MultiModem rCell Intelligent Wireless Router
●
Enter the PC IP Address. Example: 192.168.2.x.
Note: The x in the address stands for numbers 101 and up.
●
Enter the PC Subnet Mask. Example: 255.255.255.0
●
Enter the PC Default Gateway. Example: 192.168.2.1
Note:
●
Select Use the following DNS server addresses.
●
●
●
Web Management Software Configuration
1. From the PC, open a Web Browser.
Type the default Gateway Address: http://192.168.2.1
2. Login
After entering the Address, the Login screen displays.
●
Type the default User name: admin (all lower-case).
●
Type the default password: admin (all lower-case).
User Name and Password Note:
are case-sensitive (both must be typed in lower-case). A password
can be up to 60 characters. If Windows displays the AutoComplete
screen, you may want to click No to tell the Windows OS not to
remember the password; this helps maintain PC security.
Click the Login button. The Web Management Home screen
displays.
3. Use the Setup Wizard for Quick Configuration
●
To begin configuration, click the Wizard Setup button located
under the menu bar.
●
After clicking the Wizard Setup button, the Wizard Setup screen
displays.
8
The PC settings must be in the same subnet range as
the router.
The factory default settings for the router are:
IP Address: 192.168.2.1
Subnet Mask: 255.255.255.0
●
Enter the IP Address for the Preferred DNS Server.
Example: 205.171.3.65
●
Click OK.
Close the Local Area Properties screen by clicking OK.
Close the Control Panel.
Repeat these steps for each PC on your network.
The User name and Password
Multi-Tech Systems, Inc. Quick Start Guide
