Toyota VIP Owner's Manual

GBS OM 6/22/99 10:48 AM
2013- AVALON
AVALON
The GBS (G B
LASS REAKAGE
point monitoring performed by the TDS (Theft Deterrent System)–it "listens" for the noise made by
tapping on, or breaking of glass, and triggers alarms upon detection of these types of noise. Using
a microphone designed specifically for this task, the GBS is capable of ignoring other noises, which
helps prevent "false alarms" from occurring. (See reverse for descriptions of alarms.)
GLASS BREAKAGE SENSOR CHECK PROCEDURE
When the GBS was installed in your vehicle, care was taken to adjust the sensitivity level properly.
You may observe how it works following the procedure listed below.
090002-23410700
Page 1
TVIP V2
TVIP V2
GBS (G
LASS
D
esigned for
T D
HEFT eTERRENT
owner's guide
S ) provides protection for your vehicle above and beyond the entry
ENSOR
1 . Arm the theft deterrent system.
Press the lock button on the remote control or lock the doors with
the key. (Remember, the system will not arm if any door, or the trunk,
is open.)
Please note, your remote controls may look different than the one
pictured here.
2. Wait until the Security LED starts flashing.
The LED will begin to flash 30 seconds after the last door or the
trunk is closed.
Please note, your vehicle's Security LED may look different than the
one pictured here.
3. With the tip of a key, tap the center of the driver's door window.
Tap the glass with light to moderate force.
WARNING: Do not hit the glass with excessive force, especially in
cold weather, or you may crack or break it.
A W A A
ARN WAY LARM
If the A is not triggered, make sure you performed the
LARM
procedure correctly and try again. If the system did not perform as
you expected, contact your Toyota dealer for more information.
4. Disarm the theft deterrent system to stop the W
Press the unlock button on the remote control, or use the key to
unlock a door, to disarm the system.
Please note, your remote controls may look different than the one
pictured here.
GLASS BREAKAGE SENSOR (GBS)
B S
REAKAGE ENSOR
U y
se With our
S
ystem
should be triggered. (See reverse for details.)
OWNER'S GUIDE
GLASS BREAKAGE SENSOR (GBS)
OWNERS GUIDE
) E
NHANCEMENT
V
ehicle's
A A .
ARN WAY LARM
Rev. A 6/22/99
