INSTALLATION GUIDE FOR
GREEN TEA™
GREEN TEA™
GREEN TEA™
GREEN TEA™
GREEN TEA™
TOWN SQUARE
TOWN SQUARE
ELLISSE
AIR MASSAGE SYSTEM

THANK YOU...

for selecting an American Standard bath. Your new bath is shipped to you after careful inspection. The Air
Massage System is completely assembled with air pump, motor, lights, and system piping. All you need to
finish the installation are your selected fittings and electrical connections for an Air Massage System.
To insure maximum performance and pleasure from this product, please follow the instructions and cautions.
FOR AFTER-SALES SERVICE CALL 1 (00) 44-10 WEEKDAYS.
© AS America, Inc. 00
All product names listed herein are trademarks
of AS America, Inc. unless otherwise noted.
5' x 36"
5-1/2' x 36"
6' x 36"
5' x 42"
6' x 42"
®
5' x 42"
®
6' x 42"
OVAL
1
MODEL 3571
MODEL 3572
MODEL 3573
MODEL 3574
MODEL 3575
MODEL 2748
MODEL 2742
MODEL 2709
754063-100 Rev. B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Green Tea Whirlpool and Bath Tubs 3572 and is the answer not in the manual?

Questions and answers

Summary of Contents for American Standard Green Tea Whirlpool and Bath Tubs 3572

  • Page 1: Thank You

    AIR MASSAGE SYSTEM THANK YOU... for selecting an American Standard bath. Your new bath is shipped to you after careful inspection. The Air Massage System is completely assembled with air pump, motor, lights, and system piping. All you need to finish the installation are your selected fittings and electrical connections for an Air Massage System.
  • Page 2 TABLE OF CONTENTS: Cover...Page 1 Table of Contents...Page  Safety Instructions Notice...Page 3 Roughing-in Reference...Page 4 - 6 Installation and Framing Instructions...Page 7 -  Supplied Drain Assembly and Installation Instructions...Page  - 13 Post Installation Instructions...Page 14 Remote Blower Location Option...Page 15 Warranty...Page 16 754063-100 Rev.
  • Page 3: Read And Follow All Instructions

    IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS! WARNING: Risk of personal injury. WARNING: Risk of electric shock. WARNING: Risk of hyperthermia and possible drowning. history should consult a physician before using this product. WARNING: Risk of personal injury. cause overflow and slippery conditions. Exercise caution when entering and exiting. WARNING: No Food or Alcoholic Beverages.
  • Page 4: Green Tea™ 5' X

    (146mm) 1-1/2" N.P.T. THREADS 3-1/8" 3/4" 1-1/2" O.D. TAILPIECE (79mm) (19mm) HOLE DRILLING LOCATION FOR AMERICAN STANDARD "TOWN SQUARE" DECK MOUNT BATH FILLER WITH PERSONAL SHOWER, MODEL #2555.901 ONLY 29-3/4 (755mm) DRAIN TO END OF TUB FOR SPOUT & VALVES...
  • Page 5: Green Tea™ 5-1/2' X

    GREEN TEA™ 5-1/2' x 36" MODEL 3572 AIR BATH TOP VIEW (1676mm) OUTLINE OF CUTOUT 64.5 x 34.5 (1638 x 876mm) BLOWER CUTOUT IN FLOOR FOR DRAIN PROVIDE ACCESS TO BLOWER FOR CONTROL SERVICE ON ALL INSTALLATIONS PANEL END VIEW C L TO OVERFLOW LEVELING STRINGER NOT 51mm...
  • Page 6: Town Square ® 6' X

    TOWN SQUARE MODEL 2748 AIR BATH GENERAL SPECIFICATIONS FOR 2748 AIR MASSAGE SYSTEM INSTALLED SIZE 59-1/2 x 41-5/8 x 23 In. (1511 x 1057 x 584mm) WEIGHT WEIGHT w/WATER GAL. TO OVERFLOW BATHING WELL AT SUMP BATHING WELL AT RIM WATER DEPTH TO OVERFLOW FLOOR LOADING (PROJECTED AREA)
  • Page 7: Model

    FRONT EDGE OF BATH MUST BE SUPPORTED BY STUD WALL OR ACCESS PANEL MUST BE LOCATED AMERICAN STANDARD ON THE SAME SIDE AS THE BLOWER. APRON KIT ALLOW OPEN FRAMING ON BLOWER END FOR SERVICE. UNLESS AN ACCESS OPENING OF AT LEAST 12" X 24" (305 X 610mm) IS PROVIDED, WARRANTY SERVICE WILL NOT BE PERFORMED.
  • Page 8: Electrical Installation Instructions

    ELECTRICAL INSTALLATION INSTRUCTIONS All wiring must be performed by a licensed electrician in accordance with the national electrical code and all other applicable codes. WARNING: When using electrical products, basic precautions should always be observed, including the following: 1. DANGER: RISK OF ELECTRIC SHOCK! Connect only to a circuit protected by a ground-fault circuit interrupter. 2.
  • Page 9: System Test

    UNDER DECK MOUNTING INSTRUCTIONS Please note that care must be taken to protect the surface of the tub during all aspects of the installation. Do not drill or cut the bath deck with the tub directly beneath it as damage to the tub may result. 1.
  • Page 10: Drain Connection

    DRAIN CONNECTION 1. Remove and identify all drain components as defined in air bath drain illustration. 2. Find 1" schedule 40 PVC pipe, see pipe chart, HORIZONTAL DRAIN PIPE. Mark as "horizontal pipe", drain to elbow section. 3. Find 1" schedule 40 PVC pipe, see pipe chart, VERTICAL DRAIN PIPE. Mark as "vertical pipe", drain to elbow section.
  • Page 11 DRAIN CONNECTION continued... 8. Have assistant take drain assembly from step 6 and place over back surface of drain hole to engage the metal strainer bolt. Secure plastic drain base to metal strainer in drain opening using nut driver shaft. DO NOT OVER TIGHTEN! Carefully remove excess silicone from acrylic surface as directed by silicone sealant directions.
  • Page 12 DRAIN CONNECTION continued... 12. Apply PVC cement to Horizontal Drain Pipe PVC and assemble to 0 degree elbow. 13. Dry fit Vertical Drain Pipe PVC into overflow assembly, then insert into elbow, WITHOUT PVC GLUE to align drain and overflow to bath. Mark overflow female coupling as shown in photo M. 14.
  • Page 13 DRAIN CONNECTION continued... 18. Tighten chrome overflow retainer onto drain overflow assembly pipe per photo Q below. 19. Align flat on drain actuator shaft with corresponding flat in chrome metal overflow escutcheon and tighten set screw to fix overflow escutcheon in place per photos R and S. 20.
  • Page 14 POST INSTALLATION CLEAN-UP Remove all construction debris from bath. Tile grout can be removed with a wooden popsicle stick or tongue depressor. Do not use wire brushes or any other metal implement on bath surface. Post installation clean-up generally can be completed using warm water and liquid dishwashing detergent. Stubborn dirt or stains may be removed using granular Spic and Span ®...
  • Page 15: Remote Blower Location Option

    REMOTE BLOWER LOCATION OPTION IMPORTANT! It is not necessary that the blower motor be relocated. This option is provided for the case that a particular installation makes this effort practical. NOTE: Relocating blower motor from factory installed location, see photo W, will require disassembly of air blower from mounting board.
  • Page 16: Warranty

    AS America, Inc. (”American Standard”) warrants to the original consumer purchaser that it will, at its option, repair or replace this whirlpool or any of its parts that are found by American Standard, in its sole judgment, to be defective under normal residential use and maintenance so long as it is owned by the original consumer purchaser.
