American Standard Spectra Bathtub 2696.102 Installation Instructions

INSTALLATION INSTRUCTIONS

5-1/2' Cast Iron Bath
Model 2696.102
Model 2696.202
Thank you for selecting American Standard - the benchmark of fine quality for over 100 years. To ensure this product is installed properly, please read
these instructions carefully before you begin. (Certain installations may require professional help.) Also be sure your installation conforms to local codes.
CAUTION: RISK OF PERSONAL INJURY. CAST IRON BATHS ARE EXTREMELY HEAVY.
!
THIS IS A TWO PERSON INSTALLATION.
Recommended Tools & Materials
• Rule
• Level
• Square
1

REMOVE THE OLD BATH (IF APPLICABLE)

Disconnect the drain at the trap. Remove any
old wall material. Slip boards under the old
bath feet to protect the floor, and slide the
old bath out of the recess as illustrated.

PREPARE SUBFLOOR

Check the flooring under the bath area, and repair it if necessary. Make sure the subfloor is level.
FINISHED
WALL
18mm
11/16"
64mm
2-1/2"
DIA.
Fig. 2
SUPPORT
FEET
RIGHT HAND TUB IS REVERSED

DETERMINE FRAMING ROUGH-IN

Construct a recess using 2 x 4 construction designed for your particular installation.
Allow for thickness of finished wall material.
P r o d u c t n a m e s l i s t e d h e r e i n a r e t r a d e m a r k s o f A m e r i c a n S t a n d a r d I n c .
© A m e r i c a n S t a n d a r d I n c . 2 0 0 7
™
• Pliers
• Pipe Wrench
• Wood Working Tools
76mm
229 x 305mm
3"
9" X 12" HOLE
IN SUB FLOOR
FOR BELOW
FLOOR ROUGH
406mm
16"
ROUGH
FLOOR
LEFT HAND TUB ILLUSTRATED
Fig. 1
Old Bath
FINISHED
STD. 1-1/2
WALL
DRAIN OUTLET
32mm
1-1/4"
194mm
7-5/8"
FINISHED
WALL
1682mm
66-1/4"
-1-
• Plumbers Putty
• Silicone Sealant
• Metal Shims
• Wall Coverings, As Needed
Floor Protective
Material
73mm
2-7/8"
FINISHED
WALL
102mm
FINISHED
4"
WALL
740170-100 Rev. B
384mm
15-1/8"
813mm
32"
