6oxc series socket 370 processor motherboard
Table of Contents

Advertisement

Quick Links

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
GA-6OXC
Model Number:
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
Nov. 22, 2000
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection
against
harmful
residential
installations.
generates,
uses,
and
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
interference
in
This
equipment
can
radiate
radio

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GA-6OXC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gigabyte GA-6OXC

  • Page 1 Product Name: Mother Board generates, GA-6OXC Model Number: frequency energy, and if not installed and used Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), in accordance with the instructions, may cause...
  • Page 2: Declaration Of Conformity

    EN 60335 Safety of household and similar electrical appliances Manufacturer/Importer Date: Nov. 22, 2000 (Stamp) (full address) GA-6OXC EN 61000-3-2* Disturbances in supply systems caused EN60555-2 by household appliances and similar electrical equipment “Harmonics” EN61000-3-3* Disturbances in supply systems caused...
  • Page 3 6OXC Series Socket 370 Processor Motherboard USER'S MANUAL Socket 370 Processor Motherboard REV. 1.0 First Edition R-10-01-001113...
  • Page 5 How This Manual Is Organized This manual is divided into the following sections: 1) Revision History 2) Item Checklist 3) Features 4) Hardware Setup 5) Performance & Block Diagram 6) Suspend to RAM 7) Four Speaker & SPDIF 8) @ BIOS &...
  • Page 7: Table Of Contents

    Table Of Content Revision History Item Checklist Summary of Features 6OXC Series Motherboard Layout Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition Performance List Block Diagram Suspend to RAM Installation (Optional) Introduce Dual BIOS (Optional) Four Speaker & SPDIF Introduction (Optional) @ BIOS Introduction EasyTuneIII...
  • Page 8: Revision History

    6OXC Series Motherboard Revision History Revision Revision Note Initial release of the 6OXC Series motherboard user’s manual. The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein. Third-party brands and names are the property of their respective owners.
  • Page 9: Item Checklist

    Item Checklist Item Checklist The 6OXC Series motherboard Cable for IDE / floppy device Diskettes or CD (IUCD) for motherboard driver & utility 6OXC Series user’s manual...
  • Page 10: Summary Of Features

    6OXC Series Motherboard Summary Of Features Form Factor 30.5 cm x 21.5 cm ATX Size form factor, 4 layers PCB Motherboard 6OXC series includes 6OXC, 6OXC-1 Socket 370 processor Intel Pentium Intel Celeron L2 cache in CPU (Depend on CPU) Chipset Intel 815EP HOST / AGP / SDRAM Controller 82801AA I/O Controller Hub (ICH)
  • Page 11 On-Board Sound Creative CT5880 sound (Optional) AC’97 CODEC (Optional) Line In / Line Out / Mic In / AUX In / CD In / TEL / SPDIF/Game Port / Four Speaker (Optional) PS/2 Connector PS/2 keyboard interface and PS/2 mouse interface BIOS Licensed AWARD BIOS, 2M bit flash ROM Support Dual BIOS (Optional)
  • Page 12: 6Oxc Series Motherboard Layout

    6OXC Series Motherboard 6OXC Series Motherboard Layout PS/2 PGA 370 JP29 JP30 PCI1 AC97 JP28 PCI2 Creative CT5880 PCI3 JP16 PCI4 IT8712 PCI5 JP22 PCI6 JP24 JP23 FW82815EP RTM560-25 ICH82801 BAT1 JP18 JP19 Main Backup BIOS BIOS W81181D LED1...
  • Page 13: Page Index For Cpu Speed Setup/Connectors/Panel And Jumper Definition

    Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition CPU Speed Setup Connectors ATX Power COM A / COM B / LPT Port CN7 (Front Audio) [Optional] CN9 (Front USB Port) [Optional] CN12 (SCR) Floppy Port Game & Audio Port [Optional] IDE 1(Primary)/ IDE 2(Secondary) Port J1 (CPU Fan) J2 (Power Fan)
  • Page 14 6OXC Series Motherboard JP16 (Onboard Sound Function Selection) [Optional] JP18 (Clear CMOS Function) JP19 (Front USB Device Wake up Selection) [Optional] JP20 (FWH Flash Write Protection) JP21 (Top Block Lock) JP22 (Case Open) JP23 (PCI/AGP 3VAUX) JP24 (AMR Selection) [Optional] JP28 (On board CODEC Function Selection) [Optional] JP29 (SPDIF Function Selection) [Optional] JP30 (Front MIC Selection) [Optional]...
  • Page 15: Cpu Speed Setup

    CPU Speed Setup The system bus speed is selectable at 55~153MHz. The user can select the system bus speed by DIP switch SW1. SW1: SDRAM Auto Auto 55.00 82.50 60.00 90.00 66.80 100.20 68.33 102.50 70.00 105.00 72.00 108.00 75.00 112.50 77.00 115.50...
  • Page 16 6OXC Series Motherboard SDRAM 150.00 112.50 153.33 115.00 Auto Configuration: SDRAM The following setting is suggested while using 133MHz FSB CPU with 100MHz system memory: SDRAM 133.70 100.28 Note: Please set the CPU host frequency in accordance with your processor’s specifications.
  • Page 17: Connectors

    Connectors ATX Power COM A / COM B / VGA / LPT Port Pin No. Definition 3,5,7,13,15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB stand by+5V PS-ON(Soft On/Off) LPT Port COM A COM B Connectors...
  • Page 18: Cn7: Front Audio (Optional)

    6OXC Series Motherboard CN7: Front Audio (Optional) If the user do not need to use Front Audio connector, please set jumper 11-12 close & 13-14 close. CN9: Front USB Port (Optional) Pin No. Definition Incase speaker (R) Incase speaker (L) 3,4,5,6, 10,15 +12V...
  • Page 19: Cn12 (Scr)

    CN12: SCR: Smart Card Reader Floppy Port Connectors Pin No. Definition SCRFET SCRRST SCRCLK SCRIO SCRPRES Red Line...
  • Page 20: Game & Audio Port [Optional]

    6OXC Series Motherboard Game & Audio Port (Optional) Line Out 1: Line Out or SPDIF (The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby digital decoder). In general, Line Out 1 is normally Line Out, when it output digital signal, it will be change to SPDIF Out automatically (see page 50 for more information).
  • Page 21: J1: Cpu Fan

    J1: CPU Fan J2: Power Fan Connectors Pin No. Definition +12V SENSE Pin No. Definition +12V SENSE...
  • Page 22: J5: Cd Audio Line In (Optional)

    6OXC Series Motherboard J5: CD Audio Line In (Optional) J6: AUX_IN(Optional) Pin No. Definition CD-L CD-R Pin No. Definition AUX-L AUX-R...
  • Page 23: J7 (Tel) [Optional]

    J7: TEL: The connector is for Modem with internal voice connector (Optional) J10: Extra SMBUS Pin No. Definition Signal-In Signal-Out Pin No. Definition SMB CLK SMB DATA Connectors...
  • Page 24: J12: Wake On Lan

    6OXC Series Motherboard J12: Wake On LAN J13: Ring Power On (Internal Modem Card Wake Up) Pin No. Definition +5V SB Signal Pin No. Definition Signal...
  • Page 25: J14: System Fan

    J14: System Fan J15: IA Port (Optional) Connectors Pin No. Definition +12V SENSE Pin No. Definition Giga-byte web-site Internet Finance Entertainment Shopping Searching People E-mail Play-pause Forward Rewind Eject Stop Mute Mic Volume up Mic Volume down Speaker Volume up Speaker Volume down Ground...
  • Page 26: Jp7: Str Led Connector & Led1: Dimm Led (Optional)

    6OXC Series Motherboard JP7: STR LED Connector & LED1: DIMM LED (Optional) JP9: SPDIF (The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby digital decoder.) [Optional] DIMM LED STR LED Connector External Pin No.
  • Page 27: Jp13: Ir/Cir

    JP13: IR/CIR PS/2 Keyboard & PS/2 Mouse Connector Pin No. Definition IRRX IRTX CIRRX CIRTX PS/2 Mouse PS/2 Keyboard PS/2 Mouse/ Keyboard Pin No. Definition Data VCC (+5V) Clock Connectors...
  • Page 28: Usb Connector

    6OXC Series Motherboard USB Connector Pin No. Definition USB Vcc USB D0- USB D0+ USB Vcc 1 2 3 4 USB D1- USB D1+...
  • Page 29: Panel And Jumper Definition

    Panel And Jumper Definition J11: For 2x11 Pins Jumper GN (Green Switch) GD (Green LED) HD (IDE Hard Disk Active LED) SPK (Speaker Connector) RE (Reset Switch) P+P P (Power LED) PW (Soft Power Connector) Panel and Jumper Definition Open: Normal Operation Close: Entering Green Mode Pin 1: LED anode(+) Pin 2: LED cathode( )
  • Page 30: Jp1: Rear Usb Device Wake Up Selection

    6OXC Series Motherboard JP1: Rear USB Device Wake up Selection (USB Connector Pin No. 1-2 close 2-3 close Normal (Default) (If you want to use “USB KB/Mouse Wake from S3” function, you have to set the BIOS setting “USB KB/Mouse Wake from S3”...
  • Page 31: Jp4: Str Enable (Optional)

    JP4: STR Enable (Optional) JP5: Over Voltage CPU Speed Up (Magic Booster) (When JP5 set “1-2 close”, CPU Voltage is rising 10%) Pin No. 1-2 close Turbo 2-3 close Normal (Default) Panel and Jumper Definition Pin No. Definition 1-2 close STR Enable 2-3 close STR Disable (Default) Definition [Voltage enhance 10%]...
  • Page 32: Jp6: Dimm Over Voltage (Optional)

    6OXC Series Motherboard JP6: DIMM Over Voltage (Optional) Pin No. 1-2 close Enable DIMM Over Voltage 2-3 close Disable DIMM Over Voltage JP12: Internal Buzzer Connector (Optional) 1-2 close Internal Buzzer Enable 2-3 close Internal Buzzer Disable Definition (Default) Pin No. Definition (Default)
  • Page 33: Jp14: Timeout Reboot Function

    JP14: Timeout Reboot Function 1-2 close No Reboot on Timeout 2-3 close Timeout Reboot JP15: Safe mode/Recovery/Normal Panel and Jumper Definition Pin No. Definition (Default) Pin No. Definition 1-2 close Normal (Default) 2-3 close Safe mode 1-2-3 open Recovery...
  • Page 34: Jp16: Onboard Sound Function Selection (Optional)

    6OXC Series Motherboard JP16: Onboard Sound Function Selection (Optional) JP18: Clear CMOS Function Pin No. Definition Enable Onboard Sound 1-2 close (Default) 2-3 close Disable Onboard Sound Pin No. Definition 1-2 close Clear CMOS 2-3 close Normal (Default)
  • Page 35: Jp19 (Front Usb Device Wake Up Selection) [Optional]

    JP19: Front USB Device Wake up Selection(USB Port (If you want to use “USB KB/Mouse Wake from S3” function, you have to set the BIOS setting “USB KB/Mouse Wake from S3” enabled, and the jumper “JP19&JP1” enabled). *(Power on the computer and as soon as memory counting starts, press <Del>.
  • Page 36: Jp21: Top Block Lock

    6OXC Series Motherboard JP21: Top Block Lock 1-2 close Top Block Unlock (Default) 2-3 close Top Block Lock JP22: Case Open Pin No. Definition Pin No. Definition Signal...
  • Page 37: Jp23: Pci/Agp 3Vaux

    JP23: PCI/AGP 3VAUX Pin No. 1-2 close Enable PCI/AGP 3.3Vsb 2-3 close Disable PCI/AGP 3.3Vsb JP24 AMR Selection (Optional) Pin No. 1-2 close AMR Secondary (Default) 2-3 close Panel and Jumper Definition Definition (Default) Definition AMR Primary AC’97 Disable (Disable Onboard CODEC)
  • Page 38: Jp28 On Board Codec Function Selection (Optional)

    6OXC Series Motherboard JP28 On Board CODEC Function Selection (Optional) Pin No. 1-2 close Enable(Default) 2-3 close Disable JP29 SPDIF Function Selection (Optional) Pin No. Definition Definition close Enable open Disable...
  • Page 39: Jp30: Front Mic Selection (Optional)

    JP30: Front MIC Selection (Optional) BAT1: Battery Panel and Jumper Definition Pin No. Definition Close Front MIC Disable Open Front MIC Enable CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer.
  • Page 40: Performance List

    6OXC Series Motherboard Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Intel Socket 370 Processor DRAM...
  • Page 41: Block Diagram

    Block Diagram Socket 370 AGP 2X/4X FW82815EP ATA66 IDE Channels 82801AA W81181 2 USB Ports 2 USB Ports COM Ports Game Port IT8712 LPT Port Smart Card Reader Floppy PS/2 IR/CIR Block Diagram 66/100/133 MHz Host Bus 66/100/133MHz 66/100/133 MHz Intel 3.3V SDRAM 100/133 MHz...
  • Page 42: Suspend To Ram Installation (Optional)

    6OXC Series Motherboard Suspend To RAM Installation (Optional) A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 43 Step 2: (If you want to use STR Function, please set jumper JP4 Pin1-2 Closed.) 1-2 close STR Enable 2-3 close STR Disable Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup.
  • Page 44 6OXC Series Motherboard A.3 How to put your system into STR mode? There are two ways to accomplish this: Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” B.
  • Page 45 Suspend to RAM Installation Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 46 6OXC Series Motherboard C. Select the “Advanced” tab and “Standby” mode in Power Buttons. Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button. A.4 How to recover from the STR sleep mode? There are seven ways to “wake up”...
  • Page 47 A.5 Notices: In order for STR to function properly, several hardware and software requirements must be satisfied: A. Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). B. Your SDRAM must be PC-100 compliant. 2.
  • Page 48: Introduce Dual Bios (Optional)

    6OXC Series Motherboard Introduce Dual BIOS (Optional) What is Dual BIOS Technology? Dual BIOS means that there are two system BIOS (ROM) on the motherboard, one is the Main BIOS and the other is Backup BIOS. Under the normal circumstances, the system works on the Main BIOS.
  • Page 49 Dual BIOS Utility Dual BIOS Utility V6.60.g.01K (C) 1999, Gigabyte Technology Co., LTD. Wide Range Protection Halt On BIOS Defects Auto Recovery Boot From BIOS Recovery F3: Load Default F7: Save And Restart Use <Space> key to toggle setup c.
  • Page 50 6OXC Series Motherboard Halt On BIOS Defects : Disabled(Default), Enabled If the BIOS occurs a checksum error or the Main BIOS occurs a WIDE RANGE PROTECTION error and Halt On BIOS Defects set to Enable, the PC will show messages on the boot screen, and the system will pause and wait for the user’s instruction.
  • Page 51 DualBIOS Technology FAQ GIGABYTE Technology is pleased to introduce DualBIOS technology, a hot spare for your system BIOS. This newest “Value-added” feature, in a long series of innovations from GIGABYTE, is available on GA-6OXC Series motherboard. Future GIGABYTE motherboards will also incorporate this innovation.
  • Page 52 6OXC Series Motherboard I. Q: What is DualBIOS technology? Answer: DualBIOS technology is a patented technology from Giga-Byte Technology. The concept of this technology is based on the redundancy and fault tolerance theory. DualBIOS means there are two system BIOSes (ROM) integrated onto the motherboard. One is a main BIOS, and the other is a backup BIOS.
  • Page 53 III. Q: How does DualBIOS technology work? Answer: 1. DualBIOS technology provides a wide range of protection during the boot up procedure. It protects your BIOS during system POST, ESCD update, and even all the way to PNP detection/assignment. 2. DualBIOS provides automatic recovery for the BIOS.
  • Page 54 6OXC Series Motherboard 2. During or after a BIOS upgrade, if DualBIOS backup BIOS will take over the boot-up process automatically. Moreover, it will verify the main and backup BIOS checksums when booting-up. DualBIOS checksum of the main and backup BIOS while the system is powered on to guarantee your BIOS operates properly.
  • Page 55: Four Speaker & Spdif Introduction (Optional)

    Four Speaker & SPDIF Introduction (Optional) Four Speaker Introduction What is Four Speaker? The Creative CT5880 audio chip can support 4 speaker output, if you select “Four speaker” out, Line in will be change to another line out. How to use Four Speaker? a.
  • Page 56 6OXC Series Motherboard c. Click “Four speaker” item. Four Speaker Application The four speaker function will only support in application software that use Microsoft DirectX and Creative EAX. For example, the game titles, software DVD player and MP3 player. Those software support Microsoft DirectX, so they can support four speaker output.
  • Page 57 SPDIF Introduction What is SPDIF? The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby digital decoder. How to use SPDIF? a. Press your mouse right button in “My Computer” and then select the “Properties” item. b.
  • Page 58 6OXC Series Motherboard c. Press “Sound, video and game controllers” item and then select the “Creative Sound Blaster PCI128” item. d. Press “Settings” item and then select the “Output Mode” item.
  • Page 59 Four Speaker & SPDIF Introduction e. Click “Digital” item, Line Out will be change to SPDIF Out. f. Recommend you to select “Autosense”, it will auto detect the audio jack you plug in to Line Out is mono or stereo, and then change to SPDIF Out or Speaker out automatically.
  • Page 60: Bios Tm Introduction

    BIOS, just choose “Save Current BIOS” to save it first. You make a wise choice to use Gigabyte, and @BIOS update your BIOS smartly. You are now worry free from updating wrong BIOS, and capable to maintain and manage your BIOS easily.
  • Page 61: Easytuneiii Tm Introduction

    Click “Advanced Mode” to enjoy “sport drive” class overclocking. In “Advanced Mode”, one can change the system bus speed in small increments to get ultimate system performance. And no matter which mainboard is used, if it’s a Gigabyte’s product*, EasyTuneIII helps to perform the best of system.
  • Page 62: Memory Installation

    6OXC Series Motherboard Memory Installation The motherboard has 4 dual inline memory module (DIMM) sockets support 6 banks. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
  • Page 63: Page Index For Bios Setup

    Page Index for BIOS Setup The Main Menu Standard CMOS Features Advanced BIOS Features Advanced Chipset Features Integrated Peripherals Power Management Setup PnP/ PCI Configurations PC Health Status Frequency / Voltage Control Load Fail-Safe Defaults Load Optimized Defaults Set Supervisor / User Password Save &...
  • Page 64: Entering Setup

    6OXC Series Motherboard BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Power ON the computer and press <Del>...
  • Page 65: The Main Menu

    GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 66 6OXC Series Motherboard Standard CMOS Features This setup page includes all the items in standard compatible BIOS. Advanced BIOS Features This setup page includes all the items of Award special enhanced features. Advanced Chipset Features This setup page includes all the items of chipset special features. Integrated Peripherals This setup page includes all onboard peripherals.
  • Page 67 BIOS Setup Save & Exit Setup Save CMOS value settings to CMOS and exit setup. Exit Without Saving Abandon all CMOS value changes and exit setup.
  • Page 68: Standard Cmos Features

    6OXC Series Motherboard Standard CMOS Features The items in Standard CMOS Setup Menu (Figure 3) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp>...
  • Page 69 Time The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. IDE Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer.
  • Page 70 6OXC Series Motherboard Floppy 3 Mode Support (for Japan Area) Disabled Normal Floppy Drive. (Default value) Drive A Drive A is 3 mode Floppy Drive. Drive B Drive B is 3 mode Floppy Drive. Both Drive A & B are 3 mode Floppy Drives. Video The category detects the type of adapter used for the primary system monitor that must match your video display card and monitor.
  • Page 71 Memory The category is display-only which is determined by POST (Power On Self Test) of the BIOS. Base Memory The POST of the BIOS will determine the amount of base (or conventional) memory installed in the system. The value of the base memory is typically 512 K for systems with 512 K memory installed on the motherboard, or 640 K for systems with 640 K or more memory installed on the motherboard.
  • Page 72: Advanced Bios Features

    6OXC Series Motherboard Advanced BIOS Features CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software Advanced BIOS Features Virus Warning BIOS Flash Protection Processor Number Feature First Boot Device Second Boot Device Third Boot Device Boot Up Floppy Seek Boot Up NumLock Status Security Option HDD S.M.A.R.T.
  • Page 73 BIOS Flash Protection Enabled Enabled BIOS Flash Protection. Disabled Disabled BIOS Flash Protection. (Default Value) Processor Number Feature This item will show up when you install the Pentium Enabled Pentium !!! Processor Number Feature. (Default value) ® Disabled Disabled this function. First / Second / Third Boot device Floppy Select your boot device priority by Floppy.
  • Page 74 6OXC Series Motherboard Security Option This category allows you to limit access to the system and Setup, or just to Setup. System The system can not boot and can not access to Setup page will be denied if the correct password is not entered at the prompt. Setup The system will boot, but access to Setup will be denied if the correct password is not entered at the prompt.
  • Page 75: Advanced Chipset Features

    Advanced Chipset Features CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software Advanced Chipset Features Top Performance SDRAM Timing Control SDRAM CAS Latency Time SDRAM Cycle Time Tras/Trc SDRAM RAS-to-CAS Delay SDRAM RAS Precharge Time Delayed Transaction AGP Graphics Aperture Size System Memory Frequency SDRAM Buffer Strength X SWE#, SCAS#, SRAS, SMAA, SBS...
  • Page 76 6OXC Series Motherboard Top Performance If you wish to maximize the performance of your system, set “Top Performance” as “Enabled”. Disabled Disabled this function. (Default Value) Enabled Enabled Top Performance function. SDRAM Timing Control Auto Set SDRAM Timing Control to Auto. (Default value) Manual Set SDRAM Timing Control to Manual.
  • Page 77 System Memory Frequency Auto Set System Memory Frequency to Auto. (Default value) 100MHz Set System Memory Frequency to 100MHz. 133MHz Set System Memory Frequency to 133MHz. SDRAM Buffer Strength Auto Set SDRAM Buffer Strength to Auto. (Default value) Manual Set SDRAM Buffer Strength to Manual. SWE#, SCAS#, SRAS#, SMAA, SBS Default Set SWE#, SCAS#, SRAS#, SMAA, SBS to Default.
  • Page 78 6OXC Series Motherboard SMAC#[7:4] (Rows 4/5) Default Set SMAC#[7:4] (Rows 4/5) to Default. (Default value) 2.7x Set SMAC#[7:4] (Rows 4/5) to 2.7x. 1.7x Set SMAC#[7:4] (Rows 4/5) to 1.7x. 1.0x Set SMAC#[7:4] (Rows 4/5) to 1.0x. SCS[0]# (Row 0) Default Set SCS[0]# (Row 0) to Default.
  • Page 79 SCKE[0]# (Row 0) Default Set SCKE[0]# (Row 0) to Default. (Default value) 2.7x Set SCKE[0]# (Row 0) to 2.7x. 1.7x Set SCKE[0]# (Row 0) to 1.7x. SCKE[1]# (Row 1) Default Set SCKE[1]# (Row 1) to Default. (Default value) 2.7x Set SCKE[1]# (Row 1) to 2.7x. 1.7x Set SCKE[1]# (Row 1) to 1.7x.
  • Page 80: Integrated Peripherals

    6OXC Series Motherboard Integrated Peripherals CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software Integrated Peripherals On-Chip Primary PCI IDE On-Chip Secondary PCI IDE IDE Primary Master PIO IDE Primary Slave PIO IDE Secondary Master PIO IDE Secondary Slave PIO IDE Primary Master UDMA IDE Primary Slave UDMA IDE Secondary Master UDMA IDE Secondary Slave UDMA...
  • Page 81 On-Chip Primary PCI IDE Enabled Enable onboard 1st channel IDE port. (Default value) Disabled Disable onboard 1st channel IDE port. On-Chip Secondary PCI IDE Enabled Enable onboard 2nd channel IDE port. (Default value) Disabled Disable onboard 2nd channel IDE port. IDE Primary Master PIO (for onboard IDE 1st channel) Auto BIOS will automatically detect the IDE HDD Accessing mode.
  • Page 82 6OXC Series Motherboard IDE Secondary Master UDMA Auto BIOS will automatically detect the IDE HDD Accessing mode. (Default value) Disabled Disable UDMA function. IDE Secondary Slave UDMA Auto BIOS will automatically detect the IDE HDD Accessing mode. (Default value) Disabled Disable UDMA function.
  • Page 83 IDE HDD Block Mode Enabled Enabled IDE HDD Block Mode. (Default value) Disabled Disabled IDE HDD Block Mode. POWER ON by Keyboard Password Enter from 1 to 5 characters to set the Keyboard Power On Password. Disabled Disabled this function. (Default value) Keyboard 98 If your keyboard have “POWER Key”...
  • Page 84 6OXC Series Motherboard UART Mode Select (This item allows you to determine which Infra Red(IR) function of Onboard I/O chip) ASKIR Set onboard I/O chip UART to ASKIR Mode. IrDA Set onboard I/O chip UART to IrDA Mode. Set onboard I/O chip UART to SCR Mode. Normal Set onboard I/O chip UART to Normal Mode.
  • Page 85 Midi Port Address Disabled Disabled On Board Midi Port. Set On Board Midi Port to 300. Set On Board Midi Port to 330. (Default value) Midi Port IRQ Set 5 for Midi Port IRQ. Set 10 for Midi Port IRQ. (Default value) CIR Port Address Disabled Disabled this function.
  • Page 86: Power Management Setup

    6OXC Series Motherboard Power Management Setup CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software Power Management Setup ACPI Suspend Type Video Off Method Suspend Type MODEM Use IRQ Suspend Mode HDD Power Down Soft-Off by PWR-BTTN Power LED in Suspend Wake-Up by PCI card ModemRingOn/WakeOnLan USB KB/Mouse Wake From S3...
  • Page 87 Video off Method V/H SYNC+Blank BIOS will turn off V/H-SYNC when gets into Green mode for Green monitor power saving. Blank Screen BIOS will only black monitor when gets into Green mode. DPMS BIOS will use DPMS Standard to control VGA card. (The Green type VGA card will turn off V/H-SYNC automatically.) (Default value) Suspend Type...
  • Page 88 6OXC Series Motherboard Power LED in Suspend Blinking Set Power LED in Suspend at Blinking mode. (Default value) Set Power LED in Suspend at On mode. Off/Dual Set Power LED in Suspend at Off/Dual color mode. Wake-Up by PCI card Disabled Disabled this function.
  • Page 89 Resume by Alarm You can set “Resume by Alarm” item to Enabled and key in date/time to power on system. Disabled Disable this function. (Default value) Enabled Enable alarm function to POWER ON system. If the default value is Enabled. Date ( of Month) Alarm : Everyday, 1~31 Time ( hh: mm: ss) Alarm :...
  • Page 90: Pnp/Pci Configurations

    6OXC Series Motherboard PnP/PCI Configurations CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software PnP/PCI Configurations Reset Configuration Data Resources Controlled By X IRQ Resources PCI/VGA Palette Snoop Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults Figure 8: PnP/PCI Configurations Reset Configuration Data Disabled Disabled this function.
  • Page 91 PCI/VGA Palette Snoop Enabled For having Video Card on ISA Bus and VGA Card on PCI Bus. Disabled For VGA Card only. (Default value) BIOS Setup...
  • Page 92: Pc Health Status

    6OXC Series Motherboard PC Health Status CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software PC Health Status Reset Case Open Status Case Opened VCORE VGTL VCC3 + 5V +12V - 12V 5VSB(V) VBAT(V) Current CPU Temperature CPU FAN Speed Power FAN Speed System FAN speed CPU Temperature Select Shutdown Temperature...
  • Page 93 CPU FAN / Power FAN / System FAN Speed (RPM) Detect Fan speed status automatically. CPU Temperature Select ( C) 65 C / 149 F Monitor CPU Temp. at 65 C / 149 F. 70 C / 158 F Monitor CPU Temp. at 70 C / 158 F. 75 C / 167 F Monitor CPU Temp.
  • Page 94: Frequency/Voltage Control

    6OXC Series Motherboard Frequency/Voltage Control CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software Frequency/Voltage Control Auto Detect DIMM/PCI Clk CPU Clock Ratio Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults Figure 10: Frequency/Voltage Control Auto Detect DIMM/PCI Clk Disabled Disabled Auto Detect DIMM/PCI Clk.
  • Page 95: Load Fail-Safe Defaults

    Load Fail-Safe Defaults CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features 4 Advanced BIOS Features 4 Advanced Chipset Features 4 Integrated Peripherals 4 Power Management Setup Load Fail-Safe Defaults (Y/N)? N 4 PnP/PCI Configurations 4 PC Health Status ESC:Quit F10:Save &...
  • Page 96: Load Optimized Defaults

    6OXC Series Motherboard Load Optimized Defaults CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features 4 Advanced BIOS Features 4 Advanced Chipset Features 4 Integrated Peripherals 4 Power Management Setup 4 PnP/PCI Configurations Load Optimized Defaults (Y/N)? N 4 PC Health Status ESC:Quit F10:Save &...
  • Page 97: Set Supervisor / User Password

    Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features 4 Advanced BIOS Features 4 Advanced Chipset Features 4 Integrated Peripherals...
  • Page 98 6OXC Series Motherboard only when you try to enter Setup.
  • Page 99: Save & Exit Setup

    Save & Exit Setup CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features 4 Advanced BIOS Features 4 Advanced Chipset Features 4 Integrated Peripherals 4 Power Management Setup 4 PnP/PCI Configurations SAVE to CMOS and EXIT (Y/N)? Y 4 PC Health Status ESC:Quit F10:Save &...
  • Page 100: Exit Without Saving

    6OXC Series Motherboard Exit Without Saving CMOS Setup Utility-Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features 4 Advanced BIOS Features 4 Advanced Chipset Features 4 Integrated Peripherals 4 Power Management Setup 4 PnP/PCI Configurations Quit Without Saving (Y/N)? N 4 PC Health Status ESC:Quit F10:Save &...
  • Page 102: Appendix

    6OXC Series Motherboard Appendix Appendix A: Intel 815 Chipsets Driver Installation A. Windows 9x INF Update Utility Insert the support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the setup screen. 1.Click “Windows 9x INF Update Utility”...
  • Page 103 B: Intel 815 Chipsets VGA Graphics Driver (Intel 82815EP Chipset Not Support VGA Graphics) C. Intel Ultra ATA Storage Driver Installation Insert the support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the setup screen. 1.Click “Intel Ultra ATA Storage Driver”...
  • Page 104 6OXC Series Motherboard 5.Click ”Next”. 6.Click “Finish” to restart computer.
  • Page 105 Appendix B: Creative Sound Driver Installation (Optional) Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. Press “Audio” icon. 1.Click “Creative CT5880 Sound Driver”.
  • Page 106 6OXC Series Motherboard 7.Click “Next”. 8.Click “Finish” to restart computer.
  • Page 107 Appendix C: SigmaTel AC’97 Audio Driver Installation (Optional) Insert the support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the setup screen. Press “Audio” icon. 1.Click “SigmaTel AC’97 Audio Driver”. 3.Click “Yes “.
  • Page 108 6OXC Series Motherboard Appendix D: BIOS Flash Procedure BIOS update procedure: If your OS is Win9X, we recommend that you used Gigabyte @BIOS Program to flash BIOS. Click “Tool”. Click “@BIOS Writer v1.05a”. Click “ ”. Methods and steps: I. Update BIOS through Internet a.
  • Page 109 In method I, if the BIOS file you need cannot be found in @BIOS server, please go onto Gigabyte's web site for downloading and updating it according to method II. d. Please note that any intercorruption during updating will cause system unbooted...
  • Page 110 Format a bootable system floppy diskette by the command “format a:/s” in command mode. Visit the Gigabyte website at http:// need and download it to your bootable floppy diskette. Insert the bootable diskette containing the BIOS file into the floppy diskette driver.
  • Page 111 Appendix Appendix E: Issues To Beware Of When Installing AMR Please use inverse AMR card like the one in order to avoid mechanical problem. (See Figure A) PCI Slot Figure A: Inverse AMR Card (Default) PCI Slot Figure B: Non inverse AMR Card...
  • Page 112 6OXC Series Motherboard Appendix F: Acronyms Acronyms Meaning ACPI Advanced Configuration and Power Interface Advanced Power Management Accelerated Graphics Port Audio Modem Riser Audio Communication Riser BIOS Basic Input / Output System Central Processing Unit CMOS Complementary Metal Oxide Semiconductor CRIMM Continuity RIMM Communication and Networking Riser...
  • Page 113 Acronyms Meaning Original Equipment Manufacturer PCI A.G.P. Controller POST Power-On Self Test Peripheral Component Interconnect RIMM Rambus in-line Memory Module Special Circumstance Instructions SECC Single Edge Contact Cartridge SRAM Static Random Access Memory Symmetric Multi-Processing System Management Interrupt Universal Serial Bus Voltage ID Appendix...
