User Manual for your Venini
VEO64SS
60 cm Fan Oven
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
JW 19/10/12
Advertisement
Table of Contents
Related Manuals for Venini VEO64SS
Summary of Contents for Venini VEO64SS
- Page 1 User Manual for your Venini VEO64SS 60 cm Fan Oven NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for you or any person not familiar with the operation of the appliance.
-
Page 3: Table Of Contents
Contents Environmental note Important safety information 5 - 7 Specifications 8 - 10 Product and aperture dimensions Product specifications Standard accessories Electrical details Cooling fan Control panel Using the oven 10-11 Selecting manual operation mode Setting the minute minder function Selecting a cooking function and temperature 11-15 Before first use... -
Page 4: Environmental Note
Environmental note o The packaging materials that Venini use s are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 5: Important Safety Information
MPORTANT SAFETY INFORMATION Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are u nsure of any of the information contained in this booklet, please contact... - Page 6 Safety o Venini strongly recommend that babies and young children are prevented from being near to the appliance and not allowed to touch the appliance at any time. o If it is necessary for younger family members to be in the kitchen, please ensure that they are kept under close supervision at all times.
- Page 7 nstallation This appliance must be correctly installed by a suitably qualified person, strictly in accordance with the manufacturer’s instructions. o The ma nufacturer declines any responsibility for injury or damage, to person or property, as a result of improper use or installation of this appliance.
-
Page 8: Specifications
pecifications Product Dimensions Aperture Dimensi Height: 590 mm 580 mm Width: 595 mm 560 mm Depth: 550 mm 550 mm (min) Product specifications o 4 oven functions o Energy efficiency class: A o Oven gross capacity: 59 litres o Gross net capacity: 50 litres o Minute minder o Cooling fan o Double-glazed removable door... -
Page 9: Electrical Details
Electrical details Rated Voltage: 20-240 Vac 50 Hz Supply Connection: Max Rated Inputs: 2.35 kW ains Supply Lead: 3 x 1.5mm² Oven Light Bulb: 25 W/300°C screw type pygmy Cooling fan o A tangential cooling fan is fitted inside of this app liance, to make the internal temperature of the o ven stable and the external... -
Page 10: Control Panel
ontrol Panel 1) Oven function selector knob 2) Minute minder / manual operation control knob 3) Thermostat control knob 4) Power indicator light 5) Oven operating light sing the oven Selecting manual operation mode Before you can select a cooking function or set a temperature, you must set the appl iance into manual operation mode. -
Page 11: Setting The Minute Minder Function
etting the minute minder function ou are able to set the minute minder at any time, regardless of hether an oven function has been selected. You can set a period of me using the minute minder function and an alarm will sound when is period of time has elapsed. -
Page 12: Selecting An Oven Function
o It is advisable for you not to remain in the room whilst the burning off process is taking place. You should leave the oven on the maximum setting for 30 – 40 minutes. o After the oven cavity has cooled, it should then be cleaned with warm soapy water, u sing either a sponge or soft cloth. -
Page 13: Thermostat Control Knob
Thermostat control knob o The oven thermostat control knob sets require temperature of the oven . It is possible regulate temperature within a range of 50 - 250°C. o Turn control knob clockwise. Oven operating light o This light will come on to indicate oven’s heating... -
Page 14: Warnings
o IMPORTANT: You should ALWAYS pre-heat the oven if you are baking. If there is no guidance given on the food packaging specifically for cooking in fan oven mode, you can generally reduce the cooking time and temperature by 10% from the information given for conventional oven cooking. -
Page 15: Shelf Positions
Shelf positions Your oven will come supplied with the following oven furniture: (A) Safety shelf (B) Enamelled baking tray o The numbers 1 – 4, indicat the different shelf positions t hat you can utilise within the oven. o You should use the shelf p sition(s) that you find are best suited to your personal cooking preferences. -
Page 16: Replacing The Oven Bulb
Any damage th at is caused to the appliance by a cleaning product will not be fixed by Venini free of charge, even if the appliance is within the guarantee period. Replacing the oven bulb... -
Page 17: Removing The Oven Door For Cleaning
Removing the oven door for cleaning o facilitate the cleaning of the insi de of the oven and the outer frame f the oven, the door ca n be removed as follows o The hinges (A) have two movable bolts on them (B). -
Page 18: Removing The Inner Door Glass For Cleaning
Removing the inner door glass for cleaning o Do not u se any abrasive cleaner that could cause damage. o Remember that if the surface of the glass panel beco mes scratched, this could lead to a dangerous failure. To facilitate cleaning, the inner door glass can be lifted out. o Unscrew the bracket latch that is in the corner of the top of the door. -
Page 19: Installation
NSTALLATION The installation must be carried out by a suitably qualified person, in accordance with the current version of the following. o AS/NZS 3000: 2007 Wiring Regulations o 2010 Electricity Safety Regulations Electrical connectio efore connecting the appliance, make sure that the supply voltage marked n the rating plate corresponds with your mains supply voltage. -
Page 20: Installing The Oven Into The Kitchen Cabinet
nstalling the oven into the kitchen cabinet Posit ioning the appliance Ensure that the aperture that you will be fitting the oven into is of the size given in the above diagram. The oven must be fitted into an oven housing with the ventilation cut-outs shown in the “Ventilation requirements”... -
Page 21: Ventilation Requirements
entilation requirements (Figure shows the ventilation and cut-out requiremen ts for the installatio n of the appliance into a standard kitchen unit). (Figure shows ventilatio n and cut- out requirements for e installation of the ppliance into a tall ousing unit). Ensure that the oven has been securely fixed into the housing unit. -
Page 22: My Appliance Isn't Working Correctly
My appliance isn’t working correctly o The oven isn’t coming on. * Check that you have select ed a cooking function and a cooking temperature. o There appears to be no po wer to the oven and grill. * Check that the appliance has been connected to the electrical mains supply correctly. - Page 23 I am getting condensation in my oven * Steam and c ondensation is a natural by product of cooking any food with high water content, such as frozen food, chicken etc. You may get condensation in the oven cavity and forming between the oven door glasses.
-
Page 24: Cooking Tables
Cooking tables Fan oven Pre-heat Cooking Food type Weight Shelf level Temperature time time 40-50 ° Beef 15 minutes minutes 70-80 ° Pork 1 kg 15 minutes minutes 50-60 ° Chicken 1.2 kg 15 minutes minutes 50-60 ° Duck 1.5 kg 15 minutes minutes 20-30... -
Page 28: Contact Details
Think Appliances Pty Ltd. 416-424 Barry Rd Coolaroo VIC 3048 Sales Telephone 1300 132 824 Service Telephone 1800 444 357 Website www.thinkappliances.com...
