- Page 1 4x 4.3” SD / HD Monitor. TLM-434H Instruction Manual www.datavideo-tek.com...
-
Page 2: Table Of Contents
Disclaimer of Product and Services The information offered in this instruction manual is intended as a guide only. At all times, Datavideo Technologies will try to give correct, complete and suitable information. However, Datavideo Technologies cannot exclude that some information in this manual, from time to time, may not be correct or may be incomplete. -
Page 3: Warnings And Precautions
7. This product should only be operated from the type of power source indicated on the marking label of the AC adapter. If you are not sure of the type of power available, consult your Datavideo dealer or your local power company. -
Page 4: Warranty
Certain parts with limited lifetime expectancy such as LCD Panels, DVD Drives, Hard Drives are only covered for the first 10,000 hours, or 1 year (whichever comes first). Any second year warranty claims must be made to your local Datavideo office or one of its authorized Distributors before the extended warranty expires. -
Page 5: Introduction
Introduction Built within a strong 19-inch rack mountable unit, this bank of both HD & SD 4.3-inch (16:9 and 4:3) high quality TFT LCD monitors are perfect for integration into many set ups. Each monitor has individual adjustments for contrast, brightness and colour saturation as well as LED tally light indication. -
Page 6: Connections & Controls
Connections & Controls Front Panel Power Switch Switches the power On / Off. 3.5 mm Stereo Phone Jack For stereo headphones. The headphone volume is controlled by the Audio Level button. N.B. Audio source from HDMI or SDI embedded audio. Source Button Select Input source between HD-SDI / SDI and HDMI. -
Page 7: Rear Panel
Pins 15 & 14 Powering On Connect the TLM-434H power supply to the DC In socket. Ensure the power cable is connected to a suitable mains socket. Switch the power On/Off switch to the ON position and all 4 panels will become active. -
Page 8: Menu Options
Menu Options The TLM-434H is a menu driven unit; there are 4 menus for each panel. These menus are used to initially set up the unit. The menu settings are non-volatile (settings are stored even when the unit is switched off). -
Page 9: Advance
- Press UP / DOWN button moving to the Time Code setting. - Press ENTER button to select the Time Code ON/OFF on the screen. - Press UP / DOWN button moving to the TC Position setting. - Press ENTER button to select the Time Code Position on the screen (Left/Up, Middle/Down, Right/Down, Right/Up) - Press UP / DOWN button moving to the TC Font Size setting. -
Page 10: Example Set Up
Example Set Ups... -
Page 11: Specifications
Specifications LCD Display 4 x 4.3” TFT LCD Resolution RGB 480 x 272 pixel Aspect Ratio 4:3 and 16:9 selectable Brightness 500 cd/m² (Luminance) Contrast Ratio Top: 40 deg / Bottom: 60 deg Left: 60 deg / Right: 60 deg View Angle When using available 2U 19'' rack mount this product can support the following adjustable view angle (Tilt 45 degree viewing angle) -
Page 12: Service And Support
It is our goal to make your products ownership a satisfying experience. Our support staff are available to assist you in setting up and operating your product. Please refer to our web site www.datavideo-tek.com for answers to common questions, support requests or contact your local office below.
