Collar Receiver - D.T. System Micro-iDT PLUS Series Owner's Manual

Collar Belt with
Embedded Re-
ceiver Antenna
Magnetic
Switch
Indicator
(Red Mark)
Collar SmartLED Indicator Light
When the Collar Receiver is turned on, the SmartLED
light will flash green once every two seconds if the
rechargeable battery has 51% to 100% charge left and
flash red once every two seconds if it has 21% to 50%
charge left. The SmartLED light changes to a double
red flash when the battery needs charging.
SmartLED light stays lit red while plugged into the
charger and turns green when charging is complete.
Contacts should fit snugly against the dog's neck to
ensure good skin contact.
information on the proper fit of the collar.
PARTS & FUNCTIONS
Contacts
SmartLED
Indicator Light

Collar Receiver

Contacts
See page 15 for more
8
Battery Charging
Receptacle
The
