American Standard Cadet Whirlpool and Bathing Pool 2774.002 Specification Sheet

CADET™ 6' X 42" WHIRLPOOL & BATHING
POOL
2774.018W Whirlpool featuring System I
• Acrylic with fiberglass reinforcement
• Pre-leveled tub bottom
• Form-fitted backrest position
• Dual, molded in arm rests
• 2.0 HP single speed, self-draining pump/motor
• Factory installed power cord with plug
• Eight multi-directional and flow-adjustable
jets including:
- Two Ideal-flow jets
- Four body massage jets
- Two recessed back-rest jets
• Deck-mounted air switch On/Off
• Two silent air volume controls
• Quick Connect Safe-T-Heater connection
system
• Factory installed and tested whirlpool system
2774.018WC Stay Clean™ Whirlpool Massage
Featuring System I:
• Same as 2774.018W except with the
StayClean™ whirlpool system featuring
Antimicrobial AlphaSan®
2774.002 Bathing Pool only
Nominal Dimensions: 1829 x 1067 x 502mm
(72" x 42" x 19-3/4")
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
NOTE: Roughing-in dimensions and product
specifications shown on reverse side of page.
Rev. 3/03
WHIRLPOOL & BATHING POOL
To Be Specified - Required:
Color:
Bath Filler: (specify finish)
Bath Drain: 1583.470 (specify finish)
To Be Specified - Optional:
Safe-T-Heater*: 9075.120
6 Foot Acrylic Apron: 9372.018 (specify color)
6 Foot Apron: 9272.018 (specify color)
Jet Trim Ring Kit: 9860.200-two per kit
(Specify finish)
Universal Tile Bead Kit: 751755-100
Grab Bar Kit: 9822.200-two per kit (specify finish)
For color/finish availability and other faucet choices,
please see the Product Selector and Pricing Guide.
* NOTE: the Safe-T-Heater is designed to maintain water
temperature during operation. It will not heat cold water to
desired bathing temperature.
© 2003 American Standard Inc.
CADET™ 6' X 42"
HIGH GLOSS ACRYLIC
BV-22
