American Standard Colony 2740.102 Specifications
American Standard Colony 2740.102 Specifications

American Standard Colony 2740.102 Specifications

5’ x 30” w/integral apron whirlpool and bathing pool high gloss acrylic

Advertisement

Quick Links

COLONY 5' x 30" WHIRLPOOL AND BATHING
POOL with INTEGRAL APRON
2740.118 Whirlpool, Right Hand Outlet
2740.218 Whirlpool, Left Hand Outlet
Product Features:
• High Gloss Acrylic with fiberglass
reinforcement
• Integral apron with removable access panel
• Integral three-sided, tiling/water retention
flange
• Integral lumbar support
• Molded-in arm rests with elbow supports
• Safety textured tub bottom pattern
Factory installed and tested whirlpool system
featuring:
• Rigid P.V.C. piping
• 1 H.P. self-draining pump/motor with Dry Run
seal
• Six multi-direction jets
• One air volume control
• Anti-vortex suction fitting
• Deck mounted air switch On/Off control
• U.L.® Listed entire whirlpool system
2740.102 Bath only, Right Hand Outlet
2740.202 Bath only, Left Hand Outlet
• Same as above without whirlpool system
Nominal Dimensions:
(59-7/8" x 29-7/8" x 19-1/4")
1521 x 759 x 489mm
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
12/99
COLONY™ 5' X 30" w/INTEGRAL APRON
WHIRLPOOL AND BATHING POOL
To Be Specified - :
Color:
Bath/Shower Faucet*:
Faucet Finish:
Bath Drain: 1553.270
002 Chrome
* See faucet section for models available
NOTE: Roughing-in dimensions and product specifica-
tions shown on reverse side of page.
SPS 2740
© 1999 American Standard Inc.
HIGH GLOSS ACRYLIC
099 Polished Brass
BV-018B
