Summary of Contents for Broil King Q3X-1
- Page 1 Owner’s Manual For Models: Q3X-1 Q3XN-1 GAS-FIRED Page 1...
- Page 2 WARNING Broilmaster Gas Grills must ONLY use propane cylinders equipped with an Overfill Pro- tection Device (OPD). Use only a reputable propane dealer when exchanging or filling cylinders. An overfilled or improperly filled propane cylinder can be dangerous.
- Page 3 At Broilmaster, we continually strive to enhance the performance and quality of our products for your grilling enjoyment. Every effort will be made to ensure that Broilmaster continues to be your choice as the Premium grill of the future. Whether you are at the lake or in the privacy of your own backyard, the Broilmaster Premium Gas Grill performs far beyond the ordinary and is designed to provide your family with years of outdoor cooking pleasure.
-
Page 4: Parts Diagram
PARTS DIAGRAM Order repair parts through your local Broilmaster dealer. To locate a dealer in your area visit www.broil- master.com. Please provide the following information when placing a repair part order: Model Number, Purchase Date, Serial Number, Part Name, Part Number, and Quantity of parts needed. See Page 7 for parts ordering information. -
Page 5: Parts List
PARTS LIST PART NUMBER INDEX DESCRIPTION NUMBER Q3XN B100456 B100456 GRILL BODY TOP B101782 B101782 MOUNTING PLATE, HEAT INDICATOR B101736 B101736 HEAT INDICATOR B070486 B070486 LID HANDLE B073097 B073097 FOAM GRIP B101732 B101732 COOKING SCREEN (2 PIECES, STAINLESS STEEL) B101718 B101718 DRIP PAN (STAINLESS) B101747... -
Page 6: Hardware Package
HARDWARE PACKAGE WIRE, IGNITOR GROUND (QTY. 1) FOAM GRIP (QTY. 1) HEAT INDICATOR (QTY. 1) 10-24 SCREW, SS 1/4-20 NUT, SS (QTY. 3) (QTY. 1) KNOB, VALVE (QTY. 2) 5/32” PUSH NUT 1/4-20 SCREW W/ HOLE (QTY. 1) (QTY. 1) 10-24 SS KEPS NUT BRIDGE PIN AA BATTERY... -
Page 7: Master Parts Distributor List
MASTER PARTS DISTRIBUTOR LIST To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort.com. To provide warranty service, your dealer will need your name and address, model number, purchase date and serial number, and the nature of the problem with the unit. -
Page 8: Warranty Terms
WARRANTY TERMS Empire Comfort Systems Inc. warranties this Broilmaster premium gas grill to be free from defects at the time of purchase and for the periods specified below. Broilmaster Premium Gas Grills must be installed by a qualified technician and must be maintained and oper- ated safely, in accordance with the instructions in the owner’s manual. -
Page 9: Before You Begin
Follow all instructions unless noted to apply only to other grill: specific models. Do NOT use power tools. If you purchased an accessory with your Broilmaster, follow • Channel locks or pipe wrench the instructions provided with the accessory for assembly •... -
Page 10: Propane Gas Grills
PROPANE GAS GRILLS Grill Location Cylinder Requirements When choosing the ideal location for your Broilmaster Pre- mium Gas Grill, remember this grill is designed for outdoor use ONLY. Your Broilmaster Premium Gas Grill requires a standard twenty (20) pound propane gas cylinder. -
Page 11: Connection Requirements
Your propane gas cylinder is filled by weight, and should never exceed eighty percent (80%) of its All Broilmaster pressure regulators and hose assemblies weight limit. If the cylinder is not completely empty, the gas require Propane cylinders with a Type 1 connection device dealer must make necessary adjustments to ensure it is not as illustrated. - Page 12 The pressure regulator’s fitting must remain clean and free of nicks and scratches. A dirty, nicked or scratched fitting can cause a gas leak, resulting in an explosion or fire. Use only genuine Broilmaster replacement parts unless otherwise speci- fied by the manufacturer.
-
Page 13: Natural Gas Grills
Grill Location Broilmaster grills are not equipped with pressure regulators. When choosing the ideal location for your Broilmaster Pre- Your gas grill operates at a manifold pressure of seven (7") mium Gas Grill, remember this grill is designed for outdoor inches water column. -
Page 14: Grill Assembly
GRILL ASSEMBLY Install Heat Shield To ease installation remove grill body top from grill body bot- tom by removing the two hinge pins and clips. Attach shield by inserting the shield over the studs. See Figure 7. Figure 7 Figure 4 Install Control Panel Attach control panel assembly to grill bottom with two (2) 10-24 keps nuts. -
Page 15: Ignitor Wire
GRILL ASSEMBLY Heat Shield / Wind Shield Ignitor Wire Place the heat and wind shield in the grill bottom. Note: Install the Ignitor Ground Wire before installing the burner. See Figure 9. Connect the ground wire to the ground lug on the collector box . - Page 16 GRILL ASSEMBLY Install the Burner 5. Slide the bridge pin through the hole in the 1/4-20 x 1 1/2 Phillips Truss Head Screw as shown in Figure 14. 1. Insert the burner assembly into the grill bottom with the venturi tubes facing the front of the grill. See Figure 12. 2.
- Page 17 GRILL ASSEMBLY Smoker Drawer Reinstall Grill Body Top to Grill 1. Attach drawer support bracket to inside front of grill body Body Bottom with (1) 10-24 x 3/4” machine screw and 10-24 nut. See 1. Secure grill body top to grill body bottom by replacing Figure 16.
- Page 18 GRILL ASSEMBLY Handle Install Heat Indicator For your added comfort a foam grip has been provided. See 1. Insert heat indictor probe through the hole in the grill body Figure 20. lid and slide on push nut to secure. See Figure 22. Tip: For ease of installation, slightly lubricate the front handle with liquid soap before pushing the foam grip into place.
- Page 19 GRILL ASSEMBLY Assemble Drain Pan Install the Drain Pan Assembly Note: Drain pipe and valve coponents are packed inside 1. Lower the drain pan into the lower casting with the drain the smoker box. pipe on the right side. Pass the pipe through the oval 1.
-
Page 20: Air Shutter Adjustment
OPERATION - PROPANE & NATURAL GAS GRILLS Checking for Gas Leaks Lighting Instructions Check for gas leaks every time you connect your Broilmaster Using the Ignitor propane gas grill to a Propane gas cylinder, when a con- Caution: If a burner fails to light after 5 seconds, turn... -
Page 21: Operation
OPERATION Electrical Accessories Before Cooking If an electrical accessory is used on your grill, the accessory Before cooking on a grill for the first time, burn off any must be electrically grounded in accordance with local codes manufacturing process oil residue. or, in the absence of local codes, with the National Electric Code, ANSI/NFPA 70. -
Page 22: Grids/Drip Pan
MAINTENANCE Bucket Cleaning the Grill Caution: To prevent injury, use care when cleaning a The bucket can be stored under the grill lid when the grill is hot grill. not in use. Note: Do not use a commercial cleaner on the cooking Venturi Tubes grid. -
Page 23: Troubleshooting
TROUBLESHOOTING Although the manufacturer has attempted to ensure that your grill will operate properly and satisfactorily, sometimes problems do arise. The following troubleshooting guide lists several possible problems and their probable cause and solution. Problem Cause Solution Burner will not light. Out of gas Refill LP gas cylinder. -
Page 24: Cooking Tips
COOKING TIPS Cook Food To Proper Temperatures Cooking food safely requires that you raise the internal temperature of the meat high enough and for a long enough period of time to kill any food-borne bacteria that may cause illnesses. Color is not the best indicator that food is safe to eat. Use a high-quality probe thermometer to be sure your food is prop- erly cooked. - Page 25 COOKING TIPS Grilling Smoking 1. Place the cooking grids in the low position. The Qrave Grill is equipped with a front load smoker box. 2. Preheat your grill with both valve knobs set to High for 1. Soak your flavor smoking chips in water for about 15 15 minutes.
-
Page 26: Grill Maintenance History
GRILL MAINTENANCE HISTORY Date Maintenance Performed Page 26 B101748-1-0512... - Page 27 GRILL MAINTENANCE HISTORY Date Maintenance Performed B101748-1-0512 Page 27...
- Page 28 COOKING TIPS Your Broilmaster Premium Gas Grill is identified by model number, serial number, and gas type. This information is provided on a product identification label located on the grill’s control panel. For your convenience, complete this section for future reference when contacting your dealer.
