American Standard Ropetwist Bathing Pool 2722.102 LHO Installation Instructions

Installation Instructions
ROPE TWIST™ BATHING POOL
HIGH GLOSS ACRYLIC
SHOWN LESS ALL FITTINGS
MODELS: 2722.102 RHO
2722.202 LHO
USED WITH BATH WALLS: 5030.LBW
Thank you for selecting American-Standard...the benchmark of fine quality
for over 100 years. To ensure that your installation proceeds smoothly--please
read these instructions carefully before you begin.

BEFORE YOU BEGIN....

Local building codes vary by location. Observe all local plumbing and building codes.
Your new bath is shipped to you after careful inspection. All you need to finish the installation are your selected fittings.
To insure maximum performance and pleasure from this product, please follow the instructions and cautions.

GENERAL INSTALLATION INFORMATION ....

1. WHEN INSTALLING THE MATCHING ROPE TWIST BATH WALLS (MODEL 5030.LBW),
ADDITIONAL STUDS MAY BE REQUIRED. REFER TO THOSE INSTALLATION INSTRUCTIONS
PRIOR TO INSTALLING TUB.
2. ROPE TWIST SHOWER WALLS ARE TO BE INSTALLED OVER STUD WALLS.
3. BATH MAY ONLY BE INSTALLED IN A RECESS TYPE INSTALLAION.
4. THIS BATH IS NOT SELF-SUPPORTING AND MUST BE SUPPORTED ALONG ITS ENTIRE
BOTTOM WITH MORTAR OR GROUT. STRINGERS WILL HELP LEVEL TUB, BUT WILL NOT
PROVIDE ADEQUATE SUPPORT.
5. TAKE EXTRA CARE WHEN DRIVING NAILS OR SCREWS TO AVOID DAMAGING THE BATH.
TOOLS & MATERIALS REQUIRED....
TOOLS:
• Level
• Square
• Tape Measure
• Pipe Wrench
• Slip Joint Pliers
• Screw Driver
• Standard Woodworking Tools
• Personal Safety Equipment
• Caulking Gun
NOTE: Take extra care in handling surfaces of the bath. Use only non-abrasive cloths to avoid scratching.
FOR TOLL FREE INFORMATION AND ANSWERS TO YOUR QUESTIONS, CALL:
© AS America, Inc. 2008
All product names listed herein are trademarks
of AS America, Inc. unless otherwise noted.
MATERIALS:
• Nails
• Plumber's Putty
• Silicone Sealant
• 1 x 3 or 2 x 4 Stringers
• Drop Cloth
• Mortar Mix or Grout (1 bag)
HOTLINE FOR HELP
1 (800) 442-1902, in Canada call 1 (800) 387-0369.
Weekdays 8:00 a.m. to 4:00 p.m. Eastern time.
1
754049-100 Rev. G
