COLONY™ 5' x 30" WHIRLPOOL AND
BATHING POOL with INTEGRAL APRON
2740.118 Whirlpool, Right Hand Outlet
2740.218 Whirlpool, Left Hand Outlet
Product Features:
• High Gloss Acrylic with fi berglass reinforcement
• Integral apron with removable access panel
• Integral three-sided, tiling/water retention fl ange
• Integral lumbar support
• Molded-in arm rests with elbow supports
• Above fl oor rough
• 1.25 HP single speed, self-draining pump/motor
• Six multi-direction jets
• One air volume control
• Deck mounted air switch On/Off control
• Factory installed and tested whirlpool system
EverClean™ Whirlpool Massage featuring System I
2740.218C Whirlpool featuring System I,
Left Hand Outlet
2740.118C Whirlpool featuring System I,
Right Hand Outlet
• Same as above except with the EverClean™
whirlpool system featuring Antimicrobial
®
AlphaSan
2740.102 Bath only, Right Hand Outlet
2740.202 Bath only, Left Hand Outlet
• Same as above without whirlpool system
Nominal Dimensions:
(59-7/8" x 29-7/8" x 19-1/4")
1521 x 759 x 489mm
Compliance Certifi cations -
Meets or Exceeds the Following Specifi cations:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
SEE REVERSE FOR ROUGHING-IN DIMENSIONS
AND PRODUCT SPECIFICATIONS
© 2007 American Standard Inc.
COLONY™ 5' x 30" w/INTEGRAL APRON
WHIRLPOOL & BATHING POOL
To Be Specifi ed - Required:
❏ Color:
❏ Bath Faucet: (specify fi nish)
❏ Bath Drain: 1583.470 (specify fi nish)
For color/fi nish availability and other faucet choices, please
see the Product Selector and Pricing Guide.
H65
HIGH GLOSS ACRYLIC
Revised 1/07
