American Standard Whirlpool/Bathing Pool 2645 Series Installation Instructions

SCALA™ 5-1/2
HIGH GLOSS ACRYLIC
SHOWN LESS ALL FITTINGS
302mm
(11-7/8)
64 X 330mm (2-1/2" x 13")
914mm
(36)
419mm
(18)
44mm
(1-3/4)
C/L OF
210mm
DRAIN
(8-1/4)
INTEGRAL
FEET SUPPORT
1-1/2 N.P.T.M. THREADS
1-1/2 O.D. TAILPIECE
GENERAL SPECIFICATIONS FOR 2645 WHIRLPOOL
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
WHIRLPOOL MIN. OPERATING VOL.
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
3
CUBE (FT )
WHIRLPOOL ELECTRICAL SPECIFICATIONS
SYSTEM I PUMP
FOR AFTER-SALES SERVICE CALL 1 (800) 442-1902 WEEKDAYS.
750733-100 Rev. F
2645 SERIES
WHIRLPOOL/BATHING POOL

INSTALLATION INSTRUCTIONS

1676mm
RECOMMENDED FITTING LOCATION
HAND SHOWER
OUTLINE OF CUTOUT
LOCATION
1626mm X 864mm
51mm
(64 X 34)
(2)
229mm X 305mm
(9 X 12) CUTOUT
FOR DRAIN
LEVELING STRINGER
(NOT FOR SUPPORT)
102mm
(4)
464mm
(18-1/4)
44mm
(1-3/4)
457mm
(3-5/8)
66 x 36 x 19-3/4 In. (1676 x 914 x 502mm)
95 Lbs. (43 Kg.)
595 Lbs. (268 Kg.)
60 Gal. (227 L)
55 Gal. (208 L)
46 x 24 In. (1168 x 610mm)
62 X 31-1/2 In. (1575 x 800mm)
13-1/4 In. (337mm)
36 Lbs./Sq.Ft. (175 Kgs/Sq.m)
1.1 HP, 9.9 AMPS,120V.

THANK YOU...

for selecting an American Standard bath. Your new
bath is shipped to you after careful inspection. The
(66)
whirlpool version is completely assembled with pump,
6mm
motor, and system piping. All you need to finish the
(1/4)
TYP. installation are your selected fittings and electrical
connections for a whirlpool.
25mm (1)
TYP.
To insure maximum performance and pleasure from
this product, please follow the instructions and
ON/OFF
SWITCH
cautions.
List of Optional Components (not included):
• Apron Kit*
PUMP
* see your American Standard Distributor
List of Required Components (not included):
• Drain 1583.470*
* see your American Standard Distributor
List of Required Tools and Supplies:
PROVIDE ACCESS Tools
TO PUMP FOR
• Level
SERVICING ON ALL
INSTALLATIONS • Tape Measure
• Pipe Wrench
38mm
• Slip Joint Pliers
(1-1/2)
• Screw Driver
• Standard
• Personal Safety
502mm
(19-3/4)
• Caulking Gun
GENERAL INSTALLATION INFORMATION
Carefully uncrate and inspect your new bath for any
shipping damage. If such damage is found, report it to
your vendor immediately.
After inspection and during installation, protect the bath
from construction damage. After installation, and before
enclosing with wallboard, tile, etc., water test the unit
and check for leaks.
If a whirlpool, do not make modifications to the whirlpool
system or remove pump from factory mounting. This
could adversely affect the safety and performance of the
whirlpool and void the warranty. Do not handle or move
the whirlpool by the pump, motor, or piping system.
Fittings (bath filler, shower arm, etc.) are not provided
with the bath and must be ordered separately. Framing
and enclosing materials are provided by others. Check
25.6
for availability of optional American Standard wall tiling
45.1
bead (required for recess installations).
Protect all finished surfaces of the whirlpool during
construction and installation using a drop cloth.
WARNING! Do not lift whirlpool by the piping har-
ness at any time.
• Bath Filler*
Woodworking Tools
Equipment
© American Standard Inc. 2003
All product names listed herein are trademarks
of American Standard nc un ess otherwise noted
Supplies
• Nails
• Putty
• Caulking (waterproof)
• 1 x 3 or 2 x 2
Stringers
• Drop Cloth
• 15 amp
GFCI Outlet
• Cement, Plaster,
Grout
