Tripp Lite B004-008 Specifications

Model Number: B004-008
KVM Switch - 8-Port 1U Rackmount KVM Switch
Description
Tripp Lite's B004-008, 8-Port KVM Switch, is a low-cost solution for IT managers needing a KVM switch for up to 8 CPU's. Use on a desktop or in
the rack; comes with 19" rackmount hardware. This switch provides two convenient methods to access any PC connected to the unit: Port Selection
buttons located on the front panel, or, Hot-Key commands from the keyboard. A powerful Quick View Scan Mode feature allows you to auto-scan and
monitor the activities of all installed operating PC's, one-by-one. Choose from three different cable lengths to connect from the switch to the CPU:
P750-006, P750-010, or P750-015. (For computers with USB keyboard and mouse inputs, use Tripp Lite B015-000, PS/2 to USB converter, in
conjunction with the P750 cable kit). For a more feature rich 8-port KVM switch, with On Screen Display (OSD) menu functions, as well as
expandability, see Tripp Lite B042-008. Constructed of heavy-duty steel housing.
System Requirements
PS/2 mouse
PS/2 keyboard
Computer with PS/2 mouse and keyboard ports or an available USB port
1 P750-Series PS/2 KVM cable kit per PS/2 computer; or, 1 P750-Series PS/2 KVM cable kit and 1 B015-000 PS/2 to USB adapter per
USB computer
Compatible with all major operating systems
Package Includes
8 Port KVM Switch (Rackmount Ready)
Optional AC Power Adapter - 100-240V, 50/60Hz, 0.5A
Manual
Features
Control up to 8 PC's from a single console
No software required - Switch between ports via front panel push buttons or hotkey commands
Quick View Scan Mode for monitoring selected PC's
PS/2 and Serial Mouse emulation provided for system boot-up
Microsoft Intellimouse Pro, Logitech FirstMouse, FirstMouse+ support
SVGA, VGA, and MultiSync monitor support
Push Button LED display for easy status monitoring
Rack mountable in 19" system rack - mounting hardware included with switch
Hot Pluggable - add or remove PC's without powering down the switch
Compatible with all major operating systems
Superior Video Quality: 1920x1440; DDC2B
Highlights
Low Cost Switching Solution
Does not require software or complicated setup simply Plug and Play
Ultra-Compact – occupies only 1U rack space
