SCALA OVAL 5-1/2' WHIRLPOOL & BATHING
POOL
2645.018 Whirlpool featuring System I
• Acrylic with fiberglass reinforcement
• Pre-leveled tub bottom
• Molded-in lumbar back rest
• Factory installed and tested whirlpool system
• 1.0 HP single speed, self-draining pump/
motor
• Factory-installed power cord with plug
• Six multi-directional color-coordinated
jets
• Deck-mounted air switch On/Off
• Two air volume controls
• Factory installed and tested whirlpool system
2645.018C Stay Clean™ Whirlpool Massage
Featuring System I:
• Same as 2645.018 except with the
StayClean™ whirlpool system featuring
Antimicrobial AlphaSan®
2645.002 Bathing Pool only
Nominal Dimensions: 1676 x 914 x 502mm
(66" x 36" x 19-3/4")
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
NOTE: Roughing-in dimensions and product
specifications shown on reverse side of page.
Revised 4/98
WHIRLPOOL & BATHING POOL
To Be Specified - Required:
Color:
Bath Filler: (specify finish)
Bath Drain: 1583.470 (specify finish)
To Be Specified - Optional:
5-1/2 Foot Acrylic Apron: 9366.018 (specify color)
5-1/2 Foot Apron: 9266.018 (specify color)
Jet Trim Ring Kit: 9860.200-two per kit
(Specify finish)
For color/finish availability and other faucet choices,
please see the Product Selector and Pricing Guide.
© 2003 American Standard Inc.
SCALA OVAL 5-1/2'™
HIGH GLOSS ACRYLIC
BV-30
Advertisement
Related Manuals for American Standard Scala Oval 2645.002
Summary of Contents for American Standard Scala Oval 2645.002
- Page 1 5-1/2 Foot Acrylic Apron: 9366.018 (specify color) 5-1/2 Foot Apron: 9266.018 (specify color) Jet Trim Ring Kit: 9860.200-two per kit (Specify finish) For color/finish availability and other faucet choices, please see the Product Selector and Pricing Guide. © 2003 American Standard Inc. HIGH GLOSS ACRYLIC BV-30...
- Page 2 BATHING WELL AT RIM WATER DEPTH TO OVERFLOW FLOOR LOADING 25.6 (PROJECTED AREA) 45.1 PTS. CUBE (FT 3 ) © 2003 American Standard Inc. SCALA OVAL 5-1/2’™ HIGH GLOSS ACRYLIC 302mm (11-7/8) 1676mm (66) RECOMMENDED FITTING LOCATION 64 X 330mm (2-1/2" x 13")
