Contents
WARNING
WARNING .................................................. 3
CAUTION ................................................... 3
PRECAUTIONS ......................................... 3
Turning Power On and Off ............................... 6
Initial System Start-Up ..................................... 6
Display Tilt Adjustment .................................... 6
Adjusting Volume ............................................. 6
(CDA-9833R only) ....................................... 6
(CDA-9835R only) ........................................ 6
Listening to Radio ............................................. 7
Manual Storing of Station Presets .................... 8
Tuning to Preset Stations .................................. 8
Station Title Search Function ............................ 8
Frequency Search Function .............................. 8
RDS Stations ................................................. 9
Recalling Preset RDS Stations .......................... 9
PI SEEK Setting .............................................. 10
Receiving Traffic Information ........................ 10
PTY (Programme Type) Tuning ..................... 10
CD or Radio ................................................. 11
Priority PTY (Programme Type) .................... 11
Displaying Radio Text .................................... 12
Playback .......................................................... 12
Playing back a Playlist .................................... 13
Repeat Play ..................................................... 14
M.I.X. (Random Play) .................................... 14
Scanning Programmes .................................... 15
Searching from CD Text ................................. 15
WMA) ........................................................... 15
Quick Search ................................................... 15
About MP3/WMA .......................................... 16
Equalizer Presets ............................................. 18
About the Crossover ....................................... 18
About Time Correction ................................... 20
Bass Focus ...................................................... 21
Settings ........................................................... 22
Setting the MX Mode ..................................... 23
Displaying the Title/Text ................................. 23
Titling Discs/Stations ...................................... 25
Erasing Disc Title/Station Title ....................... 25
Blackout Mode On and Off ............................. 25
Setting an Amplifier Link ............................... 26
Information .................................................. 26
All the Buttons ............................................. 27
Verifying the Software Version ....................... 27
