EMPIRE
EMPIRE
Comfort Systems
Outdoor Gas Fireplace
!
DANGER
Installer:
Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
— Installation and service must be performed by a
qualified installer, service agency or the gas sup-
plier.
If the information in these instructions are not fol-
lowed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
Improper installation, adjustment, alteration, service
or maintenance can cause injury or property damage.
Read the installation, operating and maintenance
instructions thoroughly before installing or servicing
this equipment.
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
GAS-FIRED
WARNING
WARNING
OUTDOOR GAS FIREPLACE
OP36FP32M(N,P)-1
OP36FP72M(N,P)-1
OP42FP32M(N,P)-1
OP42FP72M(N,P)-1
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space
such as a camper, tent, car or home.
For Outdoor Use Only.
If not installed, operated and maintained in accordance
with the manufacturer's instructions, this product could
expose you to substances in fuel or from fuel combus-
tion which can cause death or serious illness.
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance
and immediately call your gas supplier or fire de-
partment.
Do not store or use gasoline or other flammable va-
pors and liquids in the vicinity of this or any other
appliance.
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
MODELS
WARNING
WARNING
WARNING
WARNING
Page 1
Advertisement
Table of Contents
Related Manuals for Empire Comfort Systems OP36FP32MN-1
Summary of Contents for Empire Comfort Systems OP36FP32MN-1
- Page 1 INSTALLATION INSTRUCTIONS EMPIRE EMPIRE AND OWNER'S MANUAL Comfort Systems Outdoor Gas Fireplace OUTDOOR GAS FIREPLACE MODELS OP36FP32M(N,P)-1 OP36FP72M(N,P)-1 OP42FP32M(N,P)-1 OP42FP72M(N,P)-1 GAS-FIRED CARBON MONOXIDE HAZARD DANGER This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE Important Safety Information ..................3 Safety Information for Users of LP-Gas ..............4 Introduction ......................5 - 6 Specifications ......................7 Gas Supply .......................7 Clearances .......................8 Combustible Materials ....................9 Fireplace Dimensions .....................10 Planning Installation ....................11 Fireplace Framing and Installation .................12 Operation Instrucitons / Flame Appearance ............13 OP(36,42)FP72 Lighting Instructions ..............14 OP(36,42)FP32 Lighting Instructions ..............15... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION • Installer: Please leave these instructions with the owner for • WARNING: Keep appliance area clear and free from future reference combustible materials, gasoline and other flammable vapors and liquids. • This unit complies with ANSI Z21.97/CSA 2.41 and CSA 4.96 U.S. for Outdoor Gas Fireplaces. •... -
Page 4: Safety Information For Users Of Lp-Gas
SAFETY INFORMATION FOR USERS OF LP-GAS Propane (LP-Gas) is a flammable gas which can cause fires with the members of your household. Someday when there and explosions. In its natural state, propane is odorless and may not be a minute to lose, everyone's safety will depend colorless. You may not know all the following safety precautions on knowing exactly what to do. -
Page 5: Introduction
1/4 in per foot. The fireplace can be shimmed level. When installed on surfaces where water may collect or cause damage: Empire Comfort Systems recommends a slope of 1/8 in to 1/4 in per foot towards the drain port suggested. The fireplace can be shimmed level. - Page 6 INTRODUCTION Enclosures for LP-gas supply cylinders shall be ventilated by • When the appliance is connected to a fixed piping system, openings at the level of the cylinder valve and at floor level. The the installation must conform with local codes, or in the ab- effectiveness of the opening(s) for purposes of ventilation shall sence of local codes with the National Fuel Gas Code, ANSI be determined with the LP-gas supply cylinder(s) in place.
-
Page 7: Specifications
SPECIFICATIONS Model OP36FP OP42FP Input Maximum 40,000 50,000 Minimum 36,000 LP / 38,000 NAT 36,000 LP / 38,000 NAT Orifice P245 #50 LP / P209 #31 NAT P300 #48 LP / P280 #29 NAT Accessories BD36SS 36" Bifold Glass Door - Stainless Steel BD42SS 42"... -
Page 8: Clearances
CLEARANCES Minimum Wall and Ceiling Clearances (Figure 2) Mantel Clearances Sidewall and Back Clearances: The clearance from the 12” inside of the fireplace to any combustible wall should not be 10” less than 2". MANTEL Ceiling Clearances: The ceiling height should not be less COMBUSTIBLES than 36"... -
Page 9: Combustible Materials
COMBUSTIBLE MATERIALS Do not attach combustible material to the mantel of your fireplace. No greeting cards, stockings or ornamentation of any type should be This is a fire hazard. placed on or attached to the fireplace. This is a heating appliance. The flow of heat can ignite combustibles. -
Page 10: Fireplace Dimensions
FIREPLACE DIMENSIONS DELUXE FLUSH REFERENCE LETTER OP36FP OP42FP 37 5/8" 37 5/8" 39 1/2" 43 1/2" 19 13/16" 19 13/16" 33" 37" 35" 35" 36" 40" 24 3/8" 24 3/8" 6 1/8" 6 1/8" 30 9/16" 30 9/16" 8 3/8" 8 3/8"... -
Page 11: Planning Installation
PLANNING INSTALLATION In planning the installation for the fireplace, it is necessary to Installing the Hood determine where the unit is to be installed and whether optional A stainless steel hood is furnished with each outdoor fireplace. The accessories are desired. Gas supply piping should also be planned hood MUST be installed before the fireplace is used. -
Page 12: Fireplace Framing And Installation
FIREPLACE FRAMING AND INSTALLATION 1. Place fireplace in framing opening. Fireplace framing can be built before or after the fireplace is set in 2. Using the four (4) nailing flanges provided with the fireplace, place. Framing should be positioned to accommodate wall covering attach two (2) flanges on each side. -
Page 13: Operation Instrucitons / Flame Appearance
OPERATION INSTRUCTIONS/FLAME APPEARANCE Flames from the pilot (rear right back side of the pan burner) as ANNUAL CLEANING/INSPECTION – Refer to parts diagram for well as the main flame should be visually checked as the log set location of items discussed below. is installed. -
Page 14: Op(36,42)Fp72 Lighting Instructions
OP(36,42)FP72 LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE. A. BEFORE LIGHTING, smell around the appliance area for B. -
Page 15: Op(36,42)Fp32 Lighting Instructions
OP(36,42)FP32 LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by C. Use only your hand to push in or turn the gas control hand. -
Page 16: Pilot And Main Burner Flame Characteristics
PILOT AND MAIN BURNER FLAME CHARACTERISTICS Pilot Flame Pattern Figure 10 shows a correct pilot flame pattern. The correct flame will be blue and will extend beyond the thermocouple/thermopile. The flame will surround the thermocouple/thermopile just below the tip. A slight yellow flame may occur where the pilot flame and main burner flame meet. -
Page 17: Wiring
WIRING Label all wires prior to disconnection when servicing controls. Wiring Remote Receiver errors can cause improper and dangerous operation. Verify proper Use the following steps to place the remote receiver adjacent to operation after servicing. the gas valve. Attention: The remote receiver bracket is not used in this Millivolt thermopile is self powered, gas valve does not require 110 installation. -
Page 18: Wiring
WIRING BROWN WHITE GREEN GAS CONTROL ORANGE VALVE POWER HI/LO PILOT Solenoid MAIN (GND) PILOT ELECTRONIC BLACK CONTROL MODULE ORANGE AF-4000 B/P ORANGE BROWN BLACK BLACK Page 18 27777-2-0212... -
Page 19: Remote Control Installation & Operation
REMOTE CONTROL INSTALLATION & OPERATION TWO-FUNCTION WIRELESS REMOTE CONTROL SYSTEM FOR ON/OFF-HI/LO OPERATION OF THE AF-4000 GAS CONTROL VALVE IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO NOT ATTEMPT TO OPERATE INTRODUCTION This remote control system was developed to provide a safe, reliable, and user-friendly remote control system for use with the AF-4000 gas control valve used with some gas heating appliances. -
Page 20: Maintenance
MAINTENANCE Keep the control compartment, logs and burner area surrounding the to lighting instructions located on the rating plate of the log set. logs clean by vacuuming or brushing area at least twice a year. Never obstruct the flow of the combustion and ventilation air. Keep THE LOGS CAN GET VERY HOT –... -
Page 21: Master Parts Distributor List
This list changes from time to time. For the current list, please click on the Master Parts button at www.empirecomfort.com. Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equipment repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc. Dey Distributing... -
Page 22: Parts List
PARTS LIST USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INjURY OR DEATH. PART No. Index Description OP36FP32 OP36FP72 OP42FP32 OP42FP72 17247 17247 17247 17247 Top Standoff 27781 27781 27782 27782 Firebox Front 10554 10554 10554 10554 Nailing Flange R10391... -
Page 23: Parts View
PARTS VIEW 22 28 21 20 27777-2-0212 Page 23... -
Page 24: Warranty Terms
WARRANTY TERMS Empire Comfort Systems Inc. warrants this hearth product to be free from defects at the time of manufacture and for the periods specified below. Hearth products must be installed by a qualified technician and must be maintained and operated safely, in accordance with the instructions in the owner’s manual.
