115 dB, A-weighted 20 Hz – 20 kHz, analog input to analog output
5 analog or digital inputs, 2 kΩ internal pull-up resistor to 5 V, 3.81 mm Phoenix Contact
0 V to 3.3 V (maximum 5 V)
0 V to 3.3 V (threshold voltage = 1.6 V)
5 digital outputs, 3.81 mm Phoenix Contact
High: 8 V (open circuit), 2.5 V @ 10 mA
Low: < 1 V @ 100 mA, push-pull
Power/Status, Signal, Ethernet, Serial (RS-232 + CC-16)
Green (-60 to -25 dBFS), Yellow (-24 to -3 dBFS), Red (-2 dBFS to Clip)
85 VAC-264 VAC 50/60 Hz
< 15VA typical at 122 °F (50 °C) ambient
12 W (41 BTU, 10 kcal)
1.7" H x 19" W x 8.5" D (44 mm x 483 mm x 215 mm)
32 °F - 122 °F (0 °C - 50 °C)
ControlSpace
Ethernet (RJ-45), 100Mb
RS-232 (DB9M, DTE), Bose CC-16 (3.81 mm Phoenix Contact
1 control/audio network
56 (16 analog, 8 ESPLink out, 16x16 digital with expansion card)
43 s
24-bit
48 kHz
, 6-pin
®
IEC 60320-C14 (Inlet)
5.8 lb (2.6 kg)
Passive, side venting
Designer software
® ™
Appendix
, 6-pin
®
, 3-pin)
®
