Gigabyte 6OXM7E Series User Manual
Gigabyte 6OXM7E Series User Manual

Gigabyte 6OXM7E Series User Manual

Socket 370 processor motherboard
Table of Contents

Advertisement

Quick Links

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
Model Number:
GA-6OXM7E
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
Jun. 13, 2000
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection
against
harmful
residential
installations.
generates,
uses,
and
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
interference
in
This
equipment
can
radiate
radio

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6OXM7E Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Gigabyte 6OXM7E Series

  • Page 1 FCC Compliance Statement: This equipment has been tested and found to DECLARATION OF CONFORMITY Per FCC Part 2 Section 2. 1077(a) comply with limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These Responsible Party Name: G.B.T. INC. limits are designed to provide reasonable Address: 18305 Valley Blvd., Suite#A LA Puent, CA 91744...
  • Page 2: Declaration Of Conformity

    Declaration of Conformity We, Manufacturer/Importer (full address) G.B.T. Technology Träding GMbH Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-6OXM7E is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive EN 55011...
  • Page 3 6OXM7E Series Socket 370 Processor Motherboard USER'S MANUAL Socket 370 Processor Motherboard REV. 2.0 Second Edition R-20-02-001127...
  • Page 5 How This Manual Is Organized This manual is divided into the following sections: 1) Revision History Manual revision information 2) Item Checklist Product item list 3) Features Product information & specification 4) Hardware Setup Instructions on setting up the motherboard 5) Performance &...
  • Page 7: Table Of Contents

    Table Of Content Revision History Item Checklist Summary of Features 6OXM7E Series Motherboard Layout Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition Performance List P.32 Block Diagram P.33 Suspend to RAM Installation (Optional) P.34 Introduce Dual BIOS (Optional) P.40 Four Speaker &...
  • Page 8: Revision History

    6OXM7E Series Motherboard Revision History Revision Revision Note Date Initial release of the 6OXM7E Series motherboard user’s May.2000 manual. Initial release of the 6OXM7E Series motherboard user’s May.2000 manual. Second release of the 6OXM7E Series motherboard user’s Jun.2000 manual. Third release of the 6OXM7E Series motherboard user’s Jun.2000...
  • Page 9: Item Checklist

    Item Checklist Item Checklist The 6OXM7E Series motherboard Cable for IDE / floppy device Diskettes or CD (IUCD) for motherboard driver & utility 6OXM7E Series user’s manual...
  • Page 10: Summary Of Features

    6OXM7E Series Motherboard Summary Of Features Form Factor 30.5 cm x 21.5 cm ATX SIZE form factor, 4 layers PCB. Motherboard 6OXM7E series includes 6OXM7E, 6OXM7E-1 Socket 370 processor  Intel Pentium !!! 100/133MHz FSB, FC-PGA Intel Celeron 66MHz FSB, FC-PGA...
  • Page 11 Summary of Features BIOS Licensed AWARD BIOS, 4M bit flash ROM Support Dual BIOS (Optional) PS/2 Connector PS/2 keyboard interface and PS/2 mouse interface Additional Features Supports Wake-on-LAN (WOL) STR (Suspend-To-RAM) (Optional) Supports Internal / External modem wake up Includes 3 fan power connectors Poly fuse for keyboard over-current protection Support @BIOS™...
  • Page 12: 6Oxm7E Series Motherboard Layout

    6OXM7E Series Motherboard 6OXM7E Series Motherboard Layout LED1 PS/2 PGA 370 FW82815 JP12 DFP/TV PCI1 AC’97 JP18 JP28 PCI2 ICH2 JP14 FW82801BA Creative 6OXM7E CT5880 PCI3 BAT1 JP26 JP15 PCI4 JP19 JP27 Main Backup BIOS PCI5 BIOS JP24 JP22 PCI6...
  • Page 13: Page Index For Cpu Speed Setup/Connectors/Panel And Jumper Definition

    6OXM7E Series Motherboard Layout Page Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition CPU Speed Setup Connectors Game & Audio Port COM A / COM B / VGA / LPT Port USB Connector P.10 PS/2 Keyboard & PS/2 Mouse Connector P.10...
  • Page 14 6OXM7E Series Motherboard JP21 (Top Block Lock) P.26 JP5 (Over Voltage CPU Speed up) P.27 JP6 (DIMM Over Voltage) [Optional] P.27 JP12 (Internal Buzzer Connector) [Optional] P.28 JP14 (Timeout Reboot Function) P.28 JP15 (Safe mode / Recovery / Normal) P.29 JP19 (Front USB Device Wake up Selection) P.29...
  • Page 15: Cpu Speed Setup

    CPU Speed Setup CPU Speed Setup The system bus frequency can be switched at 66MHz, 100MHz, 133MHz and Auto by adjusting JP10/JP11/JP25 (See Figure 1). The CPU Frequency is control by BIOS. The CPU speed must match with the frequency RATIO. It will cause system hanging up if the frequency RATIO is higher than that of CPU.
  • Page 16: Connectors

    6OXM7E Series Motherboard Connectors Game & Audio Port Game Port MIC In Line Out 1 Line In Line Out 1: Line Out or SPDIF (The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby digital decoder).
  • Page 17: Usb Connector

    Connectors USB Connector Pin No. Definition USB V0 USB D0- USB D0+ USB V1 1 2 3 4 USB D1- USB D1+ PS/2 Keyboard & PS/2 Mouse Connector PS/2 Mouse PS/2 Keyboard PS/2 Mouse/ Keyboard Pin No. Definition Data VCC (+5V) Clock...
  • Page 18: J1: Cpu Fan

    6OXM7E Series Motherboard J1: CPU Fan Pin No. Definition +12V SENSE J2: Power Fan Pin No. Definition +12V SENSE...
  • Page 19: J14: System Fan

    Connectors J14: System Fan Pin No. Definition +12V SENSE ATX Power Pin No. Definition 3,5,7,13,15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB stand by+5V PS-ON(Soft On/Off)
  • Page 20: Jp13: Ir/Cir

    6OXM7E Series Motherboard JP13: IR/CIR Pin No. Definition IRRX IRTX CIRRX Floppy Port Red Line...
  • Page 21: Ide 1(Primary)/ Ide 2(Secondary) Port

    Connectors IDE1 (Primary), IDE2 (Secondary) Port IDE 2 IDE 1 Red Line J13: Ring Power On (Internal Modem Card Wake Up) Pin No. Definition Signal...
  • Page 22: J12: Wake On Lan

    6OXM7E Series Motherboard J12: Wake On LAN Pin No. Definition +5V SB Signal J7: TEL: The connector is for Modem with internal voice connector Pin No. Definition Signal-In Signal-Out...
  • Page 23: J6: Aux_In

    Connectors J6: AUX_IN Pin No. Definition AUX-L AUX-R J5: CD Audio Line In Pin No. Definition CD-L CD-R...
  • Page 24: Jp7: Str Led Connector & Led1: Dimm Led (Optional)

    6OXM7E Series Motherboard JP9: SPDIF(The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby digital decoder.)[Optional] Pin No. Definition SPDIF OUT JP7: STR LED Connector & LED1: DIMM LED (Optional)
  • Page 25: Cn9 (Front Usb Port)[Optional]

    Connectors CN9: Front USB Port Pin No. Definition USB D2- USB D2+ USB D3+ USB D3- J10: Extra SMBUS Pin No. Definition SMB CLK SMB DATA...
  • Page 26: Jp27 (Scr)

    6OXM7E Series Motherboard JP27: SCR: Smart Card Reader Pin No. Definition 2,3,4,8,13 5,6,10,12 DATA Clock 9,14 CN8: DFP/TV Out Connector Use only for Gigabyte Digital Flat Panel/TV-Out Daughter card (GA-DFP-x).
  • Page 27: J15: Ia Port (Optional)

    Connectors J15: IA Port (Optional) Pin No. Definition Giga-byte web-site Internet Finance Entertainment Shopping Searching People E-mail Play-pause Forward Rewind Eject Stop Mute Mic Volume up Mic Volume down Speaker Volume up Speaker Volume down Ground CN7 :Front Audio (Optional) Pin No.
  • Page 28: Jp28: For 6 Channels Audio Card Connector (Optional)

    6OXM7E Series Motherboard JP28: For 6 Channels Audio Card Connector (Optional) Pin No. Definition Signal Signal +3.3V Signal +12V Signal Signal Signal Signal...
  • Page 29: Panel And Jumper Definition

    Panel and Jumper Definition Panel And Jumper Definition J11: For 2x11 Pins Jumper GN (Green Switch) Open: Normal Operation Close: Entering Green Mode GD (Green LED) Pin 1: LED anode(+) Pin 2: LED cathode( ) HD (IDE Hard Disk Active LED) Pin 1: LED anode(+) Pin 2: LED cathode( ) SPK (Speaker Connector)
  • Page 30: Jp18: Clear Cmos Function

    6OXM7E Series Motherboard JP18: Clear CMOS Function Pin No. Definition 1-2 close Clear CMOS 2-3 close Normal (Default) JP4: STR Enable (Optional) Pin No. Definition Open STR Disabled (Default) Close STR Enabled...
  • Page 31: Jp26: Onboard Sound Function Selection (Optional)

    Panel and Jumper Definition JP26: Onboard Sound Function Selection (Optional) Pin No. Definition Enabled Onboard Sound 1-2 close (Default) 2-3 close Disable Onboard Sound JP3: PS/2 Keyboard Power On Pin No. Definition 1-2 close PS/2 Keyboard Power on Enabled 2-3 close Normal (Default)
  • Page 32: Jp1: Rear Usb Device Wake Up Selection

    6OXM7E Series Motherboard JP1: Rear USB Device Wake up Selection (USB Connector CN2) Pin No. Definition Enabled Rear USB Device 1-2 close Wake up 2-3 close Normal (Default) (If you want to use “USB KB/Mouse Wake from S3” function, you have to set the BIOS setting “USB KB/Mouse Wake from S3”...
  • Page 33: Jp20: Fwh Flash Write Protection

    Panel and Jumper Definition JP20: FWH Flash Write Protection Pin No. Definition Open Normal (Default) Close Write Protection Please set Jumper JP20 to “Open” to enabled BIOS write function when you update new BIOS or new device. JP21: Top Block Lock Pin No.
  • Page 34: Jp5 (Over Voltage Cpu Speed Up)

    6OXM7E Series Motherboard JP5: Over Voltage CPU Speed Up (Magic Booster) (When JP5 set “Close”, CPU Voltage is rising 10%) Pin No. Definition Close Turbo [Voltage enhance 10%] for over clock use Open Normal (Default) JP6: DIMM Over Voltage (Optional) Pin No.
  • Page 35: Jp12: Internal Buzzer Connector (Optional)

    Panel and Jumper Definition JP12: Internal Buzzer Connector (Optional) Pin No. Definition Open Internal Buzzer Disabled Close Internal Buzzer Enabled (Default) JP14: Timeout Reboot Function Pin No. Definition Open Timeout Reboot Close No Reboot on Timeout...
  • Page 36: Jp15: Safe Mode/Recovery/Normal

    6OXM7E Series Motherboard JP15: Safe mode/Recovery/Normal Pin No. Definition 1-2close Normal (Default) 2-3close Safe mode 1-2-3open Recovery JP19:Front USB Device Wake up Selection (USB Port CN9) Pin No. Definition Enabled Front USB Device 1-2 close Wake up 2-3 close Normal (Default) (If you want to use “USB KB/Mouse Wake from S3”...
  • Page 37: Jp23: Pci/Agp 3Vaux

    Panel and Jumper Definition JP23: PCI/AGP 3VAUX Pin No. Definition Open Disabled PCI/AGP 3VAUX Function Close Enabled PCI/AGP 3VAUX (Default) JP24: CNR Selection (Optional) Pin No. Definition 1-2close CNR Secondary CNR Primary 2-3close AC’97 Disabled (Default) (Disabled Onboard CODEC)
  • Page 38: Bat1: Battery

    6OXM7E Series Motherboard BAT1: Battery CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.
  • Page 39: Performance List

    Performance List Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) ®...
  • Page 40: Block Diagram

    6OXM7E Series Motherboard Block Diagram Socket 370 Display 66/100/133 MHz Host Bus 66/100/133MHz 66/100/133 MHz DFP/TV Intel 3.3V SDRAM FW82815 100/133 MHz AGP 2X/4X /Display Cache 14.318/33/48/66 MHz Interface 9250-25 6 PCI PCI Bus 33MHz ICH2 ATA66/100 82801BA IDE Channels AC’97 Link...
  • Page 41: Suspend To Ram Installation (Optional)

    Suspend to RAM Installation Suspend To RAM Installation (Optional) A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 42 6OXM7E Series Motherboard Step 2: (If you want to use STR Function, please set jumper JP4 Closed.) Pin No. Definition Open STR Disabled (Default) Close STR Enabled Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter ACPI Suspend BIOS Setup.
  • Page 43 Suspend to RAM Installation A.3 How to put your system into STR mode? There are two ways to accomplish this: Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” Choose the “Stand by”...
  • Page 44 6OXM7E Series Motherboard Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 45 Suspend to RAM Installation C. Select the “Advanced” tab and “Standby” mode in Power Buttons. D. Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button. A.4 How to recover from the STR sleep mode? There are seven ways to “wake up”...
  • Page 46 6OXM7E Series Motherboard A.5 Notices: In order for STR to function properly, several hardware and software requirements must be satisfied: A. Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current).
  • Page 47: Introduce Dual Bios (Optional)

    Introduce Dual BIOS Introduce Dual BIOS (Optional) What is Dual BIOS Technology? Dual BIOS means that there are two system BIOS (ROM) on the motherboard, one is the Main BIOS and the other is Backup BIOS. Under the normal circumstances, the system works on the Main BIOS.
  • Page 48 6OXM7E Series Motherboard b. Dual BIOS Utility Dual BIOS Utility V6.60.g.01K (C) 1999, Gigabyte Technology Co., LTD. Wide Range Protection :Disabled Halt On BIOS Defects :Disabled Auto Recovery :Enabled Boot From :Main BIOS BIOS Recovery :Main to Backup F3: Load Default...
  • Page 49 Introduce Dual BIOS Halt On BIOS Defects : Disabled(Default), Enabled If the BIOS occurs a checksum error or the Main BIOS occurs a WIDE RANGE PROTECTION error and Halt On BIOS Defects set to Enable, the PC will show messages on the boot screen, and the system will pause and wait for the user’s instruction.
  • Page 50 DualBIOS Technology FAQ GIGABYTE Technology is pleased to introduce DualBIOS technology, a hot spare for your system BIOS. This newest “Value-added” feature, in a long series of innovations from GIGABYTE, is available on GA-6OXM7E Series motherboard. Future GIGABYTE motherboards will also incorporate this innovation.
  • Page 51 Introduce Dual BIOS I. Q: What is DualBIOS technology? Answer: DualBIOS technology is a patented technology from Giga-Byte Technology. The concept of this technology is based on the redundancy and fault tolerance theory. DualBIOS technology simply means there are two system BIOSes (ROM) integrated onto the motherboard. One is a main BIOS, and the other is a backup BIOS.
  • Page 52 6OXM7E Series Motherboard III. Q: How does DualBIOS technology work? Answer: 1. DualBIOS technology provides a wide range of protection during the boot up procedure. It protects your BIOS during system POST, ESCD update, and even all the way to PNP detection/assignment.
  • Page 53 Introduce Dual BIOS 2. During or after a BIOS upgrade, if DualBIOS detects that the main BIOS is corrupt, the backup BIOS will take over the boot-up process automatically. Moreover, it will verify the main and backup BIOS checksums when booting-up. DualBIOS technology examines the checksum of the main and backup BIOS while the system is powered on to guarantee your BIOS operates properly.
  • Page 54: Four Speaker & Spdif Introduction (Optional)

    6OXM7E Series Motherboard Four Speaker & SPDIF Introduction (Optional) Four Speaker Introduction What is Four Speaker? The Creative CT5880 audio chip can support 4 speaker output, if you select “Four speaker” out, Line in will be change to another line out.
  • Page 55 Four Speaker & SPDIF Introduction c. Click “Four speaker” item. Four Speaker Application The four speaker function will only support in application software that use Microsoft DirectX and Creative EAX. For example, the game titles, software DVD player and MP3 player. Those software support Microsoft DirectX, so they can support four speaker output.
  • Page 56 6OXM7E Series Motherboard SPDIF Introduction What is SPDIF? The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby digital decoder. How to use SPDIF? a. Press your mouse right button in “My Computer” and then select the “Properties” item.
  • Page 57 Four Speaker & SPDIF Introduction c. Press “Sound, video and game controllers” item and then select the “Creative Sound Blaster PCI128” item. d. Press “Settings” item and then select the “Output Mode” item.
  • Page 58 6OXM7E Series Motherboard e. Click “Digital” item, Line Out will be change to SPDIF Out. f. Recommend you to select “Autosense”, it will auto detect the audio jack you plug in to Line Out is mono or stereo, and then change to SPDIF Out or Speaker out automatically.
  • Page 59: Bios Tm Introduction

    ™ With the help of “@BIOS ’, BIOS updating is no more than a click. Besides, no matter which mainboard you are using, if it’s a Gigabyte’s product*, ™ @BIOS help you to maintain the BIOS. This utility could detect your correct mainboard model and help you to choose the BIOS accordingly.
  • Page 60 Click “Advanced Mode” to enjoy “sport drive” class overclocking. In “Advanced Mode”, one can change the system bus speed in small increments to get ultimate system performance. And no matter which mainboard is used, if it’s a Gigabyte’s ™ product*, EasyTuneIII helps to perform the best of system.
  • Page 61: Easytuneiii Tm Introduction

    ™ EasyTund III Introduction This wonderful software is now free bundled in Gigabyte motherboard attached ™ driver CD. Users may make a test drive of “EasyTuneIII ” to find out more amazing features by themselves. For further technical information, please link to: http://www.gigabyte.com.tw...
  • Page 62: Memory Installation

    6OXM7E Series Motherboard Memory Installation The motherboard has 4 dual inline memory module (DIMM) sockets support 6 banks. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch.
  • Page 63: Page Index For Bios Setup

    BIOS Setup Page Index for BIOS Setup Page Main Menu P.58 Standard CMOS Features P.61 Advanced BIOS Features P.65 Advanced Chipset Features P.68 Integrated Peripherals P.74 Power Management Setup P.80 PnP/ PCI Configurations P.84 PC Health Status P.86 Frequency / Voltage Control P.88 Load Fail-Safe Defaults P.89...
  • Page 64: Entering Setup

    6OXM7E Series Motherboard BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off.
  • Page 65: Main Menu

    BIOS Setup GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 66 6OXM7E Series Motherboard Standard CMOS Features This setup page includes all the items in standard compatible BIOS. Advanced BIOS Features This setup page includes all the items of Award special enhanced features. Advanced Chipset Features This setup page includes all the items of chipset special features.
  • Page 67 BIOS Setup Save & Exit Setup Save CMOS value settings to CMOS and exit setup. Exit Without Saving Abandon all CMOS value changes and exit setup.
  • Page 68: Standard Cmos Features

    6OXM7E Series Motherboard Standard CMOS Features The items in Standard CMOS Setup Menu (Figure 3) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp>...
  • Page 69 BIOS Setup Time The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. IDE Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer.
  • Page 70 6OXM7E Series Motherboard Floppy 3 Mode Support (for Japan Area) Disabled Normal Floppy Drive. Drive A Drive A is 3 mode Floppy Drive. Drive B Drive B is 3 mode Floppy Drive. Both Drive A & B are 3 mode Floppy Drives.
  • Page 71 BIOS Setup Memory The category is display-only which is determined by POST (Power On Self Test) of the BIOS. Base Memory The POST of the BIOS will determine the amount of base (or conventional) memory installed in the system. The value of the base memory is typically 512 K for systems with 512 K memory installed on the motherboard, or 640 K for systems with 640 K or more memory installed on the motherboard.
  • Page 72: Advanced Bios Features

    6OXM7E Series Motherboard Advanced BIOS Features CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software Advanced BIOS Features Virus Warning Disabled Item Help BIOS Flash Protection Disabled Menu Level 4 Processor Number Feature Enabled First Boot Device Floppy Allows you to...
  • Page 73 BIOS Setup BIOS Flash Protection Enabled Enabled BIOS Flash Protection. Disabled Disabled BIOS Flash Protection. (Default Value) Processor Number Feature This item will show up when you install the Pentium !!! Processor. ® Enabled Pentium !!! Processor Number Feature. (Default value) ®...
  • Page 74 6OXM7E Series Motherboard Security Option This category allows you to limit access to the system and Setup, or just to Setup. System The system can not boot and can not access to Setup page will be denied if the correct password is not entered at the prompt.
  • Page 75: Advanced Chipset Features

    BIOS Setup Advanced Chipset Features CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software Advanced Chipset Features Top Performance Disabled Item Help SDRAM Timing Control Auto Menu Level 4 SDRAM CAS Latency Time SDRAM Cycle Time Tras/Trc SDRAM RAS-to-CAS Delay SDRAM RAS Precharge Time Delayed Transaction Enabled On-Chip Video Window Size...
  • Page 76 6OXM7E Series Motherboard Top Performance If you wish to maximize the performance of your system, set “Top Performance” as “Enabled”. Disabled Disabled this function. (Default Value) Enabled Enabled Top Performance function. SDRAM Timing Control Auto Set SDRAM Timing Control to Auto. (Default value) Manual Set SDRAM Timing Control to Manual.
  • Page 77 BIOS Setup Display Cache Frequency 100MHz Set Display Cache Frequency to 100MHz. 133MHz Set Display Cache Frequency to 133MHz. (Default value) System Memory Frequency Auto Set System Memory Frequency to Auto. (Default value) 100MHz Set System Memory Frequency to 100MHz. 133MHz Set System Memory Frequency to 133MHz.
  • Page 78 6OXM7E Series Motherboard 1.7x Set SMAA#[7:4] (Rows 0/1) to 1.7x. 1.0x Set SMAA#[7:4] (Rows 0/1) to 1.0x. SMAB#[7:4] (Rows 2/3) Default Set SMAB#[7:4] (Rows 2/3) to Default. (Default value) 2.7x Set SMAB#[7:4] (Rows 2/3) to 2.7x. 1.7x Set SMAB#[7:4] (Rows 2/3) to 1.7x.
  • Page 79 BIOS Setup SCS[4]# (Row 4) Default Set SCS[4]# (Row 4) to Default. (Default value) 1.7x Set SCS[4]# (Row 4) to 1.7x. 1.0x Set SCS[4]# (Row 4) to 1.0x. SCS[5]# (Row 5) Default Set SCS[5]# (Row 5) to Default. (Default value) 1.7x Set SCS[5]# (Row 5) to 1.7x.
  • Page 80 6OXM7E Series Motherboard SCKE[5]# (Row 5) Default Set SCKE[5]# (Row 5) to Default. (Default value) 2.7x Set SCKE[5]# (Row 5) to 2.7x. 1.7x Set SCKE[5]# (Row 5) to 1.7x.
  • Page 81: Integrated Peripherals

    BIOS Setup Integrated Peripherals CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software Integrated Peripherals On-Chip Primary PCI IDE Enabled Item Help On-Chip Secondary PCI IDE Enabled Menu Level 4 IDE Primary Master PIO Auto IDE Primary Slave PIO Auto IDE Secondary Master PIO Auto IDE Secondary Slave PIO Auto...
  • Page 82 6OXM7E Series Motherboard On-Chip Primary PCI IDE Enabled Enable onboard 1st channel IDE port. (Default value) Disabled Disable onboard 1st channel IDE port. On-Chip Secondary PCI IDE Enabled Enable onboard 2nd channel IDE port. (Default value) Disabled Disable onboard 2nd channel IDE port.
  • Page 83 BIOS Setup IDE Secondary Master UDMA Auto BIOS will automatically detect the IDE HDD Accessing mode. (Default value) Disabled Disable UDMA function. IDE Secondary Slave UDMA Auto BIOS will automatically detect the IDE HDD Accessing mode. (Default value) Disabled Disable UDMA function. USB Controller Enabled Enable USB Controller.
  • Page 84 6OXM7E Series Motherboard IDE HDD Block Mode Enabled Enable IDE HDD Block Mode. (Default value) Disabled Disable IDE HDD Block Mode. POWER ON by Keyboard Password Enter from 1 to 5 characters to set the Keyboard Power On Password. Disabled Disabled this function.
  • Page 85 BIOS Setup UART Mode Select (This item allows you to determine which Infra Red(IR) function of Onboard I/O chip) ASKIR Set onboard I/O chip UART to ASKIR Mode. IrDA Set onboard I/O chip UART to IrDA Mode. Set onboard I/O chip UART to SCR Mode. Normal Set onboard I/O chip UART to Normal Mode.
  • Page 86 6OXM7E Series Motherboard Midi Port IRQ Set 5 for Midi Port IRQ. Set 10 for Midi Port IRQ. (Default value) CIR Port Address Disabled Disabled this function. (Default Value) Set CIR Port Address to 310. Set CIR Port Address to 320.
  • Page 87: Power Management Setup

    BIOS Setup Power Management Setup CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software Power Management Setup ACPI Suspend Type S1(PowerOn suspend) Item Help Video Off Method DPMS Menu Level 4 Suspend Type Stop Grant MODEM Use IRQ Suspend Mode Disabled HDD Power Down Disabled Soft-Off by PWR-BTTN...
  • Page 88 6OXM7E Series Motherboard Video off Method V/H SYNC+Blank BIOS will turn off V/H-SYNC when gets into Green mode for Green monitor power saving. Blank Screen BIOS will only black monitor when gets into Green mode. DPMS BIOS will use DPMS Standard to control VGA card. (The Green type VGA card will turn off V/H-SYNC automatically.)
  • Page 89 BIOS Setup Power LED in Suspend Blinking Set Power LED in Suspend at Blinking mode. (Default value) Set Power LED in Suspend at On mode. Off/Dual Set Power LED in Suspend at Off/Dual color mode. Wake-Up by PCI card Disabled Disabled this function.
  • Page 90 6OXM7E Series Motherboard Resume by Alarm You can set “Resume by Alarm” item to Enabled and key in date/time to power on system. Disabled Disable this function. (Default value) Enabled Enable alarm function to POWER ON system. If the default value is Enabled.
  • Page 91: Pnp/Pci Configurations

    BIOS Setup PnP/PCI Configurations CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software PnP/PCI Configurations Reset Configuration Data Disabled Item Help Menu Level 4 Resources Controlled By Auto (ESCD) X IRQ Resources Press Enter When resources are controlled manually, assign each system PCI/VGA Palette Snoop Disabled interrupt a type,...
  • Page 92 6OXM7E Series Motherboard IRQ ( 3,4,5,7,9,10,11,12,15 ) PCI Device The resource is used by PCI device. Reserved Set the resource to reserved. PCI/VGA Palette Snoop Enabled For having Video Card on ISA Bus and VGA Card on PCI Bus. Disabled...
  • Page 93: Pc Health Status

    BIOS Setup PC Health Status CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software PC Health Status Reset Case Open Status Disabled Item Help Case Opened Menu Level 4 VCORE 1.600 V VGTL 1.424 V VCC3 3.264 V + 5V 5.053 V +12V 12.160V - 12V...
  • Page 94 6OXM7E Series Motherboard CPU FAN / Power FAN / System FAN Speed (RPM) Detect Fan speed status automatically. CPU Temperature Select ( C / F) 65 C / 149 F Monitor CPU Temp. at 65 C / 149 F. 70 C / 158 F Monitor CPU Temp.
  • Page 95: Frequency/Voltage Control

    BIOS Setup Frequency/Voltage Control CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software Frequency/Voltage Control Auto Detect DIMM/PCI Clk Disabled Item Help CPU Clock Ratio Menu Level 4 Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults Figure 10: Frequency/Voltage Control Auto Detect DIMM/PCI Clk Disabled...
  • Page 96: Load Fail-Safe Defaults

    6OXM7E Series Motherboard Load Fail-Safe Defaults CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features 4 Frequency/Voltage Control 4 Advanced BIOS Features Load Fail - Safe Defaults 4 Advanced Chipset Features Load Optimized Defaults 4 Integrated Peripherals...
  • Page 97: Load Optimized Defaults

    BIOS Setup Load Optimized Defaults CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features 4 Frequency/Voltage Control 4 Advanced BIOS Features Load Fail-Safe Defaults 4 Advanced Chipset Features Load Optimized Defaults 4 Integrated Peripherals Set Supervisor Password 4 Power Management Setup Set User Password 4 PnP/PCI Configurations...
  • Page 98: Set Supervisor / User Password

    6OXM7E Series Motherboard Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features...
  • Page 99: Save & Exit Setup

    BIOS Setup Save & Exit Setup CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software 4Standard CMOS Features 4Frequency/Voltage Control 4Advanced BIOS Features Load Fail-Safe Defaults 4Advanced Chipset Features Load Optimized Defaults 4Integrated Peripherals Set Supervisor Password 4Power Management Setup Set User Password 4PnP/PCI Configurations SAVE to CMOS and EXIT (Y/N)? Y Save &...
  • Page 100: Exit Without Saving

    6OXM7E Series Motherboard Exit Without Saving CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features 4 Frequency/Voltage Control 4 Advanced BIOS Features Load Fail-Safe Defaults 4 Advanced Chipset Features Load Optimized Defaults 4 Integrated Peripherals Set Supervisor Password...
  • Page 101: Appendix

    Appendix Appendix Appendix A: Intel 815 Chipsets Driver Installation A. Windows 9x INF Update Utility Insert the support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the setup screen. 1.Click “Windows 9x INF Update Utility”...
  • Page 102 6OXM7E Series Motherboard B: Intel 815 Chipsets VGA Graphics Driver Installation Insert the support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the setup screen. 1.Click “Intel 815 Chipsets VGA Graphics Driver”...
  • Page 103 Appendix C. Intel Ultra ATA Storage Driver Installation Insert the support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the setup screen. 1.Click “Intel Ultra ATA Storage Driver”...
  • Page 104 6OXM7E Series Motherboard 6.Click “Finish” to restart computer.
  • Page 105 Appendix Appendix B: Creative Sound Driver Installation (Optional) Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. Press “Audio” icon. 2.Click “OK”. 1.Click “Creative CT5880 Sound Driver”.
  • Page 106 6OXM7E Series Motherboard 7.Click “Next”. 8.Click “Finish” to restart computer.
  • Page 107 Appendix Appendix C: SigmaTel AC’97 Audio Driver Installation (Optional) Insert the support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the setup screen. Press “Audio” icon. 1.Click “SigmaTel AC’97 Audio Driver”.
  • Page 108 6OXM7E Series Motherboard Appendix D: EasyTuneIII Setup Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. Press “tool” icon. 1.Click “EasyTuneIII Setup”...
  • Page 109 Appendix 6.Click “Finish” to restart computer.
  • Page 110 6OXM7E Series Motherboard Appendix E: BIOS Flash Procedure BIOS update procedure: If your OS is Win9X, we recommend that you used Gigabyte @BIOS ™ Program to flash BIOS. Click “Tool”. Click “@BIOS Writer v1.05a”. Click “ ”. Click Here. Methods and steps: I.
  • Page 111 In method I, if the BIOS file you need cannot be found in @BIOS ™ server, please go onto Gigabyte's web site for downloading and updating it according to method II. d. Please note that any intercorruption during updating will cause system unbooted...
  • Page 112 Please check your BIOS vendor (AMI or AWARD), your motherboard name and PCB version on the motherboard. Format a bootable system floppy diskette by the command “format a:/s” in command mode. Visit the Gigabyte website at http:// www.gigabyte.com.tw ,Select the BIOS file you need and download it to your bootable floppy diskette.
  • Page 113 Appendix Appendix F: Issues To Beware Of When Installing CNR Please use inverse CNR card like the one in order to avoid mechanical problem. (See Figure A) PCI Slot Figure A: Inverse CNR Card (Default)
  • Page 114 6OXM7E Series Motherboard Appendix G: Issues To Beware Of When Installing GA-AIMM Card (Optional) Install: 1.Insert the card at an angle as shown 2.Push the card down as per picture below. below. Push the card forward a little making sure it’s tight.
  • Page 115 Appendix Appendix H: Acronyms Acronyms Meaning ACPI Advanced Configuration and Power Interface POST Power-On Self Test Local Area Network Extended Capabilities Port Advanced Power Management Direct Memory Access Megahertz ESCD Extended System Configuration Data Central Processing Unit Symmetric Multi-Processing Universal Serial Bus Operating System Error Checking and Correcting Integrated Dual Channel Enhanced...
  • Page 116 6OXM7E Series Motherboard Acronyms Meaning Peripheral Component Interconnect RIMM Rambus in-line Memory Module Dual Retention Mechanism Industry Standard Architecture Memory Translator Hub CRIMM Continuity RIMM...
