CVA-1006R
Mobile Multimedia Station
ALPINE ELECTRONICS, INC.
Tokyo office: 1-1-8 Nishi Gotanda,
Shinagawa-ku,
Tokyo 141-8501, Japan
Tel.: (03) 3494-1101
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
Suite 203, 7300 Warden Ave. Markham,
Ontario L3R 9Z6, Canada
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
Yamagata Printing Co., Ltd.
2-6-34, Takashima, Nishi-ku,
Yokohama, Kanagawa, Japan
IVX-C806
IVX-M706
• OWNER'S MANUAL
Please read before using this equipment.
• BEDIENUNGSANLEITUNG
Lesen Sie diese Bedienungsanleitung bitte vor
Gebrauch des Gerätes.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
• ISTRUZIONI PER L'USO
Si prega di leggere prima di utilizzare il
attrezzatura.
• ANVÄNDARHANDLEDNING
Innan du använder utrustningen bör du läsa
igenom denna användarhandledning.
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
6-8 Fiveways Boulevarde Keysborough,
Victoria 3173, Australia
Tel.: (03) 9769-0000
ALPINE ELECTRONICS GmbH
Kreuzerkamp 7-11 40878 Ratingen, Germany
Tel.: 02102-45 50
ALPINE ITALIA S.p.A.
Via C. Colombo 8, 20090 Trezzano Sul Naviglio
Tel.: 02-48 47 81
B.P. 50016 F-95945, Roissy, Charles De Gaulle
13 Tanners Drive, Blakelands, Milton Keynes
MI, Italy
R
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue De La Belle Etoile, Z.I. Paris Nord Il
Cedex, France
Tel.: 01-48 63 89 89
ALPINE ELECTRONICS OF U.K., LTD.
MK14 5BU, U.K.
Tel.: 01908-61 15 56
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal De Gamarra 36, Pabellón 32
01013 Vitoria (Alava)-Apdo. 133, Spain
Tel.: 34-45-283588
Designed by ALPINE Japan
Printed in Japan (Y)
68P41262Y58-O
EN
DE
FR
ES
ES
IT
IT
SE
SE
Advertisement
Table of Contents
Related Manuals for Alpine IVX-C806
Summary of Contents for Alpine IVX-C806
- Page 1 • ANVÄNDARHANDLEDNING Innan du använder utrustningen bör du läsa igenom denna användarhandledning. ALPINE ELECTRONICS, INC. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ELECTRONICS FRANCE S.A.R.L. Tokyo office: 1-1-8 Nishi Gotanda, 6-8 Fiveways Boulevarde Keysborough, (RCS PONTOISE B 338 101 280)
- Page 2 Un caricatore CD Alpine offre maggiore scelta. Tutti i modelli, eccetto il modello CHM-S620, possono essere controllati tramite le unità di controllo Alpine e producono un suono di qualità eccellente. CHA-S624 è un caricatore a 6 dischi Ai NET compatibile e dotato di un nuovo M DAC, di un'uscita ottica digitale, memorizzazione dei titoli di 150 dischi e CD TEXT.
-
Page 3: Table Of Contents
ENGLISH Contents CD player Operation (IVX-C806 only) Operating Instructions (IVX-M706/CVA-1006R..optional) WARNING Playback ............18 Fast Forward and Backward ......18 WARNING ..........3 Music Sensor (Skip) ........19 CAUTION ........... 3 Repeat Play ............. 19 PRECAUTIONS ......... 4 M.I.X. (Random) Play ........19 Displaying and Scrolling CD Title/Text .. - Page 4 Other Useful Features Caution ............60 Precautions ............60 Displaying Spectrum Analyzer Installation ............61 (IVX-C806 only) ......... 39 Connections ............ 64 Displaying Spectrum Analyzer (IVX-M706/CVA-1006R only) ....40 * US and foreign patents licensed from Dolby Turning Defeat Mode On and Off ....40 Laboratories.
-
Page 5: Warning
DO NOT OPERATE ANY FUNCTION THAT TAKES Failure to do so may cause personal injury or damage to YOUR ATTENTION AWAY FROM SAFELY DRIVING the product. Return it to your authorized Alpine dealer or YOUR VEHICLE. the nearest Alpine Service Centre for repairing. -
Page 6: Precautions
If you have problems, do not attempt to repair the unit or irregularities, this could inhibit proper loading of the yourself. Return it to your Alpine dealer or the nearest disc. To remove the bumps, rub the inside edge of the hole Alpine Service Station for servicing. - Page 7 Depending on the products connected, the functions and disc to be out of standard specifications and may create displays will vary. For details, consult your Alpine dealer. operational problems. We recommend not using these accessories on discs played in Alpine CD players.
- Page 8 This ensures the focus of the driver’s attention will be on the road and not on the IVX-C806/ IVX-M706/CVA-1006R. This has been done for the safety of the driver and passengers.
-
Page 9: Basic Operation
• If both the DVD player and DVD Changer are connected, the display shows " DVD " instead of " AUX1 ", and " DVD-CHG " instead of " AUX2 ". Radio Mode Screen (IVX-C806 screen) Selected Source Current Time Volume Level The Function Guide displays the labels for each of the Function buttons. -
Page 10: Using Face Cover
If your vehicle has steering wheel controls for IVX-C806/IVX-M706/CVA-1006R. the radio, an optional steering wheel control Put the face cover onto the IVX-C806/IVX-M706/ interface may be available to connect to your CVA-1006R when you leave the vehicle. Alpine radio. For details, contact your Alpine Be sure to remove the anti-theft face cover when you dealer. -
Page 11: Lowering The Monitor
If the This is normal and not a malfunction. switched power (ignition) lead of the IVX-C806/IVX- M706/CVA-1006R is connected directly to the positive (+) post of the vehicle's battery, the battery may be discharged. -
Page 12: Adjusting The Volume/Bass/Treble/Balance (Between Left And Right)/Fader (Between Front And Rear)
Basic Operation (IVX-M706 ..with MD built-in MUTE (IVX-C806) MUTE CVA-1006R ... without MD built-in) FUNC FUNC SOURCE Rotary encoder Rotary encoder SOURCE Adjusting the Volume/Bass/Treble/ Turning Loudness On or Off Balance (Between Left and Right)/ Loudness introduces a special low- and high- Fader (Between Front and Rear) frequency emphasis at low listening levels. -
Page 13: Radio Operation
Radio Operation (IVX-M706 ..with MD built-in (IVX-C806) CVA-1006R ... without MD built-in) SOURCE Rotary encoder BAND SOURCE Rotary encoder BAND Manual Tuning Automatic Seek Tuning Press the SOURCE button after turning on the Press the BAND button repeatedly to select the power. -
Page 14: Mono/Stereo Switching
Radio Operation (IVX-M706 ..with MD built-in CVA-1006R ... without MD built-in) (IVX-C806) Function buttons Function buttons (1 through 6) (1 through 6) FUNC FUNC BAND BAND Mono/Stereo Switching While the P.SET1 through P.SET6 indicators in the display are blinking, press the Function... -
Page 15: Automatic Memory Of Station Presets
Automatic Memory of Station T.R.V.S. Search for Local Stations Presets Using the T.R.V.S. feature of this unit, you can automatically seek and memorize up to 12 local The tuner can automatically seek and store 6 stations (max.) in a memory separate from your strong stations in the selected band in order of regular preset memory. -
Page 16: Rds Operation
RDS Operation (IVX-M706 ..with MD built-in (IVX-C806) CVA-1006R ... without MD built-in) FUNC FUNC SOURCE Rotary encoder Rotary encoder SOURCE Tips Turning AF (Alternative The RDS digital data includes the followings: Frequencies) On or Off Programme Identification Programme Service Name... -
Page 17: Receiving Traffic Information
Receiving Traffic Information PTY (Programme Type) Tuning Press the RDS button. Press the RDS button. The display changes to The display changes to the RDS setting screen. the RDS Setting Screen. Press the 4 (T.INFO) button to turn on the Press the 5 (PTY) button to activate the PTY Traffic Information mode. -
Page 18: Receiving Traffic Information While Playing Cd/Md/Radio
RDS Operation (IVX-M706 ..with MD built-in CVA-1006R ... without MD built-in) (IVX-C806) FUNC FUNC SOURCE RDS/R.TEXT RDS/R.TEXT Rotary encoder Rotary encoder SOURCE Receiving Traffic Information While When traffic information stations cannot be received: Playing CD/MD/Radio In the CD/MD mode:... -
Page 19: Priority Pty (Programme Type)
Priority PTY (Programme Type) Turning Emergency Alarm Display On or Off This function allows presetting of a programme type such as music category, news, etc. You can Press the SOURCE button. listen to a programme in the preset programme The display shows the main menu screen. type as the unit automatically gives priority to the Press the 6 (SETUP) button. -
Page 20: Cd Player Operation (Ivx-C806 Only) (Ivx-M706/Cva-1006R
Only IVX-C806 has a built-in CD player. press the eject button on the optional CD player.) When an optional Alpine CD player or CD Changer is connected, you can control it from the IVX-C806/ NOTES (IVX-C806 only) Three-inch (8 cm) CD's can be used. -
Page 21: Music Sensor (Skip)
Music Sensor (Skip) Displaying and Scrolling CD Title/ Text This feature allows you to go to the beginning of a track. If titles have been memorized for CDs, the CD titles can be shown on the display (for titling CDs, Lightly press the 1 (g) button during the CD see "Titling CDs"... -
Page 22: Displaying List Of Track Titles/Cd Titles
CD player Operation (IVX-C806 only) (IVX-M706/CVA-1006R..optional) (IVX-M706 ..with MD built-in CVA-1006R ... without MD built-in) (IVX-C806) Function buttons Function buttons (1 through 6) (1 through 6) FUNC FUNC SOURCE BAND SOURCE LIST Rotary encoder CHANGER BAND LIST Rotary encoder... -
Page 23: Controlling Cd Changer (Optional)
After selecting the desired, you can operate in the if it is Ai-NET compatible. With a CD Changer same way as for the CD player. For details please see connected to the Ai-NET input of the IVX-C806/ the CD player operation section. IVX-M706/CVA-1006R, the CD Changer will be... -
Page 24: Md Player Operation (Ivx-M706 Only) (Ivx-C806/Cva-1006R
MD cartridge. If you feel any small bumps or IVX-M706 has a built-in MD player. This section irregularities, remove them because these may cause a describes operation assuming that an Alpine MD malfunction or damage to the player. player is connected. -
Page 25: Fast Forward And Backward
When a CD/MD player or CD Changer is connected, pressing the 1 button displays the title list. With IVX-M706 built-in MD or IVX-C806, CVA- 1006R connected, the MD player can scroll titles (disc or track names) having up to a maximum of 32 characters. -
Page 26: Dvd/Video Cd/Cd Player/Dvd Changer Operation (Optional)
Playing DVD/Video CD/CD Press the 6 (F.GUIDE) button during DVD/video CD/ CD play to turn on or off the Function Guide display. If an optional Alpine DVD/video CD/CD player is In the ON position: connected to the IVX-C806/IVX-M706/CVA-1006R, The Function Guide display will always be shown. -
Page 27: Fast Forward/Backward
DVD/DVD Changer mode screen. You can play all the tracks in random order. IVX-C806: Pressing the 2 button displays the title list or the You can use the M.I.X. function only on the track title list only when a CD with text is loaded in connected DVD player equipped with the M.I.X. -
Page 28: Controlling Dvd Changer
Controlling DVD Changer To select your desired track number on the selected disc, lightly press the 1 (g) or 3 (f) If an optional Alpine DVD Changer is connected repeatedly until your desired track number is displayed. to the IVX-C806/IVX-M706/CVA-1006R, the DVD... -
Page 29: Navigation System Operation (Optional)
SOURCE SOURCE Rotary encoder Rotary encoder Controlling Navigation System If an optional Alpine Navigation System is connected to the IVX-C806/IVX-M706/CVA- 1006R, some of its functions can be controlled from the IVX-C806/IVX-M706/CVA-1006R. The functions and display indicators available will vary depending upon the Navigation System connected. -
Page 30: Auxiliary Device Operation (Optional)
SOURCE Rotary encoder Rotary encoder Operating Auxiliary Devices To operate your devices connected to the AUX terminals on the rear panel of IVX-C806/IVX-M706/ CVA-1006R, follow the procedure described below. WARNING It is dangerous (and illegal in many states) for the driver to watch the TV/Video while driving the vehicle. -
Page 31: Audio Processor Operation (Optional)
When the FUNC (RETURN) button is pressed, the Equalization Presets display returns to the previous screen. If an optional Alpine Equalizer is connected to the In the equalizer mode, for example, you can horizontally scroll each of the mode screens by rotating the rotary IVX-C806/IVX-M706/CVA-1006R, the Equalizer encoder to the left or right. -
Page 32: Presets
Audio Processor Operation (Optional) (IVX-M706 ..with MD built-in (IVX-C806) CVA-1006R ... without MD built-in) Function buttons Function buttons (1 through 6) (1 through 6) FUNC FUNC SOURCE SOURCE Rotary encoder Rotary encoder Creating Personal Equalizer Selecting Factory Surround Mode... -
Page 33: Adjusting Surround Levels And Surround Delay Time
Adjusting Surround Levels and Selecting DHE (Digital Harmonic Surround Delay Time Enhancer) Mode If your equalizer connected is equipped with the The DHE mode enhances the sound of musical surround level/time adjustment feature, you can instruments or vocals, while masking road noises adjust the surround sound levels and surround of a moving vehicle. -
Page 34: Setting Dhe Power Or Fine Mode
Audio Processor Operation (Optional) (IVX-M706 ..with MD built-in (IVX-C806) CVA-1006R ... without MD built-in) Function buttons Function buttons (2 through 6) (2 through 6) FUNC FUNC SOURCE SOURCE Rotary encoder Rotary encoder Setting DHE Power or Fine Mode Selecting BBE Mode... -
Page 35: Customizing Bbe Mode
Customizing BBE Mode Adjusting Listening Position Activate the L.P.S. mode and select the listening This function is operative only when an audio position you wish to adjust by referring to processor equipped with the BBE level (Low and "Selecting Listening Position" section. High) adjustment feature is connected. -
Page 36: Adjustment Of Time Correction Value
Adjusting Cross-Over (X-Over) Value Point of 2-Way Divider Press the SOURCE button. If an optional Alpine Channel Divider PRA-H400 The main menu appears on the display. is connected, you can control the Divider from the Press the 4 (A.PROC) button. -
Page 37: Adjusting Levels
Adjusting Levels Press the rotary encoder and select the channel that you wish to adjust. Press and hold the FUNC (RETURN) button for Each press changes the channel as follows. at least 2 seconds in the Divider mode. When only one 2-way divider is connected: The mode changes to the Divider Adjustment F-High R-High... -
Page 38: Adjusting Time-Correction For 2-Way Speaker System
Audio Processor Operation (Optional) (IVX-M706 ..with MD built-in CVA-1006R ... without MD built-in) (IVX-C806) Function buttons Function buttons (1 through 6) (1 through 6) FUNC FUNC SOURCE SOURCE Rotary encoder Rotary encoder Adjusting Time-Correction for When two 3-way dividers are connected:... -
Page 39: Memorizing Divider Settings
This unit can memorize curves together with the settings Memorized Using Optional Divider of the equalizer, DHE, BBE and Surround Time Correction. If an optional Alpine divider (such as PXA-H600/ PXA-H510) is connected, you can recall the settings memorized using the optional divider. Press the SOURCE button. -
Page 40: Recalling Memorized Characteristic Curves Using Function Buttons
Audio Processor Operation (Optional) (IVX-M706 ..with MD built-in CVA-1006R ... without MD built-in) (IVX-C806) Function buttons Function buttons (1 through 6) (1 through 6) Rotary encoder Rotary encoder Recalling Memorized Selecting Characteristic Curves Characteristic Curves Using from Displayed Audio Processor... -
Page 41: Other Useful Features
(IVX-C806) SPE.ANA. Displaying Spectrum Analyzer Mode 3: This mode emphasizes the rhythmical bass sound and gives an image of vivid (IVX-C806 only) low frequencies. Depending on the external audio processor connected to the unit, this function may not work properly. -
Page 42: Displaying Spectrum Analyzer (Ivx-M706/Cva-1006R Only)
Other Useful Features (IVX-M706 ..with MD built-in (IVX-C806) CVA-1006R ... without MD built-in) 2 3 4 2 3 4 SOURCE SOURCE INPUT Rotary encoder INPUT Rotary encoder Displaying Spectrum Analyzer Mode 3: This mode emphasizes the rhythmical bass sound and gives an image of vivid (IVX-M706/CVA-1006R only) low frequencies. -
Page 43: Titling Cds
NOTES Titling CDs If the memory capacity for CD titles is full and if you attempt to title a new CD, the oldest title will be You can title up to 120 CDs (max.). erased to make room for the new one. To delete a title, select the title you want to delete, then select "SPC"... -
Page 44: Adjusting Subwoofer Level (When Subwoofer Is Used With Other Speakers)
Immediately after inputting titles or changing the NOTES settings of Setup Mode or Display Mode (While For further information, please contact your Alpine the system is inputting the titles or data dealer. automatically) do not turn the ignition key (engine When you connect a subwoofer, you need an amplifier key) to OFF. -
Page 45: Switching Phase
Setting the External Device Interrupt Mode Use the phase-switching function after connecting your audio-processor, amplifier and subwoofer to If an Alpine Ai-NET Interrupt Box (NVE-K200) is the IVX-C806/IVX-M706/CVA-1006R. connected to the IVX-C806/IVX-M706/CVA-1006R, an Auxiliary Source will be allowed to interrupt the Immediately after inputting titles or changing the current audio source. -
Page 46: Setting Interrupt Icon Display (In-Int)
Rotary encoder Setting Interrupt Icon Display Interrupt Feature (MIX LEVEL) (IN-INT) With an Alpine navigation system connected to the IVX-C806/IVX-M706/CVA-1006R, the voice The unit can display the icon of the external guidance of the navigation system will be mixed device such as a telephone whenever a phone with the radio or CD/MD play. -
Page 47: Setting Bass Frequency
Navigation or V. SEL. You can then reduced when the voice guidance of the Navigation display the screen of the preset item by just system starts. pressing the V. SEL button on the IVX-C806/IVX- M706/CVA-1006R. Setting Bass Frequency Immediately after inputting titles or changing the... -
Page 48: Selecting Rear Monitor
Immediately after inputting titles or changing the monitor in the AUX OUT mode, the rear-seat monitor settings of Setup Mode or Display Mode (While displays the same picture as for the IVX-C806/IVX- the system is inputting the titles or data M706/CVA-1006R. -
Page 49: Displaying Time
Displaying Time Press the FUNC (RETURN) button after adjusting the clock. Immediately after inputting titles or changing the The display returns to the main menu screen. settings of Setup Mode or Display Mode (While NOTE the system is inputting the titles or data To quickly set the time to the nearest hour, press the 5 (TIME RESET) button... -
Page 50: Sound (Beep) Guide Function
Other Useful Features OPEN/CLOSE OPEN/CLOSE FUNC FUNC SOURCE (IVX-M706 ..with MD built-in (IVX-C806) CVA-1006R ... without MD built-in) SOURCE Rotary encoder Rotary encoder Sound (Beep) Guide Function Demonstration This function will give audible feedback with In the Demonstration mode, the unit performs varying tones depending upon the button scanning of the basic operation of each source. -
Page 51: Setting Automatic Opening/Closing Of Monitor
Setting Automatic Opening/ Adjusting Brightness of Picture Closing of Monitor Immediately after inputting titles or changing the settings of Setup Mode or Display Mode (While When the Automatic Opening/Closing mode is the system is inputting the titles or data "ON," the monitor automatically opens when the automatically) do not turn the ignition key (engine ignition key is turned to the "ACC"... -
Page 52: Adjusting Tint Of Picture
Other Useful Features (IVX-M706 ..with MD built-in (IVX-C806) CVA-1006R ... without MD built-in) Function buttons Function buttons (1 through 6) (1 through 6) FUNC FUNC SOURCE SOURCE Rotary encoder Rotary encoder Adjusting Tint of Picture Adjusting Colour of Picture... -
Page 53: Illumination Control
Illumination Control Switching Background Textures/ Colours Setting the illumination control to AUTO, decreases the illumination brightness of the IVX- You have a choice of 12 different background C806/IVX-M706/CVA-1006R, whenever the textures/colours preset at the factory. Select them parking lamps of the vehicle are ON. following the procedure below. -
Page 54: Setting Automatic Background Texture/Colour Scroll
Other Useful Features (IVX-M706 ..with MD built-in (IVX-C806) CVA-1006R ... without MD built-in) SOURCE V.SEL SOURCE Rotary encoder V.SEL Rotary encoder Setting Automatic Background Switching Display Modes Texture/Colour Scroll Press and hold the V.SEL button for at least 2 seconds in the AUX or NAVI mode. -
Page 55: Playing 2 Sources Simultaneously
(Example) MODE3 Picture Voice RADIO TAPE AUX2 AUX1* NOTE In the Mode 3 (Cinema), the monitor displays a Operative only when the video source is DVD, normal picture by stretching out the picture Navigation, AUX1 or AUX 2. horizontally and vertically. This mode is good for displaying a cinema type picture with the To change only the video portion while listening proportion of 16 to 9. -
Page 56: Remote Control Operation
For the operation of external audio processor, refer to the The buttons have the same functions as rotating Owner's Manual of the external audio processor you the rotary encoder on IVX-M706/IVX-C806/CVA- purchased. 1006R. This button is used in conjunction with an optional Ai-... -
Page 57: Battery Replacement
• Point the remote control transmitter toward the remote sensor on the IVX-C806/IVX-M706/CVA-1006R and use the remote control within 2 meters from the IVX-C806/ IVX-M706/CVA-1006R. Opening the battery cover Slide out the battery cover while firmly pressing the direction of arrow. -
Page 58: Information
- Press the Reset button with a ball-point pen or other - If above solution does not work, tune in another station. pointed article. • Weak or no battery power. CD (IVX-C806 only) - Check battery. No sound or unnatural sound. CD playback sound is wavering. - Page 59 MD (IVX-M706 only) Indication for CD Player (IVX-C806 only) The MD could not be inserted. HI-TEMP • Another MD is already inserted. - Eject the inserted MD and insert the MD. • Protective circuit is activated due to high temperature.
- Page 60 MD c button again. If the error indication still does not turn off after pressing • Magazine ejection not possible. the MD c button for a few times, consult your Alpine - Press the magazine eject button. dealer. If the magazine does not eject, see the Owner's Manual for the CD Changer.
-
Page 61: Specifications
Sensitivity (IEC Standard) 31.6 µV/30 dB NOTES Due to continuous product improvement, specifications CD PLAYER SECTION (IVX-C806 only) and design are subject to change without notice. Frequency Response 5 – 20,000 Hz (±1 dB) The LCD panel is manufactured using an extremely high Wow &... -
Page 62: Installation And Connections
Failure to do so may result in damage to the unit and/or the CONNECTIONS. vehicle. When in doubt, consult your ALPINE dealer. The IVX-C806/IVX-M706/CVA-1006R uses female RCA-type Bolts or nuts used for the brake or steering systems (or any other jacks for connection to other units (e.g. -
Page 63: Installation
Installation Installing the Monitor When your vehicle has the Bracket, mount the long hex bolt onto the rear panel of the IVX-C806/ Place of installation IVX-M706/CVA-1006R and put the Rubber Cap Before determining the position of installation, on the hex bolt. If your vehicle does not have the... - Page 64 When mounting the tuner with the screws, be sure to choose a flat location. When making holes, be careful not to scratch any Screws pipes or wires. (M5x6) IVX-C806/ (Included) Ground Lead IVX-M706/ Connect the bracket to both the flanks of the CVA-1006R tuner with the supplied pan screws (M4x8).
- Page 65 If your vehicle has no ACC power supply, add an SPST (Single-Pole, Single-Throw) switch (sold separately). If the switched power (ignition) lead of the IVX-C806/IVX-M706/CVA-1006R is connected directly to the positive (+) post of the vehicle‘s battery, the IVX-C806/IVX-M706/CVA-1006R draws some current (several hundred milliamperes) even when its switch is placed in the OFF position and the battery may be discharged.
-
Page 66: Connections
Installation and Connections Connections (IVX-C806/IVX-M706/CVA-1006R Wiring Diagram) ILLUMINATION ILLM To the instrument cluster illumination lead (Orange) (Orange) IVX-C806/ IVX-M706/ BATTERY BATT CVA-1006R (Yellow) (Yellow) <Monitor> (Black) Antenna (Black) <Tuner> fi REMOTE OUT AUX1 FM ANTENNA (White/Brown) AUDIO L(MONO) AUX INPUT... - Page 67 NET feature, place this switch in the EQ/DIV cluster illumination lead. This will allow the position. When no device is connected, leave the backlighting of the IVX-C806/IVX-M706/CVA-1006R switch in the NORM position. NOTE to dim whenever the vehicle‘s lights are turned on.
- Page 68 Equalizer equipped with Ai-NET (Sold Separately) (White: L-ch) (Red: R-ch) ⁄ (White: L-ch) Colour Control of TV Tuner is set to OFF. & When connecting with NVE-N055PV of the Alpine’s Navigation System (NVE-N055PV) IVX-C801/ Navigation Connector Box IVX-M706/ CVA-1006R CD Changer (Ai-NET)
- Page 69 When connecting the DVD Changer REMOTE IN REMOTE OUT AUX1 (White/Brown) (White/Brown) <Tuner> To VIDEO FM ANTENNA OUTPUT terminal (Yellow) AUDIO ¤ L(MONO) AUX INPUT DVD Changer VIDEO (Sold Separately) NAVIGATION INPUT AUDIO L(MONO) AUX OUTPUT VIDEO DISPLAY OUTPUT REMOTE OUT Ai-NET ‹...
