Mobile Multimedia Station
IVA-D300
DIGITAL VIDEO
• OWNER'S MANUAL
Please read before using this equipment.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
6-8 Fiveways Boulevarde Keysborough,
Victoria 3173, Australia
Phone 03-9769-0000
ALPINE ELECTRONICS GmbH
Frankfurter Ring 117
80807 München, Germany
Phone 089-32 42 640
ALPINE ELECTRONICS OF U.K. LTD.
Alpine House
Fletchamstead Highway, Coventry CV4 9TW, U.K.
Phone 0870-33 33 763
R
TM
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue de la Belle Etoile, Z.I. Paris Nord Il,
B.P. 50016, 95945 Roissy Charles de Gaulle
Cedex, France
Phone 01-48638989
ALPINE ITALIA S.p.A.
Viale C. Colombo 8, 20090 Trezzano
Sul Naviglio (MI), Italy
Phone 02-484781
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava)-APDO 133, Spain
Phone 945-283588
Designed by ALPINE Japan
Printed in Japan (Y)
68P70033Y31-O
EN
FR
ES
ES
IT
SE
Advertisement
Table of Contents
Related Manuals for Alpine IVA-D300
Summary of Contents for Alpine IVA-D300
- Page 1 Veuillez lire avant d'utiliser cet appareil. • MANUAL DE OPERACIÓN Léalo antes de utilizar este equipo. ALPINE ELECTRONICS MARKETING, INC. ALPINE ELECTRONICS FRANCE S.A.R.L. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. 1-1-8 Nishi Gotanda, (RCS PONTOISE B 338 101 280) 6-8 Fiveways Boulevarde Keysborough, Shinagawa-ku, 98, Rue de la Belle Etoile, Z.I.
- Page 2 PLAY BACK and CD TEXT. The CHA-1214 Ai-NET model holds 12 discs, and the CHM-S630 M-Bus model is a super-compact 6-disc changer with a CD-R/RW PLAY BACK. Changeurs de CD Alpine : vous avez le choix! Plus de sélections musicales, plus de souplesse, plus de confort.
-
Page 3: Table Of Contents
ENGLISH Contents If a menu screen appears ......18 Displaying the Top Menu Screen (DVD only) ..........19 Operating Instructions Displaying the Menu Screen (DVD only) ..19 Displaying the Menu Operation Mode Screen WARNING (DVD only) ..........19 WARNING ..........4 Turning the PBC Function ON or OFF CAUTION ........... - Page 4 Monitor Setting Setting of the External Monitor Output ..33 Setting of the Rear Camera ......33 Monitor Setting Operation ......26 Setting Visual Mode ........33 Adjusting the Monitor Angle ....... 26 Optical Digital Input Selection for Selecting the Monitor Position ..... 26 an External Audio Processor .....
- Page 5 Precautions ..........66 Changer (Optional) Installation ............67 Controlling CD Changer (Optional) ....52 Connections (IVA-D300 Wiring Diagram) ..70 Multi-Changer Selection (Optional) ....52 System Example ..........72 HDD Player Operation (Optional) Listening to Music of HDD ......53...
-
Page 6: Operating Instructions
Failure to do so may cause personal injury or damage to the DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR product. Return it to your authorized Alpine dealer or the nearest Alpine Service Center for repairing. ATTENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE. -
Page 7: Precautions
(Bumps) Damaged Disc Installation Location Do not attempt to play cracked, warped, or damaged discs. Make sure the IVA-D300 will not be installed in a location Playing a bad disc could severely damage the playback subjected to: mechanism. • Direct sun and heat Maintenance •... -
Page 8: Discs Playable On This Unit
This ensures the focus of the driver's attention will be on the road and not on the Music Audio IVA-D300. This has been done for the safety of the driver and 8 cm Approx. passengers. - Page 9 Some files recorded by a Tips for making your own CDs software using an improper recording system may be The IVA-D300 plays DVD Video, Video CD, Audio CD and has a recognized as illegally copied.) built in MP3/WMA decoder.
- Page 10 Disc terminology Title If titles are programmed for the DVD, these are the largest units of division of the information recorded on the disc. Chapter Each Title may also be divided into smaller divisions, called chapters. These can be specific scenes or musical selections. •...
-
Page 11: Getting Started
Using Face Cover An anti-theft face cover is provided with the IVA-D300. Put the face cover onto the IVA-D300 when you leave the vehicle. Be sure to remove the anti-theft face cover when you drive. " #... -
Page 12: Turning Power On Or Off
• The IVA-D300 draws minimal current even when its power switch may cause a malfunction. is turned off. If the switched power (ignition) lead of the IVA-D300 is connected directly to the positive (+) post of the vehicle's battery, the battery may be discharged. If this lead is unswitched, it... -
Page 13: Recalling The Source
% Displays the title input screen (see pages 22,23) Recalling the Source & Changes to the source selection screen (to Step 1 Here is an example explanation for the Radio mode display on how to screen) recall a source. Display may vary depending on the connected devices. Displayed when MobileHub (CXA-B200NK) is connected. -
Page 14: Displaying The Numeric Keypad Input Screen
Displaying the Numeric Keypad Input Screen Display example for shortcut menu screen The numeric keypad input screen is displayed when the DVD mode is selected for searching a title or chapter, and for entering a country code or password for the DVD setup item, and also when selecting a channel number in the XM Radio mode. -
Page 15: Radio
Manual Storing of Station Presets Radio Tune in a desired radio station you wish to store in the preset memory by manual or automatic seek Display example for Radio main screen tuning. 3 4 5 Touch [P1/2] to change the function guide. Touch [MEMORY]. -
Page 16: Cd/Mp3/Wma
The display shows the DVD player mode screen. When a CD/MP3/WMA is inserted into the DISC SLOT of the IVA-D300, with the label side facing up, the unit starts to play the CD/MP3/WMA. • When an optional Alpine CD player is connected, inserting a CD into the optional CD player starts playback automatically. -
Page 17: Repeat Play
Repeat Play About MP3/WMA CAUTION Touch [ ] to play back repeatedly the track currently Except for private use, duplicating audio data (including MP3/ being played. WMA data) or distributing, transferring, or copying it, whether The track (file) will be played repeatedly. for free or for a fee, without permission of the copyright holder is Touch [ ] again and select OFF to deactivate Repeat play. - Page 18 Corresponding File Systems Terminology This device supports discs formatted with ISO9660 Level 1 or Bit rate Level 2. This is the “sound” compression rate specified for encoding. The Under the ISO9660 standard, there are some restrictions to higher the bit rate, the higher the sound quality, but also the larger remember.
-
Page 19: Dvd/Video Cd
IVA-D300 has a built-in DVD player. When an optional Alpine DVD/ • If you try to perform an invalid operation (based video CD/CD player (or DVD changer) is connected to the IVA- on the type of disc being played), the following D300, you can control it from the IVA-D300. -
Page 20: If A Menu Screen Appears
Insert a disc with the label side facing up. The unit starts Direct Menu Operations (DVD only) to play the disc. When an optional Alpine DVD player is connected: 1 Touch the DVD menu directly. Insert a disc into the DVD/video CD/CD player, the player •... -
Page 21: Displaying The Top Menu Screen (Dvd Only)
Numeric Keypad Input Operations (DVD) Displaying the Menu Operation Mode Screen (DVD only) Touch [P1/2] on the DVD mode main screen. The function guide changes. Touch [MENU CONT]. The menu operation mode screen appears. • For further operation, see “If a menu screen appears” on pages 18 and 19. -
Page 22: Finding The Beginnings Of Chapters Or Tracks
Finding the Beginnings of Chapters or Tracks REPEAT The chapter is played repeatedly. During playback, touch [g] or [f]. REPEAT TITLE The title is played repeatedly. The chapter/track switches each time the button is touched, and playback of the selected chapter/track starts. REPEAT OFF The playback returns to normal mode. -
Page 23: Searching Directly By Chapter Or Track Number
Video CDs with multiplex audio Searching Directly by Chapter or Track Number During playback, touch [P1/2]. The function guide changes. Use this function to easily move to the beginnings of the chapters or Touch [AUDIO]. tracks on the disc. The left and right channels will be output as shown in the figure below, each time the button is pressed. -
Page 24: Other Useful Features
Turning defeat ON or OFF Other Useful Features Touch [;] or [:] of DEFEAT to turn it ON or OFF. If you set the defeat to ON, MX is turned OFF and EQ is returned to the initial setting. Adjusting the Audio Adjusting the BASS Level Press the Rotary encoder on the unit. -
Page 25: Disc Search Function
Display example for title input screen ] is displayed if there is a hierarchical list. 2 Select directly by touching [:], and its disc (or folder/ file) is played back. 3 Go through the list pages by touching [ ] or [ ]. 4 Touch [ ] to return to the previous list screen*. -
Page 26: Switching The Function Of The Remote Sensor
In Mode 1 (Wide), the monitor displays a normal picture wider • When you watch the built-in DVD in IVA-D300 (front monitor) and to fit in a wide-screen monitor by evenly stretching out the in the rear monitor, the On Screen display of the rear monitor picture horizontally. -
Page 27: Switching The Visual Source Only (Simultaneous Function)
Switching the Visual Source Only Setting VISUALIZER (Simultaneous Function) This setting is available when the expansion box (VPE-S431) is connected. You can watch the video portion of another source while listening to the current source. Touch [V.SEL] on the main source screen. •... -
Page 28: Monitor Setting
Setting Automatic Opening/Closing of the Monitor Monitor Setting Setting item: MONITOR O/C (OPEN / CLOSE) Setting content: MANUAL / FULL / CLOSE Monitor Setting Operation MANUAL: The monitor is manually opened or closed by pressing OPEN. The monitor automatically opens and closes when FULL: the ignition key is turned to the “ACC”... -
Page 29: Setup
Display example for DVD setup screen Setup Touch [;] or [:] to set a desired language. DVD Setup DVD Setup Operation To display the DVD mode screen: To watch a video source, your vehicle must be parked with the ignition key in the ACC or ON position. To do this, follow Touch [CODE] to display the Touch [ ] or [ ] to turn the procedure below. -
Page 30: Setting Of The Menu Language
1 Touch [CODE]. Use the following procedure to set the digital audio signal output from 2 Touch [ALL DEL] or [BS]. the IVA-D300. Delete the displayed country number. Setting item: DIGITAL OUT MODE 3 Touch the 4-digit country code. - Page 31 Audio output/Optical digital audio output Optical digital audio output Analog audio Disc Audio recording Digital output (when a digital audio output (Ai-NET, format setting processor is connected) RCA output) AUTO DTS Elementary Stream LPCM LPCM Encode 2ch Down mix (48kHz/16bit) Dolby Digital AUTO Dolby Digital...
-
Page 32: Setting The Digital Output
TV monitor (rear monitor) being used. brake once then engage it again. This setting can also be applied for the IVA-D300. 3. When the parking brake is engaged for the second If the rear monitor is not connected, the screen setting is 16:9. -
Page 33: Displaying The Time
Setting the Sound Quality of the Tuner The clock display is turned off or on respectively. The IVA-D300 incorporates the MAX TUNE SQ for the highest quality tuner audio. Moreover, you can choose between 3 settings to Setting item: CLOCK suit your own personal sound preferences and usage. -
Page 34: System Setup
Setting the External Device Interrupt Mode SYSTEM Setup If an Alpine Ai-NET Auxiliary Input Adapter (KCA-801B) is connected to the IVA-D300, an Auxiliary Source will be allowed to System Setup Operation interrupt the current audio source. For example, you can listen to a... -
Page 35: Connecting And Setting The External Expansion Box
This setting is recomended if you view the navigation screen on the rear monitor. However, it is available only when the Alpine navigation system (except RGB navigation) is connected. • Only when an Alpine TV tuner is connected, can you operate the displayed function guide from this unit. -
Page 36: Optical Digital Input Selection For An External Audio Processor
Optical Digital Input Selection for an External Audio Touch [RETURN] to return to the previous screen. Processor Touch [MAIN CONT.] to return to the main source screen that was displayed before the setup operation was Make sure “OPTICAL OUT” is ON in “Setting the Digital Output” started. -
Page 37: Setting Automatic Background Textures
Setting Automatic Background Textures i-Personalize Turn on the Automatic Background Texture Scroll to automatically change background texture. The background texture will change each time the ignition key is turned off and turned back on again (5 Media Xpander Function textures). Setting item: AUTO BACKGROUND Setting the MX mode Setting content: OFF / ON... -
Page 38: Bass Engine Function
Bass Engine Function Touch [;] or [:] of the desired MX mode. The level of the audio source can be adjusted. Setting the Bass Engine MX CD (OFF, CD1 to 3) The large quantity of uncompressed CD data is processed to reproduce the sound with more clarity. The following steps 1 to 6 are common operations to each MX COMPRESS MEDIA (OFF, CMPM1 to 3)/MX XM “Setting item”... -
Page 39: About The Time Correction
To correct this, the IVA-D300 is able to delay the audio signal to the speakers closest to the listener. This effectively creates a perception of increased distance for those speakers. The listener can be placed at an equal distance between the left and right speakers for optimum staging. -
Page 40: Adjusting And Storing/Recalling The Bass Focus
Example 2. Listening Position: All Seats Time Difference Table Adjust the time correction level of each speaker to almost the Time Time same level. Number of Number of Distance Distance Difference Difference Steps Steps cm (inch) cm (inch) (ms) (ms) 1 Sit in the listening position (driver’s seat, etc.) and measure the distance (in meters) between your head 174.9 (68-7/8") -
Page 41: Adjustment And Storing/Recalling Of Time Correction
Example of Bass Focus Setting Storing the Adjusted Contents 1 After entering corrections for the front (left and right) The storing/recalling of time correction operation is performed after speakers in STEP 15, the time difference is 1.5 ms for Step 4 above. both front-left and front-right speakers. -
Page 42: Subwoofer On And Off
Storing the Adjusted Contents VISUAL EQ Following operation is performed after Step 3 above. Visual EQ Setting Operation 4 Touch [MEMORY]. 5 Within 5 seconds, touch any one of preset buttons [P.SET 1] through [P.SET 6] on the BASS ENGINE screen. The following steps 1 to 6 are common operations to each The adjusted contents will be stored on the preset “Setting item”... -
Page 43: Adjusting Color Of Picture
You can adjust the color between MIN (–15) and MAX (+15). When it reaches the minimum or maximum point, the display shows "MIN" You can download data (from Alpine’s website) to a CD-R/CD-RW or or "MAX" respectively. HDD, and download and store the data to the IVA-D300. -
Page 44: Data Downloading
Setting AMP Link (Optional) Data Downloading Adjusting and Storing/Recalling the External Insert the CD-R/CD-RW disc containing the data. Amplifier (Option) • If the optional HDA-5460 is connected, steps 2 to 7 can be performed after the data has downloaded removable hard disc. The MM DRIVER main source screen can then be selected on this unit. -
Page 45: Titling The Amplifier
Recalling the Stored Contents of Amplifier External Audio Processor Adjustment (Optional) 1 Select P-1 or P-2 by touching [;] or [:] of MEMORY READ from the adjustment mode list. When an external audio processor is connected to this unit, you can 2 Touch [READ]. -
Page 46: Adjustment Procedure For Dolby Surround
OFF: Turns off the MX effect of every music source. (Storing all the settings and adjustments made on the ON: Turns on the specified MX mode. IVA-D300 (not only the above settings/adjusts) in the memory) Touch [ ] after setting to ON. -
Page 47: X-Over Adjustment
Touch [;] or [:] of the desired MX mode. Touch a desired adjustment mode. • Music source (such as radio broadcasts and CDs, excluding AM FREQ: Adjust the H.P.F. or L.P.F. cutoff frequency. radio) level can be set. The adjustable bands differ according to the MX CD (OFF, CD 1 to 3) channel (speaker). -
Page 48: Phase Switching
Phase Switching Make sure that the defeat is turned off (page 22). Touch [SYS.] on the main source screen. 5.1ms The SYSTEM selection screen is displayed. 0.5m Touch [i-Personalize]. 2.25m The i-Personalize screen appears. Touch [ ] of A.PROCESSOR. The A.PROC list screen is displayed. Touch [ ] of PHASE. -
Page 49: Parametric Equalizer Adjustments
• When the speaker is set to the “OFF” mode, the parametric Touch [RETURN] to return to the previous screen. equalizer for that speaker cannot be set. Refer to “Setting the Speakers” (page 44). • When the speaker is set to the “OFF” mode, the graphic equalizer •... -
Page 50: Speaker Setup
Speaker Setup Setting of Dolby 5.1ch The PXA-H700 or PXA-H701 can be set according to the playable Check that Defeat mode is off. frequency range of your speakers. Check the playable frequency range of the speakers (not including the Touch [SYS.] on the main source screen. subwoofer) before performing this operation to verify whether the The SYSTEM selection screen appears. -
Page 51: Achieving Powerful High Volume Sound
Achieving powerful high volume sound Adjusting the DVD Level With Dolby Digital, the dynamic range is compressed so that The volume (signal level) for Dolby Digital, Dolby PL II, DTS and powerful sound can be achieved at regular volume levels. This PCM modes can be set. -
Page 52: Using The Pro Logic Ii Mode
Using the Pro Logic II Mode Linear PCM Setting Pro Logic processing can be conducted on the music signals recorded The output when playing discs recorded in linear PCM can be set to 2 on two channels to achieve Dolby Pro Logic II surround sound. For or 3 channels. -
Page 53: Navigation System (Optional)
• When V. SEL is pressed while the Navigation selection mode is being selected in “Setting Visual Mode” (page 33), the navigation If the IVA-D300 is not installed correctly, the driver will be mode will be directly activated. able to watch the TV/Video while driving the vehicle and •... -
Page 54: Changer (Optional)
IVA-D300 if it is Ai-NET compatible. With a CD Changer connected (Versatile Link Terminal), you can connect two changers only. to the Ai-NET input of the IVA-D300, the CD Changer will be controllable from the IVA-D300. In changer mode, touch [CHG SEL] or press... -
Page 55: Hdd Player Operation (Optional)
XM Satellite Radio* is the next generation of audio entertainment, with up to 100 brand-new digital channels. For a small monthly fee, This device is controllable from the unit when Alpine HDD player is subscribers can hear crystal-clear music, sports, news and talk, coast- connected. -
Page 56: Tuning In To Categorized Programs
In the XM mode, touch [;CAT DN] or [CAT UP :] a label directly on the XM Receiver. once to activate the Category mode. It can also be displayed on the screen of the IVA-D300 in the The “CATEGORY” indicator lights. following way. -
Page 57: Displaying The Category/Channel Name Title List
Screen example for channel name search list • When there is an incoming call while the power of the IVA-D300 is OFF, the power of the IVA-D300 turns ON automatically, hands- free call is cut, and the portable telephone call is enabled. -
Page 58: Telephone Reception
To listen to the answer-phone or to input numbers: Telephone Reception 1 In the CONNECT display, touch [10KEY]. The Dial Sending and numeric keypad displays appear. 2 Touch and input a desired number or symbol. When this unit receives a call, the screen is 3 Touch [RTN] to return to the previous screen. -
Page 59: Sms (Short Message Service) Operation
Information Touch [CALL] of a desired addressee on the list. Touch [ ] to start call. To cut the call, touch [ ]. Or the call is About DVDs automatically cut in 5 seconds after finishing. Music CDs and DVDs have grooves (tracks) in which the SMS (Short Message Service) Operation digital data is recorded. -
Page 60: Terminology
The IVA-D300 performs Dolby Digital decoding when it outputs the sound of the source. analog audio signals, it just happens to be 2-channel audio not * The separately sold digital audio processor (PXA-H700, etc.) is... -
Page 61: List Of Language Codes
List of Language Codes (For details, see page 28.) Abbreviation Code Language Abbreviation Code Language Abbreviation Code Language Afar 7369 Interlingue 8278 Kirundi 6565 6566 Abkhazian 7375 Inupiak 8279 Romanian 6570 Afrikaans 7378 Indonesian 8285 Russian 6577 Amharic 7383 Icelandic 8287 Kinyarwanda 6582... -
Page 62: List Of Country Codes
List of Country Codes (For details, see page 28.) Abbreviation Code Country Abbreviation Code Country Abbreviation Code Country 6568 Andorra 6877 Dominica 7573 Kiribati 6569 United Arab Emirates 6879 Dominican Republic 7577 Comoros 6570 Afghanistan 6890 Algeria 7578 Saint Kitts and Nevis 6967 Ecuador 7580... - Page 63 Abbreviation Code Country Abbreviation Code Country Abbreviation Code Country 8069 Peru 8374 Svalbard and Jan Mayen 8487 Taiwan, Province of China 8070 French Polynesia 8375 Slovakia 8490 Tanzania, United Republic of 8071 Papua New Guinea 8376 Sierra Leone 8565 Ukraine 8072 Philippines 8377...
-
Page 64: In Case Of Difficulty
• Connections to the navigation system are incorrect. - Do not use a commercial available lens cleaner disc. - Check the connections with the navigation system and Consult your nearest ALPINE dealer. connect the cables correctly and firmly. Disc playback sound skips without vibration. - Page 65 • Monitor’s parking brake lead is not connected. If the error indication still does not turn off after pressing c for a few times, consult your Alpine dealer. - Connect the monitor’s parking brake lead and set the parking brake.
- Page 66 • The user has selected a Channel Number that does not exist or Check the indication. Insert the magazine again. is not subscribed to. If the magazine cannot be pulled out, consult your Alpine - The unit will revert back to the previously selected channel. dealer.
-
Page 67: Specifications
GENERAL Specifications Power Requirement 14.4 V DC (11–16 V allowable) MONITOR SECTION Operating temperature +32°F to +113°F Screen Size 7.0" (0°C to + 45°C) 18 W RMS × 4* LCD Type Transparent type TN LCD Power Output Operation System TFT active matrix * Primary amplifier ratings per CEA-2006 Standard Number of Picture Elements 336,960 pcs. -
Page 68: Installation And Connections
When connecting the IVA-D300 to the fuse box, make safety-related system), or tanks should NEVER be used for sure the fuse for the intended circuit of the IVA-D300 has the installations or ground connections. Using such parts could appropriate amperage. Failure to do so may result in damage to disable control of the vehicle and cause fire etc. -
Page 69: Installation
IVA-D300. Connect all other leads of the IVA-D300 according to details described in the Connections section. - Page 70 Installing the Tuner Box Install the tuner on the floor with the supplied flange-head tapping screws (M4 × 14). Caution Do not block the unit’s fan or heat sink, thus Flange-head tapping screws preventing air circulation. If blocked, heat will (M4 ×...
- Page 71 • The diagram and the fuse amperage shown above are in the case when IVA-D300 is used individually. • If the switched power (ignition) lead of the IVA-D300 is connected directly to the positive (+) post of the vehicle‘s battery, the IVA-D300 draws some current (several hundred milliamperes) even when its switch is placed in the OFF position and the battery may be discharged.
-
Page 72: Connections (Iva-D300 Wiring Diagram)
Connections (IVA-D300 Wiring Diagram) Antenna IVA-D300 <Monitor> BATT (Yellow) Battery (Black) ILLM To the instrument cluster (Orange) illumination lead REMOTE OUT To remote input lead (White/Brown) IVA-D300 REMOTE IN To remote output lead Tuner BOX (White/Brown) " REVERSE To plus side of the back SUBW. -
Page 73: System Switch
This will allow the backlighting of = Audio Interrupt In Lead (Pink/Black) the IVA-D300 to dim whenever the vehicle‘s lights are turned on. > Parking Brake Lead (Yellow/Blue) 9 Remote Control Output Lead (White/Brown) Connect this lead to the power supply side of the parking Connect this lead to the remote control input lead. -
Page 74: System Example
- Connect the fiber digital input terminal to the DVD. - IVA-D300, DVA-5200, DVA-5205 or DVA-5210 cannot be connected simultaneously when fiber digital is in use. • When the NVA-N751AS is connected for the Navigation System, use the RGB conversion cable KWE-503N (Sold separately). - Page 75 1 RGB Cable (Included with NVE-N852, not included with NVE-N871A) 2 Remote IN/OUT Terminal 3 RGB Input Terminal Connect this to the RGB output terminal of the Navigation System. 4 System Switch When connecting an equalizer or divider using Ai-NET feature, place this switch in the EQ/DIV position.
- Page 76 When Connecting External Equipment To Audio Input terminal IVA-D300 Tuner BOX Rear monitor EQ/DIV (Sold Separately) To Video Input terminal NORM SUBW. PRE IN/OUT REAR FRONT POWER SUPPLY To Video Output terminal Ai-NET REMOTE IN / OUT Back-up camera EXT.OUT...
- Page 77 Connect an expansion box (VPE-S431), DVD Player, DVD Changer or the Touch Panel-compatible Monitor. IVA-D300 Tuner BOX SUBW. PRE IN/OUT REAR FRONT POWER SUPPLY Ai-NET To AUX Input (AUX IN 3) To AUX Input (AUX IN 1) REMOTE IN / OUT Terminals EXT.OUT...
-
Page 82: Limited Warranty
LIMITED WARRANTY ALPINE ELECTRONICS OF AMERICA, INC. AND ALPINE OF CANADA INC. ("Alpine"), are dedicated to quality craftsmanship and are pleased to offer this Warranty. We suggest that you read it thoroughly. Should you have any questions, please contact your Dealer or Alpine at one of the telephone numbers listed below.
