American Standard Reminiscence 2908.018W Specifications

REMINISCENCE DROP-IN WHIRLPOOL &
BATHING POOL
❏
2908.018W Whirlpool featuring System I
• Acrylic with fiberglass reinforcement
• Pre-leveled tub bottom
• Sculptured rim design w/raised headrest
• Dual, molded-in arm rests
• Faucet deck/accessory area at drain end
• 1.5 HP single speed, self-draining pump/motor
• Factory installed power cord with plug
• Eight multi-directional and flow-adjustable jets
including:
- Two Ideal-flow jets at foot area
- Four body massage jets
- Two recessed back-rest jets
• Deck-mounted, air switch On/Off
• Two silent air volume controls
• Quick Connect Safe-T-Heater connection
system
• Factory installed and tested whirlpool system
❏
2908.018WC StayClean™ Whirlpool
Massage featuring System I
• Same as 2908.018W except with the
StayClean™ whirlpool system featuring
Antimicrobial AlphaSan®
❏
2908.028W Whirlpool featuring System II
Same as 2908.018W except:
• 2.0 HP, two speed, self-draining pump/motor
with pulse feature
• Deck-mounted electronic control with 20
minute built-in timed safety shut off and
Chrome bezel
❏
2908.028WC StayClean™ Whirlpool
Massage featuring System II
• Same as 2908.028W except with the
StayClean™ whirlpool system featuring
Antimicrobial AlphaSan®
❏
2908.002 Bathing Pool only
Nominal Dimensions: 66" x 36" x 24-1/4"
(1676 x 914 x 616mm)
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
Rev. 10/05
REMINISCENCE™ DROP-IN
WHIRLPOOL & BATHING POOL
To Be Specified - Required:
❏
Color:
❏
Bath Faucet (Specify finish)
❏
Bath Drain: 1583.470 (Specify finish)
To Be Specified - Optional:
❏
Safe-T-Heater*: 9075.120
❏
Jet Trim Ring Kit: 9860.200-two per kit (Specify finish)
for Body Massage Jets only
❏
System II Control Bezel: 9861.100 (Specify finish)
For color/finish availability and other faucet choices, please see
the Product Selector and Pricing Guide.
* NOTE: the Safe-T-Heater is designed to maintain water
temperature during operation. It will not heat cold water to desired
bathing temperature.
NOTE: Roughing-in dimensions and product
specifications shown on reverse side of page.
© 2005 American Standard Inc.
HIGH GLOSS ACRYLIC
BV-5
