BATHS WITH INTEGRAL APRON
INSTALLATION AND
Models: 1713 Series Monarch
THANK YOU. . .
WE HAVE TAKEN GREAT PRIDE IN THE DESIGN AND CRAFTSMANSHIP OF YOUR
AMERICAN STANDARD AIR BATH. WE BELIEVE IT IS THE FINEST PRODUCT
AVAILABLE ANYWHERE.
AS A DISCRIMINATING PROFESSIONAL, YOU WILL UNDERSTAND THAT THE
QUALITY OF A PRODUCT ALWAYS INVOLVES PROPER INSTALLATION AND
UNDERSTANDING AS TO ITS USE. THIS PAMPHLET HAS BEEN CAREFULLY
PREPARED TO GUIDE YOU. PLEASE READ CAREFULLY AND CONTACT YOUR
DEALER IF YOU HAVE ANY QUESTIONS.
• IMMEDIATELY UPON RECEIPT, REMOVE BATH FROM THE PACKAGE CONTAINER
AND INSPECT FOR DAMAGE.
• MAKE SURE THE MODEL AND COLOR IS WHAT WAS ORDERED.
• DO NOT LIFT TUB BY PLUMBING AT ANY TIME.
• THE BATH MUST BE FULLY SUPPORTED ALONG BOTTOM – THE RIM OF THE TUB
IS NOT DESIGNED TO SUPPORT THE STRUCTURAL WEIGHT. FLOOR STRUCTURE
MUST BE CAPABLE OF SUPPORTING 50 LBS/SQF.
• TUB MUST BE PROPERLY LEVELED AT THE TOP TO ENSURE PROPER DRAINAGE.
• DO NOT SUPPORT BATH BY THE RIM. IF FINISHING MATERIAL IS TO OVERLAP OR
CONTACT TUB, THE ADDED WEIGHT MUST BE FULLY SELF-SUPPORTING.
© AS America, Inc. 2010
All product names listed herein are trademarks of AS America, Inc. unless otherwise noted.
SAVE THESE INSTRUCTIONS
1
754474-100 Rev. A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for American Standard 1713 Monarch Series
Summary of Contents for American Standard 1713 Monarch Series
- Page 1 Models: 1713 Series Monarch THANK YOU. . . WE HAVE TAKEN GREAT PRIDE IN THE DESIGN AND CRAFTSMANSHIP OF YOUR AMERICAN STANDARD AIR BATH. WE BELIEVE IT IS THE FINEST PRODUCT AVAILABLE ANYWHERE. AS A DISCRIMINATING PROFESSIONAL, YOU WILL UNDERSTAND THAT THE QUALITY OF A PRODUCT ALWAYS INVOLVES PROPER INSTALLATION AND UNDERSTANDING AS TO ITS USE.
- Page 2 IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS! WARNING: Risk of personal injury. Do not permit children to use this bathtub without adult supervision. WARNING: Risk of electric shock. Do not permit electrical appliances near any bathtub when bathtub contains water. WARNING: Risk of hyperthermia and possible drowning.
- Page 3 Rough-in Details ROUGH-IN CHART FOR BATH MODEL DIMENSIONS ACTUAL UNIT SIZE MODEL NUMBER WEIGHT HEIGHT LENGTH WIDTH 1713 60" 31" 15-1/2" 7-1/2" 21-3/4" 81 lbs. 23" 60" 33-3/4" 1524mm 787mm 394mm 190mm 552mm 37 Kg 584mm 1524mm 857mm Framing and installation Locate studs as required.
- Page 4 Electrical Consult a qualified electrician for the following hook-up. Failure to do this will affect your warranty. A separate 115 VAC 15 amp 60Hz service is required. Warning – When using electrical products, basic precaution should always be followed, including the following: 1.
- Page 5 Troubleshooting - Air System Always switch off power before servicing. The electronic control fails to operate: 1. Verify electric power supply. Reset circuit or replace fuse if necessary. 2. Verify all electrical connections (including keypad connection). 3. Verify that the Ground Fault Circuit Interrupter (G.F.C.I.) has not tripped. 4.
- Page 6 AS America, Inc. Limited Lifetime Warranty for Premium Acrylic Air Baths AS America, Inc. (”American Standard”) warrants to the original consumer purchaser that it will, at its option, repair or replace this whirlpool or any of its parts that are found by American Standard, in its sole judgment, to be defective under normal residential use and maintenance so long as it is owned by the original consumer purchaser.
