Model No. GGEL60407.1
Serial No.
Write the serial number in the
space above for reference.
Serial Number
(on underside
QUESTIONS?
As a manufacturer, we are commit-
ted to providing complete customer
satisfaction. If you have questions,
or if parts are damaged or missing,
PLEASE DO NOT CONTACT THE
STORE; please contact Customer
Care.
IMPORTANT: You must note the
product model number and serial
number (see the drawing above)
before contacting us:
CALL TOLL-FREE:
1-877-776-4777
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.goldsgympowerflex.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manu-
al for future reference.
Decal
of frame)
USER'S MANUAL
Advertisement
Table of Contents
Related Manuals for Gold's Gym GGEL60407.1
Summary of Contents for Gold's Gym GGEL60407.1
- Page 1 Model No. GGEL60407.1 Serial No. Write the serial number in the space above for reference. Serial Number Decal (on underside of frame) QUESTIONS? As a manufacturer, we are commit- ted to providing complete customer satisfaction. If you have questions, or if parts are damaged or missing, PLEASE DO NOT CONTACT THE STORE;...
-
Page 2: Table Of Contents
Apply the decal in the location shown. Note: The decal may not be shown at actual size. GOLD'S GYM is a registered trademark of Gold's Gym International, Inc. This product is manufactured and distributed under license from Gold's Gym International, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical exerciser before using your elliptical exerciser. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product. -
Page 4: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new GOLD’S GYM CROSSTRAINER 510 elliptical exerciser. The GOLD’S GYM CROSSTRAINER 510 elliptical exercis- er provides a wide array of features designed to make your workouts at home more effective and enjoyable. For your benefit, read this manual carefully before you use the elliptical exerciser. -
Page 5: Assembly
ASSEMBLY To hire an authorized service technician to assemble the elliptical exerciser, call 1-800-445-2480. Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included hex keys, assembly requires a Phillips screwdriver wrench , and a rubber mallet... - Page 6 To make assembly easier, read the information on page 5 before you begin assembling the elliptical exerciser. Orient the the Front Stabilizer (35) as shown. Attach the two Wheels (25) to the Front Stabilizer with two M10 x 62mm Patch Bolts (89) and two M10 Nylon Locknuts (97).
- Page 7 4. Have a second person hold the Upright (6) near the Frame (2) as shown. Pull the Wire Harness (48) out of the Frame (2) and insert it upward through the Upright (6). Do not let the Wire Harness fall into the Upright; use a piece of tape or an elastic band to hold the Wire Harness in place until step 12.
- Page 8 6. Identify the Left Handlebar (8), which is marked with a “Left” sticker. Insert the Left Handlebar into one of the Handlebar Legs (11) as shown. Attach the Left Handlebar (8) with two M8 x 42mm Bolts (71) and two M8 Nylon Locknuts (96).
- Page 9 8. Apply a generous amount of grease to the Pivot Axle (65) and insert it into the Frame (2). Attach the two Frame Covers (17) to the Frame (2) with four M4 x 16mm Screws (86) as shown. 9. Apply a small amount of grease to both sides of a Wave Washer (98).
- Page 10 10. Identify the Left Pedal (13) and the Left Pedal Leg (14), which are marked with “Left” stickers, and orient them as shown. Attach the Left Pedal (13) to the Left Pedal Leg (14) with four M6 x 35mm Phillips Screws (87) and four M6 Split Washers (88).
- Page 11 12. The Console (5) requires four 1.5V “D” batteries (not included); alkaline batteries are recom- mended. IMPORTANT: If the elliptical exercis- er has been exposed to cold temperatures, allow it to warm to room temperature before inserting batteries into the Console. If you do not do this, the console displays or other electronic components may become dam- aged.
-
Page 12: How To Use The Elliptical Exerciser
HOW TO USE THE ELLIPTICAL EXERCISER HOW TO MOVE THE ELLIPTICAL EXERCISER Due to the size and weight of the elliptical exercis- er, moving it requires two persons. Stand in front of the elliptical exerciser, hold the upright, and place one foot against one of the front wheels. - Page 13 CONSOLE DIAGRAM FEATURES OF THE CONSOLE The advanced console offers an array of features designed to make your workouts more effective and enjoyable. When you select the manual mode of the console, you can change the resistance of the pedals with the touch of a button.
-
Page 14: How To Use The Manual Mode
HOW TO USE THE MANUAL MODE 1. Press any button on the console or begin ped- aling to turn on the console. When you turn on the console, the displays and the workout target pacer will light. A tone will then sound and the console will be ready for use. - Page 15 5. Measure your heart rate if desired. If there are sheets of clear plastic on the metal contacts on the handgrip pulse sensor, remove the plas- tic. In addition, make sure that your hands are clean. To measure your heart rate, hold the handgrip pulse sensor with your palms resting against the metal contacts.
- Page 16 HOW TO USE AN AUDIO COACH WORKOUT 1. Press any button on the console or begin ped- aling to turn on the console. See step 1 on page 14. 2. Select an audio coach workout. To select one of the seven audio coach workouts, press one of the seven buttons on the left side of the console.
- Page 17 HOW TO USE A PRESET WORKOUT 1. Press any button on the console or begin ped- aling to turn on the console. See step 1 on page 14. 2. Select a preset workout. To select one of the seven preset workouts, press one of the seven buttons on the right side of the console.
-
Page 18: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the elliptical exerciser regularly. Replace any worn parts immediately. To clean the elliptical exerciser, use a damp cloth and a small amount of mild soap. Important: To avoid damage to the console, keep liquids away from the console and keep the console out of direct sunlight. -
Page 19: Exercise Guidelines
EXERCISE GUIDELINES WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for persons over the age of 35 or persons with pre-existing health problems. The pulse sensor is not a medical device. Various factors may affect the accuracy of heart rate readings. -
Page 20: Part List
PART LIST—Model No. GGEL60407.1 Key No. Qty. Description Base Frame Outer Crank Arm Cover Inner Crank Arm Cover Console Upright Roller Cover Left Handlebar Right Handlebar Handlebar Endcap Handlebar Leg Left Roller Leg Left Pedal Left Pedal Leg Right Pedal... - Page 21 Key No. Qty. Description M10 x 20mm Patch Screw Star Washer M4 x 13mm Washer M10 x 25mm Washer M8 x 16mm Patch Screw M8 Nylon Locknut Note: Specifications are subject to change without notice. See the back cover of this manual for information about ordering replacement parts.
-
Page 22: Exploded Drawing
EXPLODED DRAWING A—Model No. GGEL60407.1 R0108A... - Page 23 EXPLODED DRAWING B—Model No. GGEL60407.1 R0108A...
-
Page 24: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
