American Standard Rope Twist Bathing Pool 2722W.102 Specifications

ROPE TWIST™ BATHING POOL
with INTEGRAL APRON
❏ 2722W.102 Bathing Pool, Right Hand Outlet
❏ 2722W.202 Bathing Pool, Left Hand Outlet
Product Features:
• Stylish rope-twist design feature
• Acrylic with fiberglass reinforcement
• Integral apron design
• Integral three-sided, tiling/water retention flange
• Generous back rest
• End drain outlet
• Design coordinated to match Rope Twist
bath walls (specify walls separately)
• 17" floor to deck tub depth
• High gloss surface finish
• Limited Lifetime warranty
Nominal Dimensions:
60" x 32" x 17"
(1524 x 813 x 432mm)
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
SEE REVERSE FOR ROUGHING-IN DIMENSIONS
AND PRODUCT SPECIFICATIONS
© 2008 AS America Inc.
To Be Specified - Required:
❏ Color: (Arctic only)
❏ Bath Filler*: (specify finish)
❏ Drain: 1640.305 (specify finish)
To Be Specified - Optional:
❏ Bath Walls: 5030W.LBW
For color/finish availability and other faucet choices, please
see the Product Selector and Pricing Guide.
Rope Twist Bath Walls with Rope Twist Bathing Pool Shown.
Specify Walls Separately.
H103
ROPE TWIST™
BATHING POOL
HIGH GLOSS ACRYLIC
Revised 10/08
