- Page 1 SUPER TRAINER SUPER TRAINER Micro-iDT™ PLUS SERIES Electronic Dog Trainer Owner’s Manual • Micro-iDT™ PLUS (One Dog Trainer with Add-On Capability)
-
Page 3: Table Of Contents
TABLE OF CONTENTS Table of Contents ........3 • Introduction..........4 • Package Contents ......... 5 • Model Features........5 • Parts & Functions ........6 • Charging the Batteries......11 • Turning ON and OFF......12 • Testing........... 13 •... -
Page 4: Introduction
INTRODUCTION Congratulations and thank you for purchasing our Micro-iDT™ PLUS Training Collar with Add-On capability. It offers the Maxx-Range™ Internal Antenna System, the industry’s only internally woven antenna in the collar. With up to a 900 yard range, they are perfect for use around the house and versatile enough to use out in the field. -
Page 5: Package Contents
PACKAGE CONTENTS • Transmitter* • Collar Receiver • Rechargeable Batteries for the Collar (already in- stalled in collar unit) • Battery Charger • Splitter/Adaptor Charging Cable • Test Light • Owner’s Manual *9-volt transmitter battery not included MODEL FEATURES • Digital Technology •... -
Page 6: Parts & Functions
PARTS & FUNCTIONS Antenna Collar Selecting Switch Intensity Selection Dial Indicator Light Momentary “Nick” Stimulation Vibration Button Button Continuous Stimulation Button Magnet Model Indicator Number (Red Mark) Battery Cover (back side) Transmitter... - Page 7 PARTS & FUNCTIONS Intensity Selection Dial The intensity selection dial can be set from level 1 to level 16 to find the exact stimulation level for your dog (see page 16). Transmitter Antenna Be sure to check that the antenna is securely fas- tened to the transmitter before each use.
-
Page 8: Collar Receiver
PARTS & FUNCTIONS Remote Training Buttons Pressing the “NICK” button will make the collar give a Momentary, or ‘Nick’ Stimulation. Pressing the “CONT” button gives a Continuous Stimula- tion. Pressing the red button on the left side will make the collar Vibrate only. Collar Selecting Switch Switching between collar units can be controlled by moving the toggle selection... - Page 9 PARTS & FUNCTIONS Collar Indicator Light When the Collar Receiver is turned on, the Red LED light will flash steadily once every two seconds to indicate that the unit is active. The Red LED light changes to a rapid flash when the battery is in need of charging.
- Page 10 PARTS & FUNCTIONS Contacts Contacts should fit snugly against the dog’s neck to ensure good contact with the skin. For more information on the proper fit of the collar, see page 15. Battery Charging Receptacles The battery charging receptacles are located on the side of the Collar Receiver.
-
Page 11: Charging The Batteries
CHARGING THE BATTERIES Micro-iDT™ PLUS Series collars are equipped with rechargeable Nickel Metal Hydride (NiMH) batteries, which are not memory sensitive and do not require depletion before recharging. Although batteries come partially charged from the factory, it is recommended that they are given a full charge (about 12 hours) before initial use. -
Page 12: Turning On And Off
TURNING ON AND OFF The Transmitter is always in a permanent sleep state. It is only ON when a button is being pressed and does not need to be turned off by the user. Turning the Collar Unit On: Hold the Red Mark (Magnet Indicator) on the left side of the transmitter directly against the Red Mark (Magnetic Switch Indicator) on... -
Page 13: Testing
TESTING NOTE: Before testing, make sure that both units are fully charged and the power to the Collar Receiver is “ON”. To Test the Electronic Stimulation: 1. Place the tester firmly on the contacts of the Collar Receiver. 2. Set the intensity (note - an intensity level setting of 4 or less might not be enough to light the tester). -
Page 14: Programming
PROGRAMMING When adding an “Add-On” collar, the collar will need to be programmed to the transmitter. If your current collar unit is not responding to the transmitter, it may also need to be reprogrammed to the transmitter. 1. Select the desired Collar Selecting Switch position on the transmitter. -
Page 15: Properly Fitting The Collar
PROPERLY FITTING THE COLLAR NOTE: Proper collar tightness and position are very important to insure safe and consistent collar use. All electronic collars need to be very snug around the dog’s neck to work properly. They must be just tight enough to allow the “contacts”... -
Page 16: Setting The Intensity Level
SETTING THE INTENSITY LEVEL It is very important to set the correct intensity level on your Micro-iDT PLUS Training System before beginning your training sessions to provide the proper level of stimulation without over-stimulating your dog. 1. Place the Intensity Selection dial so that the system is set on Level 1. -
Page 17: Maintenance
MAINTENANCE Micro- It is very important to periodically clean your iDT™ PLUS Series systems for maximum performance. Regular cleaning will also lengthen the life of your unit. Micro-iDT™ • Clean the PLUS Series collar box with lukewarm water and a mild anti-bacterial soap. •... -
Page 18: Important Safety Notes
IMPORTANT SAFETY NOTES • Before training, your dog should be examined by a veterinarian to assure that your dog is in good health. • Never leave your dog unattended with the unit on. Since no electronic device is perfect, there is a very slight possibility that your dog may receive an unintentional electric stimulation. -
Page 19: Warranty
WARRANTY All Micro-iDT™ PLUS Trainer systems have a one year parts and labor warranty effective from the original date of purchase. A copy of the original sales receipt is required to validate the date of purchase. The Micro-iDT™ PLUS Trainer has been made with State of the Art equipment. Any fine adjustment should be performed only by D.T. -
Page 20: Contact Information
2872 Walnut Hill Lane Dallas, Texas 75229 Tel: (214) 350-9446, (888) 588-8364 Fax: (214) 350-7847 Website: www.dtsystems.com E-mail: customerservice@dtsystems.com 1-iDT PLUS 2010.05.28 Printed in Korea...
