- Page 1 Hilux Towbar Wiring Kit 7pin (LHD) Installation instructions Model year: 05/2015 Vehicle code: GUN1**L-****HW(3) Part number: PW5D0-0K001 Manual reference number: AIM 003 431-2...
-
Page 2: Revision Record
Revision record Rev. No. Date Page Picture Update Deleted Steps 15.10.15 15.10.15 10,11,15,18,20 4,6,14,19,22 15.10.15 24,25,26,29 29,31,33,36 15.10.15 19.07.16 19,20,28 21,22,35 Manual Ref. no. AIM 003 431-2 2 of 36... - Page 3 Manual Ref. no. AIM 003 431-2 3 of 36...
- Page 4 Manual Ref. no. AIM 003 431-2 4 of 36...
- Page 5 Manual Ref. no. AIM 003 431-2 5 of 36...
- Page 6 200 mm 450 mm 540 mm PZ457-00560-15 PZ457-00560-20 Manual Ref. no. AIM 003 431-2 6 of 36...
- Page 7 Soap Cleaner/ Degreaser 8/10/12/14 mm 8/10/12/14 mm PVC - Tape 3 mm Reference: (mm) PZ415-0JGB9-00 Manual Ref. no. AIM 003 431-2 7 of 36...
- Page 8 7-10 ROUTING battery 2 battery 1 STOP Airbag Manual Ref. no. AIM 003 431-2 8 of 36...
- Page 9 Installer Safety Customer Safety Regulation Attention 10 mm 8 Nm 12 mm Manual Ref. no. AIM 003 431-2 9 of 36...
- Page 10 12 mm 13 Nm 20 mm Manual Ref. no. AIM 003 431-2 10 of 36...
- Page 11 Manual Ref. no. AIM 003 431-2 11 of 36...
- Page 12 Soap Manual Ref. no. AIM 003 431-2 12 of 36...
- Page 13 12-13 Manual Ref. no. AIM 003 431-2 13 of 36...
- Page 14 Manual Ref. no. AIM 003 431-2 14 of 36...
- Page 15 10 mm 10 mm 8,5 Nm Manual Ref. no. AIM 003 431-2 15 of 36...
- Page 16 12 mm Manual Ref. no. AIM 003 431-2 16 of 36...
- Page 17 Manual Ref. no. AIM 003 431-2 17 of 36...
- Page 18 12 mm 30 Nm Manual Ref. no. AIM 003 431-2 18 of 36...
- Page 19 Manual Ref. no. AIM 003 431-2 19 of 36...
- Page 20 10 mm 12 mm 19 Nm Manual Ref. no. AIM 003 431-2 20 of 36...
- Page 21 Manual Ref. no. AIM 003 431-2 21 of 36...
- Page 22 Manual Ref. no. AIM 003 431-2 22 of 36...
- Page 23 stop 6/54 7/58-L 3/31 5/58-R Manual Ref. no. AIM 003 431-2 23 of 36...
- Page 24 Manual Ref. no. AIM 003 431-2 24 of 36...
- Page 25 32-34 Manual Ref. no. AIM 003 431-2 25 of 36...
- Page 26 Signal TURN R TURN L GR-W PIN1 Reference: GR-Y PIN2 SB (mm) Manual Ref. no. AIM 003 431-2 26 of 36...
- Page 27 Manual Ref. no. AIM 003 431-2 27 of 36...
- Page 28 10 mm 10 mm Rear Fog Manual Ref. no. AIM 003 431-2 28 of 36...
- Page 29 Block Assy, Relay: 82660-52010 38-39 Manual Ref. no. AIM 003 431-2 29 of 36...
- Page 30 10 mm (0.39 in) 10 mm (0.39 in) 10 mm (0.39 in) 10 mm (0.39 in) Manual Ref. no. AIM 003 431-2 30 of 36...
- Page 31 10 mm 8,5 Nm Reference: Signal REAR FOG (mm) Manual Ref. no. AIM 003 431-2 31 of 36...
- Page 32 Signal REAR FOG Manual Ref. no. AIM 003 431-2 32 of 36...
- Page 33 E F G O 5,4 Nm 10 mm Manual Ref. no. AIM 003 431-2 33 of 36...
- Page 34 Towing Hitch Wiring Model / Year Hilux 2015/05 7 POLE LHD Adapter Adapter 34 of 36 Manual Ref. no. AIM 003 431-2...
-
Page 35: Check Sheet
CHECK SHEET Page 1 of 2 Towing Hitch Wiring Model / Year Hilux 2015/05 7 POLE LHD VIN n° P/N = OK CLICK Serial Number 10 mm 8 Nm 4x CLICK Serial Number 12 mm 13 Nm 1x CLICK Serial Number 10 mm 8,5 Nm 1x CLICK... - Page 36 CHECK SHEET Page 2 of 2 CLICK Serial Number 10 mm 5,4 Nm 2x s t o p s t o p = OK Installation Date: Technician Name & Signature: Stamp: . . / . . / ..36 of 36 Manual Ref.
