Owner's Manual
DisplayPort KVM Switch
USB 3.0 Hub
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind.
You could also win an ISOBAR6ULTRA
surge protector-a $50 value!
www.tripplite.com/warranty
Copyright © 2015 Tripp Lite. All rights reserved.
2
2
2
3
1
4
5
7
5/7/2015 4:20:53 PM
Advertisement
Related Manuals for Tripp Lite B004-DPUA2-K
Summary of Contents for Tripp Lite B004-DPUA2-K
-
Page 1: Table Of Contents
