(Continued from previous page.)
The functions that the icons perform is described in the table below:
Icon
Click to bring up the Hotkey setup dialog box (see Hotkey Setup,
page 48 for details).
Click to bring up the Video settings dialog box.
Click to bring up the Message board (see page 51).
Click to send a Ctrl+Alt+Del signal to the remote system.
Click to exit the remote view.
The Lock Key LEDs show the Num Lock, Caps Lock, and Scroll Lock
status of the remote computer.
Click on the icon to toggle the status.
Note: When you first connect, the LED display may not be accurate.
To be sure, click on the LEDs to set them.
The Java Applet Control Panel icons and their functions are described in the
sections that follow.
When the lock state is Off, the LED is dull green and the lock hasp
is open.
When the lock state is On, the LED turns bright green and the lock
hasp is closed.
Chapter 6. The Java Applet
Function
47
