Vehicle Security System
VSS 1
System Setting Guide - English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VSS 1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toyota VSS 1

Summary of Contents for Toyota VSS 1

  • Page 1 Vehicle Security System VSS 1 System Setting Guide - English...

  • Page 2: Dear Customer

    Dear Customer, You will find in this guide the information and operations necessary in order to – Confirm installation of the alarm system. – Activate/deactivate some features. – Diagnose the last 3 causes of alarm. If you need any information about the usage of the alarm system, please refer to the owner’s manual of the alarm system.

  • Page 3: Enter Programming Mode

    Programming mode This function allows to enable/disable various system options and to retrieve information from the system. To enter programming mode you have to follow the procedure below: • First you must enter the programming mode. • Then, you can select the function you want to edit by counting the number of times you close the door.
  • Page 4 3 Select the programming mode Within 30 sec, select the programming mode by performing the following number of door open/ close operations; (counting the number of closures). One: Buzzer ON/OFF (see paragraph .8) Two: Automatic doors lock ON/OFF (see paragraph .3) Three: Alarm memory confirmation (see paragraph .5) Four:...

  • Page 5: Diagnostic Mode

    Five: Additional car horn ON/OFF. 1) Open and close the door five times within 30s (LED will turn ON). Once: Horn OFF. Twice: Horn ON. ) Turn the key (IG OFF > ON > OFF). The LED will turn OFF and the hazard lamps turn ON the same number of times as the door open/close operations.

  • Page 6: Exit From Programming Mode

    Four. Installation confirmation. 1) Open and close the door four times within 30s (LED will turn ON) The system can confirm the correct installation. ) When an intrusion is detected, Alarm status light (LED) and hazard signals blink for detection time. 3) If any other alarm trigger is detected (opening door, boot, bonnet, additional sensor) The alarm status light (LED) and the siren buzzer will turn ON continuously while the trigger is present.

  • Page 7: Arm Without Intrusion Sensor

    7 Arm without intrusion sensor If you have to lock the car with somebody inside (passenger, children, dog, …), you must deactivate the Intrusion Sensor. Central Door Lock (Located on the driver’s door) Unlock Lock Activation steps Hazard light Alarm status Buzzer indication light (LED)

  • Page 8: Garage Mode

    8 Garage mode If you have to bring your car to your authorised retailer and do not want to provide the remote controlled key, you can deactivate the alarm system for a limited period of time. During garage mode, all the alarm system functions are inhibited. This mode has to be manually activated by following this procedure: 1.
  • Page 9 PZ???-?????-EU Publication no. ASM 000 009-0...
