American Standard Whirlpool and Bathing Pool 2732.002 Specification

RENAISSANCE™ WHIRLPOOL
AND BATHING POOL
Comfortable bathing design with form-fitted
backrest and molded-in armrests
❏ 2732.018 Whirlpool featuring System I
• Acrylic with fiberglass reinforcement
• Factory installed and tested whirlpool system
• 1.25 HP single speed, self-draining pump/motor
• Factory-installed power cord with plug
• Six multi-directional color-coordinated
jets including two in back rest area
• One color-coordinated air volume control
• Deck-mounted, color-coordinated air switch
On/Off control
• Dual, molded-in arm rests
❏
2732.002 Bathing Pool Only
Nominal Dimensions:
1524 x 832 x 502mm
(60" x 32-3/4" x 19-3/4")
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
SEE REVERSE FOR PRODUCT DIMENSIONS
AND SPECIFICATIONS
© 2008 AS America Inc.
RENAISSANCE™ WHIRLPOOL
AND BATHING POOL
To Be Specified - Required:
❏ Bath Filler: (specify finish)
❏ Bath Drain: 1583.470 (specify finish)
To Be Specified - Optional:
❏ 5 Foot Apron: 9260.018 (specify color)
❏ Universal Tile Bead Kit: 751755-100
❏ Grab Bar Kit: 9822.200-two per kit (specify finish)
For color/finish availability and other faucet choices, please
see the Product Selector and Pricing Guide.
H67
HIGH GLOSS
Revised 2/08
