EMPIRE
EMPIRE
Comfort Systems
Premium Ventless Universal Fireboxes
For Outdoor Use Only.
If not installed, operated and maintained in accordance
with the manufacturer's instructions, this product could
expose you to substances in fuel or from fuel combus-
tion which can cause death or serious illness.
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance
and immediately call your gas supplier or fire de-
partment.
Do not store or use gasoline or other flammable va-
pors and liquids in the vicinity of this or any other
appliance.
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
WARNING
WARNING
WARNING
WARNING
OUTDOOR VENTLESS FIREBOX
OP32FB2MF-2
OP36FB2MF-2
OP42FB2MF-2
GAS-FIRED
Installer:
Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
— Installation and service must be performed by a
qualified installer, service agency or the gas sup-
plier.
If the information in these instructions are not fol-
lowed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
Improper installation, adjustment, alteration, service
or maintenance can cause injury or property damage.
Read the installation, operating and maintenance
instructions thoroughly before installing or servicing
this equipment.
WARNING
WARNING
Page 1
Advertisement
Table of Contents
Related Manuals for Empire Comfort Systems OP32FB2MF-2
Summary of Contents for Empire Comfort Systems OP32FB2MF-2
- Page 1 INSTALLATION INSTRUCTIONS EMPIRE EMPIRE AND OWNER'S MANUAL Comfort Systems Premium Ventless Universal Fireboxes OUTDOOR VENTLESS FIREBOX OP32FB2MF-2 OP36FB2MF-2 OP42FB2MF-2 GAS-FIRED WARNING For Outdoor Use Only. Installer: Leave this manual with the appliance. WARNING Consumer: Retain this manual for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE Important Safety Information ..................3 Introduction ......................4-5 Clearances .......................6 Combustible Materials ....................6 Outer Firebox Dimensions ..................7 Inner Firebox Dimensions ..................8 Planning Installation ....................9-10 Firebox Framing and Installation ...............10-11 Gas Line Connection ....................12 Master Parts Distributor List ...................13 How To Order Repair Parts ..................13 Parts List ........................14 Parts View ......................15... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION • Installer: Please leave these instructions with the owner for • WARNING: Keep appliance area clear and free from future reference combustible materials, gasoline and other flammable vapors and liquids. • This unit complies with ANSI Z21.97/CSA 2.41 and CSA 4.96 U.S. for Outdoor Gas Fireboxes. •... -
Page 4: Introduction
The firebox can be shimmed level. When installed on surfaces where water may collect or cause damage: Empire Comfort Systems recommends a slope of 1/8 in to 1/4 in per foot towards the drain port suggested. The firebox can be shimmed level. -
Page 5: Introduction
INTRODUCTION Enclosures for LP-gas supply cylinders shall be ventilated by • When the appliance is connected to a fixed piping system, openings at the level of the cylinder valve and at floor level. The the installation must conform with local codes, or in the ab- effectiveness of the opening(s) for purposes of ventilation shall sence of local codes with the National Fuel Gas Code, ANSI be determined with the LP-gas supply cylinder(s) in place. -
Page 6: Clearances
CLEARANCES Minimum Wall and Ceiling Clearances Mantel Clearances Sidewall and Back Clearances: The clearance from the inside of the firebox to any combustible wall should not be less than 2". Ceiling Clearances: The ceiling height should not be less than 36" from the top of the hood. Mantel Clearances: Ventless firebox models must use the hood supplied with the firebox. -
Page 7: Outer Firebox Dimensions
OUTER FIREBOX DIMENSIONS DIMENSIONS (in inches) INDEX OP32FB2MF OP36FB2MF OP42FBMF LETTER 39-7/8 41-7/8 41-7/8 36-5/8 41-5/8 43-1/8 17-1/16 19-1/4 19-1/4 28-1/4 32-1/4 36-1/4 32-7/8 34-7/8 34-7/8 22-1/4 6-1/8 6-3/8 6-3/8 28-3/8 30-3/8 30-3/8 8-3/4 8-3/8 8-3/8 5-7/16 5-1/4 5-1/4 33-1/4 37-5/8 39-5/8 66-7/16... -
Page 8: Inner Firebox Dimensions
INNER FIREBOX DIMENSIONS SIDE VIEW TOP VIEW INDEX LETTER OP32FB2MF OP36FB2MF OP42FBMF 29 1/8” 34 1/8” 38 1/8” 23 5/8” 27 5/8” 31 5/8” 12 7/8” 15 5/16” 15 5/16” 17 5/16” 18 3/4” 18 3/4” 20 9/16” 22 9/16” 22 9/16”... -
Page 9: Planning Installation
PLANNING INSTALLATION In planning the installation for the firebox, it is necessary to determine Installation must conform with one of the following conditions: where the unit is to be installed and whether optional accessories • With walls on all sides, but with no overhead cover; are desired. -
Page 10: Firebox Framing And Installation
PLANNING INSTALLATION Installing the Hood Cleaning Instructions a stainless steel hood is furnished with each outdoor firebox. The This appliance is built using mostly high-grade stainless steel to hood MUsT be installed before the firebox is used. Failure to do resist rust-through. - Page 11 FIREBOX FRAMING AND INSTALLATION Secure the non-combustible board to the middle bracket slide the firebox into position inside the metal studs. secure using two 10-16 flathead screws as shown in Figure 11. the firebox to the metal studs with four #10 pan-head screws as shown in Figure 9.
-
Page 12: Gas Line Connection
GAS LINE CONNECTION The firebox is designed to accept a 3/8-inch gas line for an approved ventless gas logset. Have the line installed by a qualified service person in accordance with all building codes. Consult local building codes to properly size the gas supply line leading to the 3/8-inch hook-up at the unit. -
Page 13: Master Parts Distributor List
This list changes from time to time. For the current list, please click on the Master Parts button at www.empirecomfort.com. Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equipment repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc. Dey Distributing Victor Division of F. -
Page 14: Parts List
PARTS LIST USE ONLY MANUFACTURER’S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INjURY OR DEATH. PART No. Index Description OP32FB2MF OP36FB2MF OP42FB2MF 23219 23219 23219 Top Standoff 28987 27781 27782 Firebox Front 32359 32359 32359 Mount Bracket R10387 R10391 R10391 Liner, Side - Left... -
Page 15: Parts View
PARTS VIEW 32273-0-0713 Page 15... -
Page 16: Warranty Terms
WARRANTY TERMS Empire Comfort Systems Inc. warranties this hearth product to be free from defects at the time of purchase and for the pe- riods specified below. Hearth products must be installed by a qualified technician and must be maintained and operated safely, in accordance with the instructions in the owner’s manual.
