Furuno FCR-21x9 (with 19" LCD) Quick Manual

Antenna Unit
for FCR-2119/2129/2819/2829/2829W
XN-20AF
39 kg 86 lb
XN-24AF
42 kg 93 lb
XN-20AF: 2040 80.3"
XN-24AF: 2550 100.4"
4- 15
468 18.4" 300 11.8"
Monitor Unit
MU-231
MU-190 12.8 kg 28.2 lb
8.8 kg 19.4 lb
110 4.3"
450 17.7"
553 21.8"
489 19.3"
592 23.3"
448 17.6"
554 21.8"
4-Ø18
Cutout for ush mount
Cutout for ush mount
Control Unit
RCU-025 3.1 kg 6.84 lb
72 2.83" max.
32 1.26" 339 13.3"
10 to 20
0.39" to 0.79"
398 15.7"
55 2.17"
Processor Unit Switching Hub
EC-3000 HUB-100
426 16.77"
153 6.02"
14 kg 30.9 lb
15 0.59" 396 15.59"
150 5.9"
360 14.17"
3-ø8
Fixing hole
Sensor Adapter
Serial : MC-3000S Analog : MC-3010A
1.5 kg 3.3 lb
4-ø5 48 1.88"
220 8.66" 100 3.94"
Fixing
Hole 41 1.61" 60 2.36"
180 7.09"
4-ø5
Fixing
Hole
